Summary of Contents for CSL DigiAir Pro 3
- Page 1 DIGIAIR PRO 3...
- Page 2 EN50136 & PD6662. The range consists of DigiAir Pro 3 Radio and DigiAir Pro 3 LAN - our single-path solutions that utilise either a Radio path or LAN to signal an alarm.
-
Page 3: Step 1 - Site Survey
DIGIAIR PRO 3 - LAN DigiAir Pro 3 uses DHCP as the default IP settings. Fixed IP settings can be added or amended using the My Base App. Fit the Ethernet Cable to the device and connect to the customer’s router. Ensure the customer’s LAN socket is live and their network allows access to the CSL servers through their firewall... -
Page 4: Step 2 - Installation
DigiAir Pro 3 Step 2 - Installation DigiAir Pro 3 must be installed within an enclosure suitable for the installation certification. The unit should be fixed securely using the adhesive pads supplied or via the screw fixings accessible by removing the lid. - Page 5 • INSTALL CLOSE TO METAL OR SOURCES OF INTERFERENCE, E.G. WIRING, DON'T LIGHTING, ELECTRICAL INSTALLATIONS, COMPUTERS, MONITORS, ROUTERS & OTHER EQUIPMENT.
- Page 6 DigiAir Pro 3 Step 3 - Commissioning On power-up, the DigiAir Pro 3 will automatically contact the Gemini Global Platform to perform its commissioning process, which can take up to 5-8 minutes. Once commissioned, all 3 LEDs will light green for 5 seconds. The device will then reboot.
- Page 7 DigiAir Pro 3 Step 4 - Testing Before leaving site you must test the DigiAir Pro 3 device as per these steps. 1 - Place device on test at the ARC and send a range of signals from the panel 2 - Perform a path test by tapping button C whilst in quiescent/normal state 3 - LED 3 will flash to show signals are being sent...
- Page 8 ID. USING THE BUTTONS & LEDs Once commissioned, the DigiAir Pro 3 enters the quiescent or normal state. In this state, LED 3 will show the device status and there will be no other activity on LED 1 or 2.
- Page 9 Press Button A again to return to Quiescent/Normal State. LED 1 - Primary Path LED 2 - N/A LED 3 - N/A Figure 4 - Connectivity GENERATE A TEST CALL Press Button C once from Quiescent/Normal State to send a Test Call EXECUTE PIN LEARN From the Quiescent/Normal State, press and hold Button C for 5 seconds to allow the device to perform a self-learn of the current input pins.
- Page 10 DigiAir Pro 3 Panel Integrations Your device will come pre-configured to connect to the panel using pin triggering. In My Base it will show Panel Type = pins only. A panel can also be connected using • Dial Capture (PSTN Modem) •...
- Page 11 Figure 5 – Example of pin triggering wiring CONFIGURING PIN INPUTS To self-learn the current panel input status, press button C whilst in quiescent/normal state for 5 seconds. LED 3 will flash red twice once completed. To change the input from negative removed or applied to positive removed or applied, change the pin bias via My Base under the Hardware menu button and use the A+ terminal instead of RTN.
-
Page 12: Panel Connections
Fast Format*, Contact ID or SIA. In the event the control panel needs to send a signal to the ARC, DigiAir Pro 3 will capture the message and forward it, via Gemini, to the ARC. The Digi-Modem must have an ARC telephone number (ie 01) - Page 13 Dial Capture connection, you will need to connect an output configured as PSTN line fault on your control panel, to one of the DigiAir Pro 3’s inputs. That input then needs to be designated as Dial Capture Fail at your ARC.
- Page 14 PRO 3 BEFORE CONNECTING THE SERIAL LEAD, TO AVOID DAMAGE. For RISCO, Eaton, UTC and other panels, please purchase the relevant cable from CSL Live. For other connections or further instructions on Control Panel programming, panel guides can be found by clicking the panel type (after selection)
- Page 15 DigiAir Pro 3 My Base App My Base provides Installers with the ability to manage and configure DigiAir Pro 3 devices on a handy App/Web portal. Simply download CSL My Base from your appropriate App store and obtain log-in information from CSL (or the CSL web administrator within your company) to access these great features: Configure static IP...
-
Page 16: Troubleshooting
Green Solid Figure 10 - LED Key As the DigiAir Pro 3 powers up for the very first time it will run through its commissioning process. You will need to wait for LEDs 1, 2 & 3 to go green before the unit reboots. -
Page 17: Led Description
Error found on the device (no commissioning performed) No errors found and the device is currently transmitting or receiving data Operating normally Figure 12 - Quiescent/Normal State LEDs From the quiescent/normal state, press button A. Only LED 1 will show. LED 1 No signal / SIM not ready or LAN not connected Registering / Signal is unacceptable / LAN connected but cannot transmit data... - Page 18 Q. Does my unit have a roaming SIM? A. Yes, all DigiAir Pro 3 Radio devices come with 2 Roaming 4G SIMs Q. My signal strength is 30% (3/10) or less or my LED is orange/red. What can I do to improve it? A.
- Page 19 A. No, it will also work with DHCP. Q. Does the DigiAir Pro 3 support any type of negotiation speed? A. No, the DigiAir Pro 3 will only support negotiation speeds of up to 100Mbps.
-
Page 20: Technical Specifications
The SPT will shut down on detecting a low supply of 7.6 Volts DC +/- 0.5 Volts DigiAir Pro 3 Radio attached to Security Panel: 66 mA (average value) Current DigiAir Pro 3 Radio attached to Fire Panel: 55 mA (average value) -
Page 21: What's In The Box
DIGIAIR PRO 3 AVAILABLE PATH WHAT'S IN THE BOX PART NUMBER GRADES Radio DigiAir Pro 3, serial cable & CS.51.R2 small aerial DigiAir Pro 3, serial cable & CS.51.L2 small aerial DigiAir Pro 3 CSL DualCom ltd. Building 4, Croxley Park, Hatters Lane, Watford, WD18 8YF DoP No.
