- Page 1 RADIUS EW 350 EW 350 ELECTRIC ACTUATOR INSTALLATION, MAINTENANCE AND OPERATION MANUAL RADIUS, LLC 4922 TECHNICAL DR. MILFORD, MI 48381 www.radius-eng.com...
- Page 2 Thank you for purchasing our EW series electric actuator! For safe and proper operation, please carefully read this manual before using and save it for reference Important note: Radius reserves the right to change the content of this document without prior notification.
- Page 3 2>Sizing should be done after careful reviewing the valve type, temperature/ pressure, characteristics of fluid, etc. 3> Applications under abnormal condition such as high and low temperature, seawater, severe corrosion and high vibration, consult with our technical dept before selecting actuator. RADIUS, LLC 4922 TECHNICAL DR. MILFORD, MI 48381 www.radius-eng.com...
- Page 4 3> Tighten cam set screw (M2) to fix cam position. 4> Do the same way for open position OLS CAM (OPEN LIMIT SWITCH CAM) MICRO SWITCHES (SPDT) CLS CAM (CLOSE LIMIT SWITCH CAM) RADIUS, LLC 4922 TECHNICAL DR. MILFORD, MI 48381 www.radius-eng.com...
- Page 5 Do wiring again tightly Coil of motor is damaged Change the motor Capacitor is damaged Change the capacitor Setting of limit and torque switch is not correct Do setting switches again RADIUS, LLC 4922 TECHNICAL DR. MILFORD, MI 48381 www.radius-eng.com...
- Page 6 Long service life can be achieved if a yearly inspection of the actuator is performed. Pleas check operating condition, corrosion, painting & etc. Others : Should you have any further queries, please contact us through Phone, fax and E-mail without hesitation. RADIUS, LLC 4922 TECHNICAL DR. MILFORD, MI 48381 www.radius-eng.com...
