Summary of Contents for Maruzen MEF-13E
- Page 1 Fryer（Electric） 【Stand regular type １tank-type】 ●ＭＥＦ－１３Ｅ ●ＭＥＦ－１８Ｅ ●ＭＥＦ－２３Ｅ ●ＭＥＦ－２７Ｅ USER’S MANUAL （Product・Installation） General commercial kitchen Appliances & Equipment Maruzen Co.,Ltd.
- Page 2 Contents １ Before Use １－１ Name and function of each part s・・・・・・・・1 １－２ Accessories・・・・・・・・・・・・・・・・・・3 ２ How to Use ２－１ Preparation before use・・・・・・・・・・・・・4 ２－２ Basic usage・・・・・・・・・・・・・・・・・・７ ２－３ How to use Menu Mode Operation・・・・・・・10 ２－４ Other usage・・・・・・・・・・・・・・・・・1１ ２－５ Precautions for use・・・・・・・・・・・・・・1３ ２－6 Draining of oil・・・・・・・・・・・・・・・・13...
- Page 3 Before use １－１ Name and function of each parts Name of each parts ４５０ ４５０ ＭＥＦ－１８Ｅ High limit reset switch ハイリミットリセットスイッチ ハイリミットリセットスイッチ ハイリミット感熱棒 ハイリミット感熱棒 High limit thermos sensitive rod Temperature sensor 温度センサー 温度センサー ヒータ ヒータ Heater 油槽 油槽 Oil tank ４０...
- Page 4 ① Power switch･･････････Power is “ON” or “OFF” whenever you press the power switch. ② Power lamp (Yellow) ･････････Lit when the power is “ON”. ③ Hearting start switch････････････Used to start or stop heating while the power switch is “ON” ④ Heating lamp (Red) ････････ Lit when heating is「ON」.The heating lamp starts blinking over set temperature. ⑤...
- Page 5 使用前に Before Use １－２ Accessories Name of Shape Q’ty How to use Accessory ●Accompanying all models. １ ●Keep carefully in a place to make it available for User’s manual reference at any time. ●Accompanying all models. 型式 製造年月 保 証 書...
- Page 6 ●Accompanying the Fixed type and Tabletop typ e. (ＭＥＦ－１３ＴＥ) （※However, the Fixed Oil cut net fast food type is excluded.) ●Used by putting it on Oil cut plate. Name of Accessory Shape Q’ty How to use Fry basket ●Accompanying the Fixed fast food type. (Fast foods type) ●Accompanying Tabletop fast food type.
- Page 7 How to use ２－１ Preparation before use ・WARNING ●Do not place or use spray cans, or combustible, volatile or inflammable substance near the appliance. ●Turn on ventilation facilities such as exhaust fan while in use. CAUTION ●Do not place any material weak to heat near the appliance. ●Do not touch electrical components such as power plug or operate electric switches with wet hands.
- Page 8 ③ Confirm whether oil drain handle is at the stop position. Drain handle 排油ハンドル 止 開 メ ニュ ー タ イ マー メ ニ ュ ー 設 定 分 秒 電 源 １ ２ ３ 現在 温度 ℃ ４ ５ ６...
- Page 9 How to use ２－２ Basic usage ・WARNING ●Do not place or use spray cans, or combustible, volatile or inflammable substances near the machine. ●In case of abnormality, or earthquake or fire, stop the use and turn the main power (Hand switch・Consent) off.
- Page 10 ③Press the heating start switch. ・Heating lamp (Red) lights and heating starts. ※Once the temperature reached at appropriate temperature, appropriate temperature lamp (Green) is turned on. ④ Once the appropriate temperature lamp (Green) lights, 適 you can start cooking. 温 Put cooked food in to the oil tank.
- Page 11 ④ Once it is the preset time, the buzzer is sounded to notify the completion. Please take cooked food from the oil tank with a scoop net etc. ・The buzzer is sounded 5 seconds before of the preset time. ・Once “End” is displayed on the timer display, press the Start/Stop switch to finish cooking.
- Page 12 How to use ２－３ How to use Menu Mode Operation １）How to register menu ①When the power is “ON”, press the ten key switches to register desired menu number. ・"Menu Number” is displayed on the menu display. ・You can register up to 99 menus. e.g.) The menu number is 10.
- Page 13 How to use ２－４ Other usage ■ＥＣＯ mode ・When the ECO switch is pressed, the mode enters an ECO mode. ・“ECO” is displayed on the timer display panel. ・Under the ECO mode, ECO lamp (Yellow) lights and the oil temperature is maintained at -20℃...
- Page 14 【How to put solid oil into the oil tank】 ※If you put the solid oil in the solidified state, remove the partition net from the heater and never attach the sliding plate and fry basket. フライカゴ Fry basket 仕切網 Partition net Sliding Plate スベリ板...
- Page 15 How to use ５ Precautions for use ２－ ●Do not drain oil when the power is on. ・It is very dangerous because there is a risk for damage for the product or accident caused by the product. Never do that. ●If you neglect cleaning of the oil tank and continue to cook, the product is in trouble.
- Page 16 ④Pull oil can slowly and lifting up a little to this end with holding the drawer handle of oil ※持上げぎみにして引出す Pull out with lifting a little. can to remove. If pulling out quickly, it’s dangerous because oil may splash. There are wheels at the back of the bottom of the oil can.
- Page 17 General commercial kitchen Appliances & Equipment Maruzen Co.,Ltd. Head Office 2-19-18, Negishi, Taito-ku, Tokyo, Japan ０３－５６０３－７７２２ ０３－５６０３－７７２８ 台湾丸善股份有限公司 台北縣台北市延平北路二段２０２號１２樓之３ 010-886-2-2550-1355 010-886-2-2550-1399 Maruzen (Thailand) Co.,Ltd Room184/193 Floor29-C3 ForumTower Rachadaphisek Rd. Huai Khwang, Huai Khwang, Bangkok 10310 Thailand. 010-66-2-645-4242 FAX 010-66-2-645-4241...
