Q U I C K S T A R T
1
Remove screws from back of unit
3
housing and carefully remove back
cover to get access to battery holders.
W A R N IN G

AUTOMATIC GATES AND DOORS CAN CAUSE
SERIOUS INJURY OR DEATH!
ALWAYS CHECK THAT THE GATE/DOOR PATH
IS CLEAR BEFORE OPERATING!
REVERSING OR OTHER SAFETY DEVICES
SHOULD ALWAYS BE USED!
www.ShopAmericanAccess.com | (800) 878-7829 | Sales@ShopAmericanAccess.com
G U I D E

Unpack box and make sure you have all items shown here.

(Screwdriver not shown.)
Ridge ResKey AAA Battery
Unit
( 2x )
Hold circuit board in place and insert
4
batteries into battery holders, making
sure to place in correct orientation.

Install mounting plate where desired
6
(hardware not included).
(Can be done after programming.)
 IMPORTANT!
This unit is IP44-rated and has
some protection from the
elements, but it should be
mounted in a covered location.
Make sure to mount the unit
away from metal objects and
anything that will interfere
with or block RF transmission.
Receiver
(Security Brands 14-REC20
or 14-REC300 not included)
Place unit on a sturdy surface
to make this step easier.
Model
Remove single screw from bottom of
2
unit and remove unit from mounting
plate, pulling away from bottom end.
Pull away and down on unit to
release mounting plate hook
from unit groove (circled).
Replace back cover of unit and secure
5
with screws.
Attach unit and secure with screw.
7
(Can be done after programming.)
Slip mounting plate hook
(circled) into unit groove before
pressing unit into place.
1 of 2
14-RK10
