Wireless Dual Channel Microphone System
USER MANUAL
FR : Un manuel dans votre langue est disponible sur Internet:
IT: Il manuale nella sua lingua può essere trovato su Internet:
ES: Puede encontrar un manual en su idioma en Internet:
PT: Um manual em seu idioma pode ser encontrado na Internet:
PL: Instrukcję w swoim języku możesz znaleźć na stronie:
SV: En handbok på ditt språk finns på Internet:
NL: Een handleiding in uw taal vindt u op internet:
bit.ly/3FkosHS
EN
Advertisement
Table of Contents
Summary of Contents for MYSTUDIO MIC DUO
- Page 1 Wireless Dual Channel Microphone System USER MANUAL FR : Un manuel dans votre langue est disponible sur Internet: IT: Il manuale nella sua lingua può essere trovato su Internet: ES: Puede encontrar un manual en su idioma en Internet: PT: Um manual em seu idioma pode ser encontrado na Internet: PL: Instrukcję...
-
Page 2: Table Of Contents
Description of the microphone transmitters ........10 Description of the receiver ..............11 Charging ..................... 12 Recording with Wireless MIC DUO ............. 13 Preparing the receiver and the microphones ......13 Muting a microphone ..............14 Adjusting gain levels ..............14 Connection reset ................ - Page 3 Disclaimer Easypix makes no representations or warranties with respect to this manual and, to the maximum extent permitted by law, expressly limits its liability for breach of any warranty that may be implied to the replacement of this manual with another. Furthermore, Easypix reserves the right to revise this publication at any time without incurring an obligation to notify any person of the revision.
-
Page 4: General Instructions
General instructions Read this manual and its safety instructions before using this product. Follow all the instructions. This will avoid fire, explosions, electric shocks or other hazards that may result in damage to property and/or severe or fatal injuries. The product shall only be used by persons who have fully read and understand the contents of this user manual. -
Page 5: Explanation Of Safety Warnings
NOTICE Indicates information considered important, but not hazard-related. Product introduction MyStudio Wireless Mic Duo is a compact, rechargeable wireless mic system consisiting of a dual channel receiver, two microphone transmitters and a protective charging case. Intended use This product is intended for use anywhere where wireless and convenient ‘plug and play’... -
Page 6: Declaration And Prove Safety
near hospitals or medical equipment due to possible radio interference. Declaration and prove safety The product has been verified in accordance with the essential requirements and other relevant provisions of Directives 2014/53/EU, 2011/65/EU & (EU) 2015/863 and in accordance with the Radio Equipment Regulations 2017 (SI 2017 No. -
Page 7: Safety Instructions
Safety instructions WARNING This product is only suitable for the purpose described, the manufacturer is not liable for damage caused by abnormal use. WARNING Please read this instruction manual carefully before use. Keep all small parts out of the reach of small children. •... -
Page 8: Operating Environment
Operating environment HINWEIS Operation only permitted in closed rooms. - Do not use the product in places where the use of radio equipment is prohibited. - Do not use the product near hospitals as well as medical devices such as pacemakers, hearing aids, etc. -
Page 9: Radio Interference And Disturbance
- Check with your doctor or the manufacturer of your medical device (pacemaker, hearing aid, implant with electronic control, etc.) to ensure that it will not interfere with the use of the product. Frequencies of MyStudio Wireless MIC DUO: Modulation type Transmitting frequency and transmit power GFSK •... -
Page 10: Storage Environment
NOTICE The range in buildings can deviate greatly from the range in sight. In addition to the transmitting power and the receiver characteristics, environmental influences such as air humidity or structural conditions on site play an important role for the range. Storage environment •... -
Page 11: Description Of The Microphone Transmitters
Description of the microphone transmitters 1. Microphone 8. 3.5mm audio input 2. Power / 9. Reset button Battery indicator 10. TYPE-C charging port 3. Wireless connection 11. Mounting clip indicator 12. Magnetic charging 4. Mute status indicator contacts 5. Recording indicator 13. Windshield holder 6. -
Page 12: Description Of The Receiver
Description of the receiver 1. Power On/Off 6. MIC 1 2. Reset button Connection indicator 3. TYPE-C charging port 7. 3.5mm audio output 4. Power / 8. TYPE-C digital Battery indicator audio output 5. MIC 2 9. Mounting clip Connection indicator 10. Magnetic charging contacts... -
Page 13: Charging
Charging Please ensure the microphones and receiver are fully charged before first use. Charging can be completed by placing each of the units into the charging case and connecting the USB-C port of the case to your computer. Alternatively the units can be charged by direct connection to the USB-C charging port on each device. -
Page 14: Recording With Wireless Mic Duo
Recording with Wireless MIC DUO Preparing the receiver and the microphones 1. Connect the receiver to your camera, smartphone, laptop or recording device. This can be done by using either the 3.5mm cable for connection to a DSLR camera for example, or by using the USB-C cable. NOTICE In the case of use with iOS devices an Apple® Lightning to 3.5mm Headphone Jack Adaptor is required which be used in conjunction with the 3.5mm cable. -
Page 15: Muting A Microphone
To reactivate recording simply short press the power button again. Adjusting gain levels MYSTUDIO MIC DUO allows you to set the gain levels independently on each microphone. To do this simply short press the Db gain adjustment button (6) until the green LED flashes. - Page 16 The gain adjustment has 3 levels as follows: Level 1: -40db – Green LED flashes once Level 2: -50db – Green LED flashes twice Level 3: -70db – Green LED flashes 3 times NOTE: Db gain adjustment is not possible when the microphone is muted.
-
Page 17: Connection Reset
Connection reset Should the product experience an issue whereby the wireless connection is lost, the pairing between the mics and receiver must be re-established. This process is completed using the reset buttons: 1. Turn on both the mic and receiver units 2. -
Page 18: Functions And Indicators: Microphone Transmitters
Functions and indicators: Microphone transmitters Function Button LED Status Power On Long press power Connection indicator LED is button illuminated Power Off Long press power All LED’s are off button Disconnected Connection indicator LED flashes slowly Connected Connection indicator LED is illuminated Gain Adjustment Short press Db button Recording LED indicator flashes to cycle through 3 gain... -
Page 19: Functions And Indicators: Receiver
Functions and indicators: Receiver Function Button LED Status Power On Long press power button MIC LED flashes Power Off Long press power button ALL LED’s off Disconnected Mic indicator LED flashes Connected MIC1 LED illuminated Charging Battery LED illuminated Fully Charged ALL LED’s off Low Power Battery LED flashes once per second Functions and indicators: Charging case... -
Page 20: Box Contents
• Dual Channel Receiver • USB Cables 2x • 2x Wireless Microphone • 3.5mm Cable Transmitter • User Manual EN/DE • 2x Clip-on Windshield • Charging Case Operating instructions in other languages are available for download at bit.ly/3FkosHS or www.easypix.info/download-manuals/download/mystudio-mic-duo/... -
Page 21: Technical Specifications
Technical specifications Wireless Dual Channel Microphone System • Dual channel receiver + 2x MICs transmitters • Digital transmission 2.4GHz • Working distance up to 150M • Adjustable gain control Level 1:~40db Level 2:~50db Level 3:~70db • For use with devices containing an audio input •... -
Page 22: Disposal
Disposal Disposal of packaging: Dispose of the packaging according to its type. Add cardboard and paperboard to the waste paper, foils and plastic wrapping to the recyclable waste collection. Waste electrical and electronic equipment and/or batteries disposed of by users in private households in the European Union: This symbol on the product or on its packaging indicates that it cannot be disposed of with household waste. -
Page 23: Declaration Of Conformity
Directives 2014/53/EU and 2011/65/EU & (EU) 2015/863. The full text of the EU Declaration of Conformity can be found in German and English at: www.easypix.info/download/pdf/doc-mystudio-mic-duo.pdf UKCA Declaration of conformity We hereby declare that the product complies with the Radio Equipment Regulations 2017 (SI 2017 No.1206).
