Summary of Contents for RAIN OR SHINE GOLF HomeBay
- Page 1 HOMEBAY® INSTALLATION GUIDE Questions? Contact Us support@rainorshinegolf.com 1-888-831-9489...
- Page 2 Step #2: L ocate Wall Studs and Make Measurements for Installation Step #3: I nstall Brackets to Wall Step #4: I nstall HomeBay Screen to Brackets Step #5: I nstall Side Nets Step #6: I nstall Ceiling Net & Ceiling Hooks...
- Page 3 ● For your safety, and to make this a smoother setup process, make sure you work with at least one other person. ● Completing full assembly of your HomeBay will take about 1 hour 1 Hour Assembly Time ● Please be sure to follow the instructions laid out in this manual carefully.
- Page 4 HomeBay Parts List (Images not to scale) Bracketing and Hardware Parts List (Extra pieces will be included) Part Specs Quantity Image Top Brackets 18” x 20” Bottom Brackets 18” x 20” Hex Washer Head ¼” Screws Drywall Anchor ¼” Elevator Bolt 2”...
- Page 5 Impact Screen, Netting, and Accessories Parts List Part Specs Quantity Image White Impact Screen 8’ x 10’ Triangular Side Nets 8’ x 10’ SandBags Ceiling Net 10’ x 6’ Ceiling Hooks 3” Ball Bungees 6” Recommended Tools (not included) Studfinder Laser Level...
- Page 6 Step #1: Layout the Pieces of Your Bracketing Kit Layout all pieces of your HomeBay Bracket and Hardware kit. You should have 2 wide brackets for the top of the setup and 2 narrow brackets for the bottom. You will also want to layout all the hardware provided to confirm all pieces were received.
- Page 7 The following diagram indicates where the velcro will need to be positioned. Attach the velcro portion of the side net to the side flap of your HomeBay Impact Screen from top to bottom. The side net should be the same height as the impact screen if properly fastened.
- Page 8 4-5 feet from the screen. You’re all done! Now that you have fully installed your HomeBay, go enjoy the golf simulator of your dreams! If you are in need of any additional assistance, please contact us at 888-831-9489 with extension 1 for our customer service department.
