Solid Surface Ramp
Portable ramp for temporary or semi-permanent use. Available with or without handrails.
Instructions for Part #SSG and #SSGHR
RAMP WITHOUT HANDRAILS
GENERAL GUIDELINES & SAFETY
• It is the user's responsibility to read and follow all instructions
• Keep these instructions with the product at all times and review before each use
• It is the responsibility of this product's owner to furnish the instructions to any person that borrows or
purchases the product
• Inspect the product before use to ensure it is assembled properly and all parts are in safe working
order and free of defects
• Never modify this product in any way
• All circumstances cannot be addressed in these instructions
• Please use common sense and practice general safety measures when using this product
•
Parts and/or instructions are subject to change without notice
17602 REV 07-19-2021
1-888-651-3431
RAMP WITH HANDRAILS
All text and images contained in this document are
copyrighted, proprietary, and may not be shared, modified,
distributed, reproduced, or reused without the express
written permission from the manufacturer.
Advertisement
Table of Contents
Summary of Contents for Silver Spring SSG
- Page 1 Solid Surface Ramp Portable ramp for temporary or semi-permanent use. Available with or without handrails. Instructions for Part #SSG and #SSGHR RAMP WITHOUT HANDRAILS RAMP WITH HANDRAILS GENERAL GUIDELINES & SAFETY • It is the user’s responsibility to read and follow all instructions •...
- Page 2 INTRODUCTION The Solid Surface Ramp is available with or without handrails (if walking on the ramp, handrails are required). This portable ramp is ideal for either temporary or semi-permanent use and is designed for the rigors of repeated, everyday use. Throughout this manual, the Solid Surface Ramp is also referred to as ‘ramp’...
- Page 3 GETTING STARTED Read this instruction manual in its entirety before use and follow all instructions before and during use. Before use with mobility equipment, refer to your mobility equipment's owner guide for acceptable ramp usage, including proper slope/incline, chair direction, etc.; never exceed its recommendations. Before each use, check the ramp for worn, loose, or damaged parts.
- Page 4 AVAILABLE RAMP STYLES The Solid Surface Ramp is available with or without handrails and in a variety of lengths. Shown below is the 6-ft. ramp without handrails (FIG. 1) and the 6-ft. ramp with handrails (FIG. 2). FIG. 1 FIG. 2 CARE AND MAINTENANCE Before each use, check the ramp for worn or damaged parts.
- Page 5 Ramp handrail vertical posts each have two holes that correspond with the studs on the brackets. Place the side with the holes onto the bracket studs (FIG. 4). Handrails are interchangeable from side to side. 5.5.1 Attach using (2 ea.) washers and nuts per handrail post. Tighten securely with ½” socket or wrench.
- Page 6 SET UP AND USE Place the ramp’s top lip transition plate (identifiable by its two pre-drilled holes) onto the upper landing. Ensure that the surface area of the top lip transition plate fully overlaps a secure, unobstructed, level landing enough to safely install provided clevis pins or other non-provided anchoring hardware, and rests firmly against the upper landing (FIG.
- Page 7 INCLINE CHART An incline chart is provided below, however, it is intended only as a guideline. Before use, refer to your mobility equipment's owner guide for acceptable ramp usage, including proper slope/incline, chair direction, etc.; never exceed its recommendations. TO ESTABLISH THE PROPER RAMP LENGTH 1.
- Page 8 PRODUCT WARRANTY & LIABILITY GENERAL PRODUCT WARRANTY: Products purchased from the Authorized Dealer (original place of purchase) or Merchant (“Dealer”) will be free of defects in material and workmanship at the time of receipt, and will meet the specifications stated at the place of purchase transaction or online at the Dealer’s website, under normal use and service when correctly installed, operated and maintained.
