Designed for your house, a New Living Style.
USER MANUAL
Bar Cart
SKU:
HUSF- CBC3004CRM
Attention:
This instruction contains important safety information, please
carefully read it and keep it for future reference...
No Need to Return ! ! !
If any problems occur, please reach out to us at
646-204-5003 or at Amz@hausfame.com
for further assistance, clear pictures associated with
your problems will contribute to a faster solution...
1
Advertisement
Summary of Contents for Hausfame HUSF-CBC3004CRM
- Page 1 No Need to Return ! ! ! If any problems occur, please reach out to us at 646-204-5003 or at Amz@hausfame.com for further assistance, clear pictures associated with your problems will contribute to a faster solution...
- Page 2 Welcome to visit our store and purchase our quality products! Amazon store please search with Hausfame series cover a vast selection of furniture item spanning Computer Desks， Side Tables, Garment Racks, Cabinets, Chairs, Bar Stools, Sofas, Ottomans, Bookshelves and Living Room Sets, etc, all of which are geared towards addressing various tastes and budgets.
- Page 3 Attention: Extra hardware parts and foot pads are provided for the purpose of possible repair or replacement in the future. In the process of assembly, be sure to keep all small parts in the package out of reach of babies and children, which pose a choking hazard if swallowed or inhaled;...
-
Page 4: Parts List
Parts List Prior to assembly, check to see if all parts and hardware are included as follows, should any part be found missing or defective ,please reach out to our customer service for further assistance. (1)x1pc (2)x1pc (3)x1pc Top frame Bottom Shelf Frame Middle Shelf Frame (4)x3pcs... - Page 5 Assembly Steps Align Tempered Glass (4) to the Top Frame (1), Step 1 Middle Shelf Frame (2), Bottom Shelf Frame (3) with Screws E by using the Allen Wrench A. Bottom Shelf Frame Middle Shelf Frame Top frame EX12PCS Screw M4x4...
- Page 6 Assembly Steps Step 2 Before you begin, please distinguish Top, Middle Shelf and Bottom Shelf. Additional labels (1) (2) (3) already marked on the Each Shelf. Bottom Shelf Frame Middle Shelf Frame Top frame...
- Page 7 Assembly Steps Step 3 Align Top Frame (1), Middle Shelf Frame (2), Bottom Shelf Frame (3) to the Side Frame (5), Secure with Screws D by using the Allen Wrench A. Please Align the Top Frame first, then Middle Shelf Frame and Bottom Shelf Frame.
- Page 8 Assembly Steps Step 4 Align Top Frame (1), Middle Shelf Frame (2), Bottom Shelf Frame (3) to the Another Side Frame (5), Secure with Screws D by using the Allen Wrench A. Top frame Bottome frame Middle frame DX6PCS Screw M6x15...
- Page 9 Assembly Steps Step 5 Attached wheel G and wheel with lock F to the Bottom Shelf Frame (3), Secure with a Wrench B. FX2PC GX2PC...
- Page 10 Assembly Steps Step 6 Attach the handle (6) to the Top Frame (1), then secure with Screws C by using the Allen Wrench A. CX2PCS Screw M6x40...
- Page 11 Assembly Steps Step 7...
-
Page 12: Care And Maintenance
Care and Maintenance It is recommended to wipe off the dust gathering on the bar cart with a soft and clean piece of dry cloth. Do not use solvents of any kind, as they may damage the finish of the item. It is essential to check if any screws/bolts are loosened periodically and then tighten them accordingly. - Page 13 Designed for your house, a New Living Style. CUSTOMER SERVICE Contact Us: 646-204-5003 9:00 am-5:00 pm (Pacific Time) Monday through Friday...
