- Page 1 USER MANUAL 62xx/72xx Terminals MARITIME: COMMUNICATION SYSTEMS...
- Page 2 List of abbreviations and definitions The following symbols are used to describe the operating instructions: System and/or station status The user actions • Activity in the system or station CONFIG: This symbol indicates that the functionality is dependant of the configuration settings and refers to the Phontech 6200 configuration description.
- Page 3 Amendment Record INIT DATE CHAPTERS VERSION REASON FOR CHANGE Initial release Page iv Revision A...
- Page 4 The information in this book has been carefully checked and is believed to be accurate. However, no responsibility is assumed for inaccuracies. Zenitel AS reserves the right to make changes without further notice to any products or modules described herein to improve reliability, function or design. Zenitel AS does not assume any liability arising out of the application or use of the described product.
-
Page 5: Table Of Contents
TABLE OF CONTENTS SYSTEM OVERVIEW ........................1 SYSTEM INFORMATION TONES: ................... 2 CONFIGURATION DEPENDANT FUNCTIONALITY: ............3 FLEXIBLE NUMBERING PLAN: ..................3 CALL GROUP: ......................... 3 CALL HUNTING GROUP: ...................... 3 PAGING GROUP: ........................3 ALERT GROUP: ........................3 INTRUSION: ..........................4 CONFERENCE: (CONFIG) ..................... -
Page 6: System Overview
1. SYSTEM OVERVIEW The Phontech 6200 Integrated Communication System is a digital communication system meeting all aspects of internal and external communication, information exchange onboard vessels, offshore installations and to/from onshore operation centers. Based on the latest computer technology, it´s flexible configuration is a cost effective solution for Intercom, Telephone, Public Address, Alarm, Loudhailing and Entertainment. -
Page 7: System Information Tones
2. SYSTEM INFORMATION TONES: The system will use some different information tones in different situations: Tone name: Graphic: Tone description: Purpose: Dial tone 425Hz: Continuous Ready to receive dialling 425Hz: Call tone Calling other extension 1sec. ON - 4sec. OFF 425Hz: Busy tone The called extension is busy... -
Page 8: Configuration Dependant Functionality
3. CONFIGURATION DEPENDANT FUNCTIONALITY: 2.1 FLEXIBLE NUMBERING PLAN: The system can have numbers ranging from 1 to 36 digits, 0-9 (CONFIG). The length of numbers can be mixed freely, but overlapping numbers (143 and 1435) will introduce a short delay on accepting the shorter number. -
Page 9: Intrusion
2.6 INTRUSION: This function must be enabled as a part of “Service Classes” (CONFIG). It will override busy subscribers and subscribers with PRIVACY enabled. 2.7 CONFERENCE: (CONFIG) The conference function uses “MeetMe” rooms. When enabled, a globally configured extension is the entry point to the conference rooms, where the user is asked to select a specific conference room. -
Page 10: Special Functions Overview
4. SPECIAL FUNCTIONS OVERVIEW: Special functions are available from intercom terminals. The following list is an overview of the special functions. Entry Name Description Code *080 Who am I / Identification The system outputs the extension *21* Call forwarding Forwards all incoming calls to the requested extension number Wake-up call Performs a Wake-up Call at the requested time. -
Page 11: Basic Operation
5. BASIC OPERATION: 4.1 PLACE A CALL: Using the handset: Idle Unhook the handset • Dial tone Dial the extension number (on 72xx press to skip timeout) • Call tone • ……Conversation Replace the handset In general, when this document says to “Unhook the handset” you can alternatively use the speakerphone mode by pushing the Speaker key. -
Page 12: Intrusion: (Config)
• Confirmation tone Replace the handset Note: While the extension is forwarded it is still possible to make calls To clear call forwarding: Idle Unhook the handset • Dial tone Dial [#21] • Confirmation tone Replace the handset 4.4 INTRUSION: (CONFIG) The called party is busy in another call: Busy... -
Page 13: Wake Up Call
4.6 WAKE UP CALL: The wake up call is automatically executed by the system at the requested time. The telephone unit will ring normally until the call is answered (Off hook), or for 3 minutes before automatically being turned off. •... -
Page 14: Intercom Unit Facilities
6. INTERCOM UNIT FACILITIES : 5.1 ONE-BUTTON INTERCOM: This functionality is dependant of having configured the one-button intercom memories (A, B or C) in the configuration (CONFIG). Idle Dial (KEEP HOLDING FOR PTT MODE) • Extension dialled responds differently according to type: Paging group: Normal page. -
Page 15: Loudspeaker Volume Control
6.4 LOUDSPEAKER VOLUME CONTROL: The loudspeaker volume control has 10 steps independent of other volume settings. The default volume setting is preset to any of the 10 levels in the configuration (CONFIG). Minimum level is adapted to meet the requirement of a quiet cabin or office environment. ……Loudspeaking conversation (using integrated microphone and internal / external loudspeaker) Rotate menu wheel clockwise to increase ringer volume and counter clockwise to decrease... -
Page 16: Display Contrast Control
6.8 DISPLAY CONTRAST CONTROL: The display has 10 contrast levels. The selected level is maintained through next change or restart/power up. Idle Press the Menu wheel to enter menu. Scroll down to Settings and Contrast Rotate Menu wheel clockwise to increase contrast and counter clockwise to decrease contrast. Contrast is stored after menu wheel is released. - Page 17 Zenitel and its subsidiaries assume no responsibility for any errors that may appear in this publication, or for damages arising from the information therein. Phontech products are developed and marketed by Zenitel. The company’s Quality Assurance System is certified to meet the requirements in NS-EN ISO 9001. Zenitel reserves the right to modify designs and alter specifications without notice. ZENITEL PROPRIETARY. This document and its supplementing elements, contain Zenitel or third party information which is proprietary and confidential.
