Pin # I/O port
6 RS-232 output 1
20 RS-232 output 2
9 RS-232 output 3
5,18 RS-422 output 1
16,4 RS-422 output 2
7 or 15 & 3 RS-232 input 1 or RS-422 input 1
21 or 1 & 14 RS-232 input 2 or RS-422 input 2
10 RS-232 input 3
Pin # I/O port
6 RS-232 output 1
20 RS-232 output 2
9 RS-232 output 3
5,18 RS-422 output 1
16,4 RS-422 output 2
7 or 15 & 3 RS-232 input 1 or RS-422 input 1
21 or 1 & 14 RS-232 input 2 or RS-422 input 2
10 RS-232 input 3
05/01/97 REV H
sensor (for pinouts, see Table 16 on page 39). Configuration 6 is similar,
except that the GPS sensor takes the SC-104 corrections from port 2,
either RS-232 or RS-422 (for pinouts, see Table 17 on page 40).
You can easily switch between internal BDM and
external SC-104 operation simply by opening or
grounding pin 23 on the connector.
Configuration 5 (for pinouts, see Table 15 on page 38) is used with the
Northstar 8800, which only contains a BDM. Inputs and outputs from
both BDM ports are available in RS-232 and RS-422 signal levels.
Section 8 - Input/output configurations
NOTE:
Table 8: Configuration 7
Sensor signal
GPS primary output
BDM SC-104 output
BDM monitor output
GPS primary output
Echo of RS-232 input 1 or RS-422 input 1
GPS primary input
BDM control input
BDM monitor input
Table 9: Configuration 6
Sensor signal
GPS primary output
BDM SC-104 output
BDM monitor output
GPS primary output
Echo of RS-232 input 1 or RS-422 input 1
GPS primary input
GPS auxiliary input
BDM monitor input
PAGE 31
