Hypno
Hypno is an "all-in-one" semi-modular video
generator. The panel is organized into mirrored
sides for 2 shapes A&B. The centered controls
are global. Hypno outputs video with a compos-
ite jack, HDMI or NDI.
Polarization
Rotation
Shape A
Sine
Tangent
Square
Circle
Fractal Noise
Frequency
Video Out 1
Composite output. PAL or NTSC
switchable via firmware
update. Defaults to this output
unless an HDMI Connection is
detected on power-up.
Case Module-Lock
The enclosure features module
locking tabs. Pull and flex out a
side of the case at the point
indicated with the lock icon below
to pull Hypno out of the enclosure.
Hypno
sleepy
CV Control (-5V to 5V)
Knobs are connected with a line
to their corresponding modulation
jack. Subtle smoothing is applied
to inputs by default.
Epilespy Warning!
Hypno's video output may
trigger seizures in
individuals with
photosensitive epilepsy.
USB
Stream to a Computer via NDI
MIDI Host Capable
UVC compliant Video Input
Easy Updates for New Firmware
Feedback
Regular
hyper_digital
Edgy
Stable Glitch
Inverted Stable
Gain
Master value of both
shapes A&B. Bi-Polar
control with blackness
at 12 o'clock.
Hue
Color selection
shifts color
relationship for
both shapes A&B
at once.
Shape Trig Inputs
Triggers on underlined jacks
step through the shapes of
the corresponding
oscillator.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Hypno and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sleepy Circuits Hypno

  • Page 1 The panel is organized into mirrored Hypno’s video output may sides for 2 shapes A&B. The centered controls trigger seizures in are global. Hypno outputs video with a compos- individuals with photosensitive epilepsy. ite jack, HDMI or NDI. Polarization...
  • Page 2 Shape Pages Holding one of the side buttons on Hypno enters the UI into an alternate state, allowing more detailed control of the Shapes. Hypno Fractal Amount Polar/Fractal Mod Modulates the polarization or Fractals/Mirrors the shape in Fractal Axis if Fractal is active.
  • Page 3 Gain sliders control connection magnitude. Preset System Each of Hypno’s buttons represent a preset slot. Holding 2 buttons lets you access the slot on the 3rd button. Presets save the state of all of Hypno’s controls in all of the pages.
  • Page 4 After a short delay, you will see Shape A light up in tion controls) a new color. Now you have a video feed! Note: Video input into Hypno has a slight delay. Give the lil guy a break, it’s doing a lot!!! Y Crop Preforms a center relative crop of the input on the Y axis.
