Table 18 - 8900 Alternate Connector Pinouts/Config. 4 - NorthStar 8700 Technical Reference Manual

Pin # Description
1 BDM control input 2A (RS-422)
2 Ground
3 BDM monitor input 1B (RS-422)
4 BDM SC-104 output 2B (RS-422)
5 BDM monitor output 1A (RS-422)
6 GPS primary output 1 (RS-232)
7 GPS primary input 1 (RS-232)
8 Ground
9 GPS auxiliary output 3 (RS-232)
10 Not used
11 Configuration pin B (leave OPEN)
12 Remote POWER ON control
13 (-) DC power input (Ground
05/01/97 REV H
Choose either RS-422 or RS-232 pins as required by the host device. You
may use other pins if complex installations require additional inputs or
outputs.
Echo port: An exact copy of the noted inputs.
•
GPS primary output: NMEA-format output data from the GPS sensor.
•
See Section 10.2, "GPS Serial Protocol," and Section 10.2.2, "Output
Sentences."
GPS auxiliary output: Status messages as described in Section 8,
•
"Input/Output Configurations."
GPS primary input: Optional NMEA-format commands. See Section
•
10.2, "GPS Serial Protocol," and Section 10.2.1, "Input Sentences."
GPS auxiliary input: DGPS corrections to the GPS sensor. See Section
•
10.2, "GPS Serial Protocol," and Section 10.2.1, "Input Sentences."
Time mark: 1 Hz timing pulse available during navigation mode.
•
Table 18: 8900 alternate connector pinouts/config. 4
Pin # Description
14 BDM control input 2B (RS-422)
15 BDM monitor input 1A (RS-422
16 BDM SC-104 output 2A (RS-422)
17 Ground
18 BDM monitor output 1B (RS-422)
19 Ground
20 Time mark output 2 (RS-232)
21 BDM control input 1 (RS-232)
22 Not used
23 Configuration pin A (leave OPEN)
24 Configuration pin C (leave OPEN)
25 (+) DC power input
—
Section 9 - Connector pinouts
—
