IP-ACM Ethernet Door Module
The IP-ACM module provides connection and management of the access control for two doors through inputs, outputs,
and reader interfaces. Supporting two readers through Power over Ethernet (PoE), the IP-ACM communicates to the
Ultra General Control Module (GCM) over TCP/IP. The IP-ACM module also has AES256 network encryption from the
unit to the GCM. The encryption settings are determined by the GCM configuration. The maximum number of IP-ACM
modules supported per GCM is 32.
Installation Requirements
Ensure the site is ready:
■ The module installation must be performed by a certified installer and must be installed within the same protected
premise as the controlling GCM.
■ For a UL-compliant installation, the power supply must be UL Listed to UL 294 and/or UL 603, low voltage Class 2
power limited with appropriate ratings.
■ All interconnecting devices must be UL Listed, low voltage Class 2 power limited.
■ The site must be approved and all wiring must comply with UL requirements and other codes, as appropriate.
Installation shall be in accordance with the National Electric Code, ANSI/NFPA 70-1993.
■ In this installation, the enclosure is mounted directly to a wall or uni-strut using suitable user-supplied hardware.
■ The anchoring system must be capable of sustaining, a proof load four times that of the assembly. Refer to the
enclosure dimensions for information on the weight of enclosures. This weight does not include the cables.
1
Not UL listed.
2
Not UL listed.
Part Number
IP-ACM2-MB
IP-ACM, 2 Reader, board only
IP-ACM2-EM
IP-ACM, 2 Reader in metal enclosure
1
IP-ACM2-EP
IP-ACM, 2 Reader in plastic enclosure
IP-ACM2-CAN
IP-ACM metal enclosure without board
2
IP-ACM2-CAN-P
IP-ACM plastic enclosure without board
Table 1: Part numbers and descriptions of IP-ACM and enclosures
IP-ACM Ethernet Door Module
Description
Quick Start Guide
VERSION C0
PART NUMBER 8200-1200-02
MARCH 2016
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Tyco Security Products Software House IP-ACM
- Page 1 IP-ACM Ethernet Door Module Quick Start Guide VERSION C0 PART NUMBER 8200-1200-02 MARCH 2016 IP-ACM Ethernet Door Module The IP-ACM module provides connection and management of the access control for two doors through inputs, outputs, and reader interfaces. Supporting two readers through Power over Ethernet (PoE), the IP-ACM communicates to the Ultra General Control Module (GCM) over TCP/IP.
- Page 2 IP-ACM Ethernet Door Module Quick Start Guide ■ The cables are protected by using metal or plastic conduit, or using flexible cable grip strain relief. ■ The module can be powered from either a 12V or 24V local source, PoE or PoE plus. ■...
-
Page 3: Plastic Enclosure
IP-ACM Ethernet Door Module Quick Start Guide Data processing equipment and office appliance and business equipment used as computer equipment NOTE shall comply with the Standard for Information Technology Equipment - Safety - Part 1: General Requirements, UL 60950-1. ■ The installation shall supply line transient protection complying with the Standard for Transient Voltage Surge Suppressors, UL 1449, with a maximum marked rating of 330 V. -
Page 4: Metal Enclosure
IP-ACM Ethernet Door Module Quick Start Guide IP-ACM and Reader Plastic Enclosure Dimensions Item Dimension Weight 2.2lb (1kg) Height 12.1in (307mm) Width 7.2in (183mm) Depth 2.46in (62.4mm) Table 2: Plastic enclosure dimensions Installing the Plastic Enclosure and the IP-ACM Module To install the IP-ACM module and plastic enclosure, use the following steps: 1. -
Page 5: Grounding Requirements
IP-ACM Ethernet Door Module Quick Start Guide IP-ACM and Reader Metal Enclosure Dimensions Item Dimension Weight ~2.6lb (~1.2kg) Height 8.25in (209.6mm) Width 7.34in (186.5mm) Depth 3.46in (87.8mm) Table 3: Metal enclosure dimensions Installing the Metal IP-ACM Enclosure and Module To install the IP-ACM module and metal enclosure, use the following steps: 1. - Page 6 IP-ACM Ethernet Door Module Quick Start Guide IP-ACM Power and Wiring Requirements The table below describes the power and wiring requirements for the IP-ACM. Signal Power Requirements Shield Maximum Length RS-485 Comm, Data RM & I/O modules 4000ft (1212m) Full duplex 4 wire RS-485 Power RM &...
-
Page 7: Environmental Requirements
IP-ACM Ethernet Door Module Quick Start Guide Supervision Wiring Figure 3: Supervised wiring This method reports: ■ Short ■ Alert: 500 ohms ■ Normal: 1K ■ Alert: 2K ■ Open: >30K ■ Line Fault: Any unexpected value usually due to wrong value or fault resistors For more information regarding other inputs available and details of configuration, refer to the I/8-CSI User Guide. -
Page 8: Standalone Configuration Mode
IP-ACM Ethernet Door Module Quick Start Guide 5. Ensure you have previously configured the iSTAR Ultra controller in order to obtain the iSTAR IP address for the IP-ACM configuration. 6. To discover the IP-ACM, click the IP-ACM icon in the ICU. A list of IP-ACM modules appear. 7. -
Page 9: Switches And Jumpers
IP-ACM Ethernet Door Module Quick Start Guide Figure 4: IP-ACM board Switches and Jumpers Refer to Figure 4 for switches and jumpers on the IP-ACM module. SW1-2, SW1-3, and SW1-4 are not used and must in the OFF position. NOTE SW1-1 is for standalone configuration. In normal operation mode, SW1-1 must be in the OFF position. Refer to Initial Configuration section for details. - Page 10 IP-ACM Ethernet Door Module Quick Start Guide Figure 5: Wiegand wiring for the IP-ACM Inputs Refer to Figure 4 for the four supervised inputs (P11 to P14) of the IP-ACM. Use standard Software House 1K dual EOL configuration. Further configurations may be selected through the IP-ACM editor in C•CURE 9000. Readers and Accessory Modules The following readers and accessory modules are UL supported: ...
- Page 11 The trademarks, logos, and service marks displayed on this document are registered in the United States [or other countries]. Any misuse of the trademarks is strictly prohibited and Tyco Security Products will aggressively enforce its intellectual property rights to the fullest extent of the law, including pursuit of criminal prosecution wherever necessary.
