Summary of Contents for Urbanworx CAM-1080PFHD
- Page 1 FULL HD ACTION CAMERA CAM-1080PFHD INSTRUCTION MANUAL Please read this manual carefully before using, and keep it for future reference.
-
Page 3: Table Of Contents
CONTENTS General Safety The Basics Removing Battery Charging Memory card use Accessing Files Wrist Remote Control First Time Use Shooting Mode Video Recording Mode Car Carrying Mode Replay Menu Specifications... -
Page 4: General Safety
GENERAL SAFETY Read this manual thoroughly before you start using the Urbanworx Action Camera. Store this manual, the completed warranty card, your receipt and the product packaging. The safety precautions instructions reduces the risk of fire, electric shock and injury when correctly complied to. -
Page 5: The Basics
THE BASICS FRONT BACK FRONT: BACK: 1. Battery Indicator 1. LCD Screen 2. Shutter Key 2. Up 3. Microphone 3. Mode Button 4. Charging Indicator 4. Down 5. Micro SD Card Slot 5. Power On/Off 6. Micro USB Port 7. Infrared Remote Light 8. -
Page 6: Removing Battery
REMOVING BATTERY Removing battery from the camera 1. Remove the battery door by placing your thumb. 2. Allow the door to pop out, grasp the battery pull-tab and remove from the camera. 3. When re inserting the Battery pack, ensure the LCD side of the Action Camera is facing up and the Battery pack connections facing up and insert the battery pack. -
Page 7: Charging
CHARGING Charge the built-in Lithium Battery The camera is equipped with a built-in 3.7V lithium battery. Please ensure it is charged before first time use. Connecting the camera to a computer for charging, the light indicator will turn on and will turn off once the action camera is fully charged. -
Page 8: Accessing Files
ACCESSING FILES Accessing files from a computer Using the Micro USB cable provided, plug in your Aciton Camera to your PC and your PC will automatically detect the action camera. You will then be able to access all the Video’s and Photo’s taken. Viewing the files from a TV Using the Micro USB cable provided, plug in your Aciton Camera to your TV. -
Page 9: Wrist Remote Control
WRIST REMOTE CONTROL 1. Undo the strap and fit it around your left wrist, please ensure it is on your left wrist as the infrared sensor will need to face towards the Action Camera to work correctly. 2. To take a Photo, press the Photo (Camera) button to take a photo. If in another mode, press the button once and it will take it to “Shooting Mode”, then press again to take a photo. -
Page 10: First Time Use
FIRST TIME USE Turning on the Action Camera To turn on the camera, press the power button and hold the power button for 3 seconds. To shut down the camera, hold power button for 3 seconds. Auto shutdown The action camera will automatically shutdown when the camera hasnt been in use for a certain time to save power. -
Page 11: Video Recording Mode
FIRST TIME USE (CONT.) Video Recording Mode After Action Camera is turned on, press the Mode button to enter recording mode. Press OK button to start video recording. If you want to stop recording, press OK button. 1. Icon of Video Recording Mode 2. -
Page 12: Replay Menu
FIRST TIME USE (CONT.) Replay Mode After Action Camera is turned on, press the Mode button until you enter recording mode. Press OK button to start video recording. When video file being played, press OK to pause, play and click power to stop playing. Press Mode button if you want to go back to Shooting Mode. -
Page 13: Specifications
SPECIFICATIONS Function Modes Video Recording, Car Carrying, Shooting and replay Lens: F2.6 f=3.56mm LCD Display Screen: 2.0 inch TFT LCD Screen 5M(2592*1944) / 3M(2048*1536) / 1M(1280*960) / Photo Definition Ratio: VGA(640*480) Full HD - 1920X1080 25fps Video Definition Ratio: HD - 1280X720 30fps VGA - 640X480 60fps File Formats: Videos(AVI) / Photos(JPG) - Page 16 CUSTOMER HELPLINE: 1300 296 699 info@ayonz.com DISTRIBUTED BY: Ayonz Pty Ltd PO Box 3291, North Strathfield, NSW, 2137...
