Alpha Motors WSERD30B Manual

1. TECHNICAL SPECIFICATIONS
Protection index: IP20
Up to 15 remotes can be assigned
to each motor.
2. CHARGING AND WAKING UP
!
Please charge the motor using charger 16.8V/1A before operation.
The motor won't function until it has been charged.
Waking the motor up for the first time:
Method A
Plug ALDC charger into charging port
for a few seconds till motor vibrates.
Method B
Press and hold white motor head button for
6 seconds, green LED will flash 3 times and then turn red.
3. CODE LEARNING
Press the button on the head for
1 second, the motor will vibrate.
4. CHANGING THE RUNNING DIRECTION
Method A.
Press motorhead's button for about 5 seconds until the motor vibrates.
Method B.
Press UP and DOWN buttons
simultaneously.
5. TURN ON STEP BY STEP FUNCTION
Note: If the motor is in step-by-step mode, pressing the UP or DOWN button for 3s will make the motor will run continuously.
Press UP and DOWN buttons
simultaneously.
WSERD30B MOTOR GUIDE p1
ALPHA SUPPORT PHONE (02) 4355 4775
Received frequency: 433.92MHz
Charging: 16.8V/1A
M OTOR
Press UP and DOWN
together and release.
Long press for 5 seconds
Press the STOP button
6 times within 10s.
The motor will move in small increments unless the button is held down.
Press the STOP button
2 times within 10s.
Charging port
Press the STOP button once,
the motor will vibrate.
Press the DOWN button once
within 10s, the motor will vibrate.
Press the UP button once within
10s, the motor will vibrate.
Code: Rolling
Charge time: 6 hours
Programming button
The remote should now
control the motor.
The motor's running direction is reversed.
The motor's running direction
is reversed.
The motor will run
step by step.
