X11 PRO

Wireless Bone Conduction Sport Headphones

User Manual

Please read the User Manual carefully and follow the guidelines in this manual to assemble

or operate; Design and specifications of the products are subject to change without notice.

For the most up-to-date product information, please contact us.

Need help?

Do you have a question about the X11 PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for JOMISE X11 PRO

Page 1 X11 PRO Wireless Bone Conduction Sport Headphones User Manual Please read the User Manual carefully and follow the guidelines in this manual to assemble or operate; Design and specifications of the products are subject to change without notice. For the most up-to-date product information, please contact us.
Page 2 ON/OFF ◆Power on: Touch and long press the ON/OFF button for 2 seconds until the LED flashes blue 3 times, then red and blue flashes alternately. ◆Power off: Touch and long press the ON/OFF button for 3 seconds until the LED turns red and lights for 1 second and then the light goes off.
Page 3 Pairing 1.Start operation with X11 Pro turned on. 2.Open your device's Bluetooth settings and select "X11 Pro". When you see the headphones LED flashes alternately red and blue, it means the headphones are in pairing mode. 3.When you hear the voice reminding you to "connected" and the blue LED light flashes slowly, it means the pairing is successful.
Page 4 ◆Voice Assistant: Triple-touch in Bluetooth connection ※To protect your hearing, JOMISE will alert you with a "Max Volume" sound when the volume reach the maximum. ※"Hearing Damage": Listening to music at too high a volume may damage your hearing...
Page 5 Wearing ① Wearing Method 1 During use(the correct wearing method is shown in the pictures below) ◆Hold the switch button position of the headphones with your left hand, hold the logo position of the headphones with your right hand, and turn your right hand in the direction of your body from top to bottom to open the headphones.(Please combine the diagram to understand) ◆Separate the headphones and wear them to a suitable position to enjoy the...
Page 6 Wearing ② Wearing Method 2 ◆With the silicone side that touches the ear side facing up, hold the wire corresponding to the left ear with your left hand (the one with the button is the left ear) and the wire corresponding to the right ear with your right hand. ◆Separate the headphones and wear them to a suitable position to enjoy the music.
Page 7 Wearing ③ When not in use: ◆When the wrist contacts the headphones cable, it can be naturally wrapped like a bracelet, which is portable and not easy to fall off. ◆The headphones cable is made of titanium memory wire, which can be freely stretched and folded without deformation.
Page 8 1.Start with X11 Pro turned on. 2.Open your device's Bluetooth settings and select "X11 Pro". Siri will say "connected". ※Play/call cannot be performed on two devices at the same time. You can switch between two devices based on your requirements.
Page 9 LED Indicator Definition ◆Power on: LED Indicator flashes blue 3 times then alternately flash red and blue ◆Power off: LED Indicator turns red for 1 second and goes off ◆In pairing: LED Indicator alternately flash red and blue ◆Successful connection: LED Indicator flashes blue slowly ◆Disconnected: LED Indicator flashes red and blue alternatively ◆Play/Pause: LED Indicator flashes blue slowly ◆Incoming call: LED Indicator flashes blue slowly...
Page 10 Voice Prompt ◆Power on: Power on ◆Power off: Power off ◆In pairing: /(none) ◆Successful connection: Connected ◆Disconnected: Disconnected ◆Volume in Maximum: Max Volume ◆Volume in Minimum: /(none) ◆Ringing tone: / ◆Numbers Reading: / ◆Low Battery Remind: Low battery, please charge ◆Reject Call: /(none) ◆Ring Off: Dong~ ◆Callback：/...
Page 11 Product Specification ◆Product Model：X11 Pro ◆Wearing Method：Hanging Ear ◆Bluetooth Version：V5.3 ◆Bluetooth Protocol：AVRCP V1.6.A2DP V1.3.HFP V1.7 ◆Wireless Range：Approx. 10 meters/33 ft(without barriers) ◆Frequency Range：20Hz-20KHz ◆Speaker impedance：ϕ16MM 6Ω ◆Horn Sensitivity：-83Db±3 ◆Playback Duration: Approx. 6h@80% Volume ◆Call Duration: Approx. 6h@80% Volume ◆Standby Duration: Approx. 80h ◆Charging Time: Less than 2 hours...
Page 12 Manufacturer Declarations ◆Product warranty period is 1 year, man-made damage is not covered by the warranty. Please refer to the terms of the Product Warranty Card for details. ◆Before putting the product into operation. Please observe the respective country specific regulations ◆Please dispose of used batteries properly, observe local regulations, and do not incinerate them.
Page 13 Safety Precautions To guarantee the service life of the product, please refer to the instructions as follows: ◆Please keep away from high temperature, flammable, high humidity, corrosive environments, etc. ◆Do not dissemble the product or subject the product to shock, squeeze and fire. ◆Do not overcharge, otherwise it will affect the service life of the product.
Page 14 FCC Compliance Statement ◆This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 15 FCC Radiation Exposure Statement ◆The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction Name And Content of Harmful Substances in the Product Harmful Substances Part Name Cr(VI) PBBs PBDEs Printed Circuit Board...
Page 16 Common Performance Troubleshooting *Unable to power on --First of all, please make sure the headphones are charged (ios phones and some Android phones can check the remaining power directly through the mobile phone terminal), if the headphones are low or no power, they need to be charged. --If can't turn on the headphones after charging, you can initially determine that the headphones' electronic circuit may have a fault, please contact our company through the Customer Service contact information in this manual and...
Page 17 company through the Customer Service contact information in this manual and communicate the follow-up solution. *Unable to charge --Check if there is power to the charging line (whether the socket switch is off, etc.). --Check if the charging cable is in good condition (you can judge the integrity of the cable by charging other matching appliances instead).
Page 18 Packing List Headphones *1 Charging Cable *1 Earplugs *2 User Manual *1 Please do not use the product if items in the picture above is missing or the product is damaged. Please contact the dealer who sold the product or contact us directly.
Page 19 The headphones you purchased are guaranteed. Please contact us before returning the item. WE WILL HELP YOU RESOLVE ANY ISSUE ASAP. Email: service@jomise.cn WhatsApp: 15003435812 YOUR EXPERIENCE IS OUR FOCUS. Any feedback or suggestions from you are very important to us.
