- Page 1 ASSEMBLY INSTRUCTIONS Echo panel screen Need help! Call us on Sizes: 1200 / 1600 mm wide 1300 527 665 Page 1 of 4...
- Page 2 ASSEMBLY INSTRUCTIONS Echo panel screen Need help! Call us on Sizes: 1200 / 1600 mm wide 1300 527 665 STEP 01 Please leave 25mm gap between table tops (A) so we can install pincer clamp brackets between the two table tops.
- Page 3 ASSEMBLY INSTRUCTIONS Echo panel screen Need help! Call us on Sizes: 1200 / 1600 mm wide 1300 527 665 STEP 02 STEP 03 Step 2: Once desired location is set, please tighten the first pincer clamp bracket bottom screw using an allen key.
- Page 4 ASSEMBLY INSTRUCTIONS Echo panel screen Need help! Call us on Sizes: 1200 / 1600 mm wide 1300 527 665 STEP 04 STEP 05 Step 4: Please put the plastic spacer in between the clamp brackets. Hint: Echo screen use 1x thick & 1x thin plastic spacer.
