Summary of Contents for AV Pro Edge AC-DANTE-D
- Page 1 AC-DANTE-D User Manual 2-Channel Analog Audio Output DANTE™ Decoder...
-
Page 2: Table Of Contents
Contents Contents ......................................2 Important Safety Instructions ..............................3 Safety Classifications in this Document ..........................3 Electrical Shock Prevention ..............................3 Weight Injury Prevention ................................. 3 Safety Statements ..................................4 Introduction ....................................5 Features ..................................... 5 Key Benefits ....................................5 Product Overview .................................. -
Page 3: Important Safety Instructions
Important Safety Instructions Before installing, configuring, and operating the devices and other vendor equipment, AVPro Edge strongly recommends that each dealer, integrator, installer, and all other necessary personnel access and read all the required technical documentation, which can be located by visiting AVProEdge.com. Read and understand all safety instructions, cautions, and warnings in this document and the labels on the equipment. -
Page 4: Safety Statements
Safety Statements Follow all of the safety instructions listed below and apply them accordingly. Additional safety information will be included where applicable. Read and keep these instructions. Heed and follow all warnings. Clean devices and equipment only with a dry cloth. Do not use the devices near water or expose them to rain and moisture. -
Page 5: Introduction
44.1kHz up to 96kHz, in 16-, 24-, or 32-bit word lengths. When powered up and connected to a Dante™ network, the AC-DANTE-D is automatically discovered on the network and ready to retrieve digital audio from Dante™ devices, including the AC-DANTE-E encoder, using the Dante™ Controller software. -
Page 6: Product Overview
Product Overview Box Contents (1x) AC-DANTE-D (Unit) (1x) 5V 1A USB Power Adapter (1x) USB-A to USB-C Cable (1x) 5-Pin Terminal Block (2x) Mounting Brackets (4x) Mounting Screws Technical Specifications Audio Frequency Response 20-20kHz Analog Output Voltage Balanced or Unbalanced 1V (2.828V... -
Page 7: Front And Rear Panels
Illuminates solid red when Dante™ audio stream is muted • Green LED status indicator light Power • Illuminates solid green when power is present on the AC-DANTE-D • 8-pin RJ-45 female connector port • Dante Decoded Dante™ digital audio output port •... -
Page 8: Installation
Installation Once the AC-DANTE-D is powered on and connected to the network switch, it will automatically be discovered on the network using the Dante Controller software. Connecting the Devices Connect the provided USB-A to USB-C cable between the 5V 1A power supply and the AC-DANTE-D decoder’s DC/5V port. -
Page 9: Dante Port Wiring
– Link/Activity Left LED (Green) Indicates there is an active link between the AC-DANTE-D and the receiving end. Solid green indicates the AC- DANTE-D and the receiving end device have been identified and are communicating with one another. If either LED is not illuminating, check the following: Ensure the AC-DANTE-D is powered on from the DC/5V port. -
Page 10: Audio Output Wiring
Audio Output Wiring The audio output port on the AC-DANTE-D outputs 2-channel balanced audio, ideal for 2-channel systems and zoned audio systems (does not downmix). This balanced analog output can be used in a balanced audio system, but can also be converted to a traditional 2-channel unbalanced (L/R) audio output by preparing a cable as shown below. -
Page 11: Device Configuration
Device Configuration Configuring the AC-DANTE-D requires installing Audinate’s Dante Controller software on a computer connected to the Dante network. Dante Controller is a powerful tool used to configure network settings, signal latency, audio encoding parameters, Dante flow subscriptions, and AES67 audio support. The latest version of Dante Controller... -
Page 12: Changing Device Name And Encoding Configuration
Changing Device Name and Encoding Configuration To configure the AC-DANTE-D audio stream, open the Device View by double clicking the Device Name for the AC-DANTE-D and navigate to the Device Config Tab. • Device Name for the AC-DANTE-D • Device Name... -
Page 13: Aes67 Audio Stream Configuration
AES67 Audio Stream Configuration The AC-DANTE-D supports multicast reception of AES67 encoded audio to compatible non-Dante devices. AES67 multicast reception can be configured by opening the Device View by double-clicking the AC-DANTE-D Device Name and navigating to the AES67 Config tab. -
Page 14: Troubleshooting
Troubleshooting • Verify Power – Check that the power supply is properly connected and is outputting 5V. • Verify Connections – Check that all cables are properly connected and/or terminated where applicable. • Verify Source Device – Ensure the source device is powered on and all mute settings are disabled. Maintenance To ensure reliable operation of these devices as well as protecting the safety of any person using or handling these devices while powered, observe the following instructions:... -
Page 15: Warranty
Warranty The Basics AVPro Edge warranties products it manufactures and sells when purchased directly from AVPro Edge or from an authorized AVPro Edge reseller. Products are guaranteed to be free from manufacturing defects and in sound physical and electronic condition when shipped by AVPro Edge. AVPro Edge has developed a warranty everyone can get behind. -
Page 16: Obtaining An Rma
Obtaining an RMA Dealers, resellers, and installers can request an RMA (Returned Merchandise Authorization) from an AVPro Edge Technical Support rep or Sales Engineer. Or you may email support@avproedge.com or fill out the general contact form at www.avproedge.com/contact. End users may not request an RMA directly from AVPro Edge and will be referred back to the dealer, reseller, or installer.
