TIS MET-EN-1PH Installation Manual

INSTALLATION MANUAL
TIS ENERGY METER 1 PHASE
Model: MET-EN-1PH
Specifications
Protection
Display
Dimensions
Housing
BARCODE (UPC-A)
6 58921 79907 9
This module is a single-phase power meter that
calculates how much KW/H is consumed in your
location. Other electricity parameters, such as
current amps, voltage, and active power, are also
measured. It also shows electricity expenses
based on this data.
P R O D U C T S P E C I F I C AT I O N S
Voltage AC (Un)
Base Current (Ib)
Max. Current (Imax)
Mini Current (Imin)
Power consumption
Frequency
Short Output Protection
LCD
Max. Reading
Length × Width × Height
Materials
Casing color
IP rating
Automation Made Easy
PRODUCT INFORMATION
176-276V / 80-140V (optional)
10 A
100 A
0.5 A
<2W/10VA
50/60Hz(±10%)
Output will turn off in case of short connection
LCD with blue backlit
99999.99kWh
46mm × 62mm × 90mm
Self-extinguishing UL94V-0
Black
IP 51 indoor
