Section 9 - Connector pinouts
Pin # Description
7 GPS primary input 1 (RS-232)
8 Ground
9 BDM monitor output 3 (RS-232)
10 BDM monitor input 3 (RS-232)
11 Configuration pin B (leave OPEN)
12 Remote POWER ON control
13 (-) DC power input (Ground
9.1.5 Alternate
connector pinouts
for the 8900
Pin # Description
1 GPS auxiliary input 2A (RS-422)
2 Ground
3 GPS primary input 1B (RS-422)
4 Output 2B (Echo of input 1 - pins 7 or
15 & 3) (RS-422)
5 GPS primary output 1A (RS-422)
6 GPS primary output 1 (RS-232)
7 GPS primary input 1 (RS-232)
8 Ground
9 BDM monitor output 3 (RS-232)
10 BDM monitor input 3 (RS-232)
11 Configuration pin B (leave OPEN)
12 Remote POWER ON control
13 (-) DC power input (Ground)
PAGE 40
An alternate configuration for the 8900 lets the BDM and GPS receivers
operate independently, whereby the GPS receiver accepts differential cor-
rections from an external device rather than the internal BDM receiver.
This is configuration 6: For this configuration, pin 23 is grounded and
pins 11 and 24 are left open. Pin connections for configuration 6 are
described below in Table 17 (functions highlighted in bold indicate the
suggested pins for a normal installation, and are the minimum connec-
tions required for operation of the 8900):
Table 17: 8900 alternate connector pinouts/config. 6
Input signals may be connected to any appropriately labeled input pin;
output signals may be taken from any appropriately labeled output pin.
Pin # Description
20 BDM SC104 output (RS-232)
21 BDM control input 2 (RS-232)
22 Not used
23 Configuration pin A (leave OPEN)
24 Configuration pin C (leave OPEN)
25 (+) DC power input
—
Pin # Description
14 GPS auxiliary input 2B (RS-422)
15 GPS primary input 1A (RS-422)
16 Output 2A (Echo of input 1 - pins 7 or
15 & 3) (RS-422)
17 Ground
18 GPS primary output 1B (RS-422)
19 Ground
20 BDM SC-104 output 2 (RS-232)
21 GPS auxiliary input 2 (RS-232)
22 Not used
23 Configuration pin A (to GROUND)
24 Configuration pin C (leave OPEN)
25 (+) DC power input
—
—
—
05/01/97 REV H
