Summary of Contents for FoxSec FS9500
- Page 1 FoxSec FS9500 FoxSec FS9500 LCD keypad LCD keypad user guide user guide 2009 2009...
- Page 2 Index Index Index 1. FoxSec FS9500 LCD keypad user guide 1. FoxSec FS9500 LCD keypad user guide 1.1 Basic principals 1.1 Basic principals 2 Base level 2 Base level 3 User level ...
- Page 3 1. FoxSec FS9500 LCD keypad user guide 1.1 Basic principals FoxSec LCD menu has 4 levels: 1. and 2. level menu is for every keypad and user deniable/allowable by installer 1. Main level – open for anyone. Moving between menus can be done with arrow buttons ↑ and ↓.
- Page 4 Index 2 Base level Moving around Menu will show amount of menu use buttons FoxSec 2.8 alarms automatically on screen 1 new alarms ↓, ↑ and ← if in main unit has unaccepted alarms ↓ Menu will show amount of bypassed zones in the main FoxSec 2.8...
- Page 5 Index 3 User level 3.0 Action level Work time Moving around 3.1 Action level menu use buttons In user level user can arm, disarm, accept Work time alarms, change settings by the rights given ↓, ↑ and ← to user If there is special worktime software in use then user can start workday...
- Page 6 Index 3 User level 3.2 Action level Disarming Moving around menu use buttons ↓, ↑ and ← 2. Disarming areas? 2. Disarming areas? 1002*1003 area 1002 name ↓ The letter after area name will show its status 2. Disarming areas? R –...
- Page 7 Index 3 User level 3.3 Action level Arming Moving around menu use buttons ↓, ↑ and ← 3. Arming areas? 3. Arming areas? 1002*1003 ALA 1002 NIMI ↓ The letter after area name will show its status R – ready A- Armed 3.
- Page 8 Index 3 User level Moving around menu use buttons ↓, ↑ and ← Pressing ‘YES’ button will disarm Full disarming? all of the areas in this main panel except restricted areas. Menu is shown only if user has appropriate right assigned. ↓...
- Page 9 Index 3 User level 3.7 Action level Accept own alarms Moving around menu use buttons ↓, ↑ and ← Every ‘Yes’ button pressing will show unaccepted alarm only in View only allowed those areas that user has with Area alarms, accept? rights and after showing last alarm, system asks to accept all alarms.
- Page 10 Index 3 User level 3.8 Action level Changing own PIN code Moving around menu use buttons ↓, ↑ and ← In case all of the keypads are with card reader then user can change own PIN code freely Replace Insert 4-number Insert again →...
- Page 11 Index 3 User level 3.9 Action level Changing user PIN code Moving around menu use buttons Changing users PIN code is the same as changing own PIN code with difference that ↓, ↑ and ← first must select user whose PIN is about to change Replace Nr:1 USER NEW PIN? Insert 4-number...
- Page 12 Index 3 User level 3.10 Action level Allow blocked user Moving around menu use buttons In this menu admin can allow users back to the system with all previous rights ↓, ↑ and ← 10. Allow blocked Nr:1 Allow user? OK! User →...
- Page 13 Index 3 User level 3.11 Action level Blocking users Moving around menu use buttons In this menu admin can temporarily block user from system. Function is used if it is danger that users PIN code is out public or user has lost his access card. If user is ↓, ↑...
- Page 14 Index 3 User level 3.12 Action level Node blocking Moving around In this menu admin can temporarily block node from system (input/output nodes, menu use buttons keypads). Function is good if some node has problem that can not be repaired right ↓, ↑...
- Page 15 Index 3 User level 3.13 Action level Allowing node Moving around menu use buttons In this menu admin can allow blocked nodes back to the system (input/output nodes, keypads) ↓, ↑ and ← 13. Add node to Nr:1 Add OK! Node →...
- Page 16 Index 3 User level 3.14 Action level Zone bypassing Moving around In this menu admin can bypass zones. menu use buttons Function is good if there is problem with the zone that can not be repaired right away. ↓, ↑ and ← NB! Bypassed zone will NOT send an alarm to the alarm company 14.
- Page 17 Index 3 User level 3.15 Action level Zone un-bypassing Moving around menu use buttons In this menu admin can allow ALL of the bypassed zones ↓, ↑ and ← 15. Allow all OK! All bypassed zones bypassed zones? → allowed!!! ↓...
- Page 18 Index 3 User level 3.16 Action level Date and time In this menu user can view system date, time and holiday. 16. View 20:25:17 19.08.2009 → system time? WEEKDAY:4 Holiday=0 Holiday=0 not holiday ↓ Holiday=1 is holiday Weekday (1-sunday, 2-monday etc) Pressing ‘YES’...
- Page 19 Index 3 User level 3.17 Action level Viewing log Moving around menu use buttons In this menu user can view last 100 events made from this keypad. Also is shown arming ↓, ↑ and ← and disarming events made from other keypads but in that case event will not show who made that action.
