Installation and
User Guide
IMPORTANT
• Please read this manual carefully and
thoroughly before installing and
operating your Vigil
• Please retain this manual for future
reference after reading it thoroughly
www.solutionscentre.net.au
info@solutionscentre.net.au
thermo
remote
basic
Advertisement
Table of Contents
Summary of Contents for Solutions Centre vigil geo
- Page 1 Web: www.solutionscentre.net.au E:mail: info@solutionscentre.net.au vigil geo+ thermo remote basic Installation and User Guide IMPORTANT • Please read this manual carefully and thoroughly before installing and operating your Vigil • Please retain this manual for future reference after reading it thoroughly...
-
Page 2: Table Of Contents
Tamper Switch..........................12 Make the connections ........................12 Ignition Kill ............................12 Electronic Bilge level sensing......................13 VIGIL GEO – TYPICAL BOAT WIRING SUGGESTIONS ................14 OUTPUT RELAY CONNECTION ALTERNATIVE ................... 15 WIRING ASSIGNMENTS ..........................16 QUESTIONS and TROUBLESHOOTING ....................... 19... -
Page 3: Introduction
This manual provides you with installation and operating guidelines for the Vigil Geo, Geo+, Thermo and Remote. Since the Vigil range of products is so versatile, it is impossible to provide you with instructions applicable to every application in a single document. -
Page 4: Loading Sim Card
LOADING SIM CARD CAUTION: Before loading your SIM Card, ensure that the SIM Card you are using does NOT require a PIN Number (most Telstra SIM Cards are supplied with a PIN Number required each time you start the mobile device). If the SIM Card requires a PIN Number you will need to insert the SIM Card into another mobile phone and turn off this requirement before it will work on Vigil. -
Page 5: Turn Vigil On
TURN VIGIL ON If you have not already done so insert the SIM Card using the instructions noted above. To activate the unit, take the small white plug from standby battery and slide it into the power socket as shown in FIG 4. This only goes in one way. Do NOT force. When you do this you may note the small LEDs on the circuit board start flashing. -
Page 6: List Registered Phones
NB This will cause Vigil to send itself an occasional SMS to update the time. Depending on your chosen mobile phone plan you may be charged for these SMS messages. Once entered this number cannot be removed. If you don’t add the Device Phone number, Vigil will still work, but the TIME will only be updated from the network when an SMS message transfer occurs. -
Page 7: Changing The Geofence Radius
2. If the GPS receiver is already on and tracking satellites then the message your unit sends will show ‘(NEW)’ for the fix. If it is not warmed up, or it cannot determine its location because it cannot get a GPS fix, it will send a report showing '(OLD)', while it continues searching the sky for satellites and a NEW fix. -
Page 8: Expanded Command Set
When your Vigil unit sends a position Fix, it delivers the Course (co) in degrees (True); Speed (Sp) in knots (default or configurable to miles or kilometres) and lastly a hyperlink to Google Map that contains the Latitude and Longitude in a degrees and decimal degrees. Cursor your internet enabled smart phone browser over the hyperlink and click to see the current position displayed on Google Map. -
Page 9: I/O Contact Switches
I/O contact Switches EnOE Enables unit to send an alert when the nominated switch changes to Open – where n is the switch number, e.g. Switch 1 OPEN Enable is E1OE EnCE Enables unit to send an alert when the nominated switch changes to Close –... -
Page 10: Fast Access Commands
REL2ON Setup command: Relay 1 can be turned both ON or OFF REL2OFF SetupCommand: Relay Turns OFF and remains OFF regardless of F6E SIREN This is a setup command that ARMS Siren relay connection but does NOT activate relay. Issues a REL2ON. -
Page 11: Report
GPSD Disable GPS receiver Acquire immediate fix ( = GPSA) Report REP<>nnn.d//opcode,opcode,opcode.. Where nnn.d is the time between reports in hours and 1/10 hour. e.g. REP 20//INFO,RCOUNT, TEMPRESET. Max 30 chars. Note commas. Set nnn.d = Zero to disable (i.e. REP 0). SETSERVICEDUE<>ddmmyy//nn where ddmmyy is due date and nn = days before date to alert. -
Page 12: Basic Installation
BASIC INSTALLATION A. Determine mounting location. This is an important step that requires careful forethought in order to get the best results out of your unit. B. Considerations The following instructions describe issues to consider when installing the device in a boat. The same principles need to be considered when installing the unit in any other environment. -
Page 13: Tamper Switch
3 Engine, Kill isolation, so turning one off at the key-switch, does not kill the others. Connect the ORANGE VIGIL GEO wire to the Diode common terminal. Each diode goes to a separate engine Kill wire. Use any of... -
Page 14: Electronic Bilge Level Sensing
Seek advice and then confirm by running engine and grounding wire before connecting to VIGIL GEO. If you are using VIGIL GEO on an outboard engine marine installation, please make sure that the link is inserted at Jumper link J2. The J2 link connects the KILL relay (RL1) to ground, providing the ignition ground that KILLs the outboard ignition. -
Page 15: Vigil Geo - Typical Boat Wiring Suggestions
VIGIL GEO – TYPICAL BOAT WIRING SUGGESTIONS... -
Page 16: Output Relay Connection Alternative
OUTPUT RELAY CONNECTION ALTERNATIVE Depending on the model Vigil you are using, the output relays have provision for Normally Open, and Normally Closed connections. Instead of finding and connecting to the relay common to create a positively switched output, it is often easier and more convenient to convert the relays to negative switching. -
Page 17: Wiring Assignments
WIRING ASSIGNMENTS Each Vigil model has slightly different wiring assignments. Please ensure you identify the wiring assignments applicable to your model from the following diagrams. Please note that only 7 wires are typically exposed at the end of the cable. To access the remaining wires carefully remove the heat shrink at the end of the cable. -
Page 20: Questions And Troubleshooting
Only activate remote engine kill when you have the vessel in sight and it is safe to do so. Solutions Centre and Vigil Marine also accept no liability for the use or misuse of its products under any circumstances, including GSM network, GPS services, or device failure, for whatever reason.
