Summary of Contents for Yes We Scan CPK-S100
- Page 1 Mobile Ref : YWS08 Note Taker SCAN Final Mode d'emploi YWS08NetBEng1 1 05/05/2010 14:24:27...
- Page 2 Final Mode d'emploi YWS08NetBEng2 2 05/05/2010 14:24:28...
-
Page 3: Table Of Contents
Welcome Contents Page Contents ---------------------------------------------------------------1 Introduction ----------------------------------------------------------2 Features ---------------------------------------------------------------2 About the digital pen ----------------------------------------------2 Installing/replacing an ink refill -------------------------------3 Installing/replacing the pen battery -------------------------3 About the base unit ------------------------------------------------4 Button description -------------------------------------------------4 Resetting the base unit -------------------------------------------4 LCD indicator --------------------------------------------------------5 Charging the battery ----------------------------------------------5 Mounting the base unit to paper ------------------------------5 Taking handwritten notes ---------------------------------------6... -
Page 4: Introduction
Introduction Congratulations on purchasing the CPK-S100 Mobile Note Taker. Please read this instruction manual to learn about the features and functions of this unit. Features Capture natural handwritings and drawings while being away from computer. Save captured handwritten notes into built-in flash memory. -
Page 5: Installing/Replacing An Ink Refill
Installing/replacing an ink refill The top of the pen cap also functions as an ink refill extractor. No special ink refill is needed. Just use a standard off-the-shell ink refill. NOTE . Make sure you use a refill that is similar to the original. . -
Page 6: About The Base Unit
. This warning is continuously displayed on each new note and the appli- cation icon in the system tray changes to reflect the current status until the batteries are replaced. . Lifetime of the batteries may vary and cannot be guaranteed. Supplied batteries are good for initial use only. -
Page 7: Lcd Indicator
LCD indicator Name On when Off When Blinks When Mobile Note Taker Unit is connected to Unit is NOT Data is uploaded is Connected connected to PC to PC Mobile Note Taker Less than 90% Never memory is 90% full. capacity used Memory FULL Pen Low Battery... -
Page 8: Taking Handwritten Notes
C. Mounting the base unit at the top right corner of a paper block is recommended for left hand users: You can upload notes from the base unit to a computer, work in On-line mode and upgrade firmware by connecting the device to a computer. Use the included USB cable to connect the device to a computer. -
Page 9: Installing Easy Note Taker Software
The digital pen can also acts as a mouse with features like hovering, left and right click. Additionally, there are some special features to be used only with the Online mode. Those features will be described in details in the following chapters. Before you connect the device to a PC, first make sure to install the Note Taker manager application included in the CD and run it. -
Page 10: Operating Mode Of The Digital Pen
NOTE . When you select ‘NO’, the next time you upload, those notes that are already uploaded to the PC will not be uploaded. However, if you delete notes from the PC application and then upload again from the memory unit, the notes will be uploaded again. . -
Page 11: Mouse Mode
NOTE . On each mode change, a Balloon will popup indicating the current mode and the corresponding LED will light. Mouse mode In Mouse mode, your Digital pen behaves as a mouse with the following functionality: . To move your mouse cursor, you can hover with the pen. To start hovering, you can press the side button or tip the pen on the paper. -
Page 12: Using The Mobile Note Taker
When you have finished with your note, use the other toolbar buttons to save your note to a picture file, email, print, or simply save to your Note Manager window for later use. The Note Manager can be used for storing, viewing, searching, copying, exporting and e-mailing notes. -
Page 13: Using Mobile Note Taker In Mac System
3. Open ink comment-(blue pen on yellow mote at the ink toolbar). A bal- loon is opened, on the right hand side. Use it for handwriting comments. In every Office Application there is a Tablet PC input Panel on the left hand side. -
Page 14: Easy Note Taker Preferences Tool
3. The installer advances to the Installation Type stage. In this stage, you confirm that you want to perform a standard installation of the Easy Note Taker software on the hard drive you selected. Click ‘Install’. NOTE . Performing a standard installation will install the software directly into your Applications folder on your Mac’s hard drive. -
Page 15: Mobile Note Taker Operation With Mac
3. Choose where on your Mac you want to save TIFF images by clicking on the relevant location in the left hand column, and then click ‘Open’. The Finder window closes and the new target path is displayed in the Easy Note Taker Preferences dialog. - Page 16 3. While being connected to the Mac via the USB port, the Mobile Note Taker can be used as a Mouse and as a Tablet input device for Mac ink applications. Use the digital pen in applications such as iWork’08. You can write handwritten test, on-line, and the Mac will convert it into text.
-
Page 17: Troubleshooting Guide
Troubleshooting guide Problem Possible Cause Solution The LCD Battery of the base unit Connect the base unit to a displays nothing is too low computer or use the charger to when I power on charge the battery the base unit The battery The charger/USB Reconnect the charger or...
