8. Follow the steps outlined in this installation manual and notify Terrasmart within 48 hours of delivery of any missing or defective parts or any other concern with regards to the installation process, including conflicts between this installation manual and codes, regulations, laws and/or other documentation.
Neither Terrasmart nor its affiliates assume any responsibility for use of information furnished by Terrasmart or its affiliates, nor for any infringements of patents or other rights of third parties that may result from the use of such information. No license is granted by implication or otherwise under any patent or patent rights of Terrasmart or its affiliates.
Avoid working on system in rain or standing water. Proper Installation and Maintenance: The TerraGlide Portrait Mounting System must be installed, operated, and maintained as specified in this manual and the TerraGlide O&M manual. If not, then personal safety and product reliability may be compromised. Inspections of all components should be performed yearly to ensure there are no loose components, fasteners or corrosion.
Page 29
Cee Purlin as shown in Figure 3.3.24. The Cee Purlins are pre-punched to match the mounting hole locations on the PV module frame. Consult section 3.5 and Appendix 1 in this installation manual, as well as Terrasmart project specific construction drawings for specific PV module fastening details.
Page 32
2. Verify the tilt angle is within tolerance as specified by the EPC. On the East-West slopes, the resulting compound angle of the PV modules may result in a skewed tilt angle. Terrasmart recommends measuring the tilt angle at the Rafter and not on the PV modules. Adjust as needed by raising or lowering the North Posts as shown in Figure 3.3.30.
Bonding and Grounding Requirements Install lay in lug (Burndy CL501-TN or approved grounding device for the Terrasmart racking system) at the end of one Cee Purlin per rack following manufacturer’s instructions and as shown in Figure 3.4.1. Lay in 6 AWG copper equipment grounding conductor (EGC) into the lay in lug and route to NEC compliant direct to earth ground such as a properly sized grounding rod or to the main equipment ground.
Note – Not all of these PV module-to-mounting system bonding methods have been evaluated for use with every specific PV module. Please consult the Appendix 1 - Terrasmart, Inc. UL 2703 Approved PV Module Bonding List (for TerraGlide Portrait, TerraGlide Landscape, and TerraFarm 3L) of this document for the appropriate bonding method for a chosen PV module.
