ICU Intelligent Identification offers age verification and several facial recognition-based functions
Age Restricted Sales Access Control Machine Access Authorised Vehicle Use
Photo ID Verification Face Covering Detection Targeted Advertising Know Your Customer (KYC)
Customise facial recognition, age verification and gender identification functions to fit your application
Age Restricted Sales
Photo ID Verification
ICU's core objective - to provide affordable and easy to use biometric technology
Proprietary Algorithms
We design, train and fine-tune
all our own algorithms
All algorithms run locally on the
hardware – quick, no internet
required (ICU Pro & ICU Lite)
Leading Biometric Solutions
Applications
ICU can benefit a vast number of industries.
Access Control
Face Covering Detection
Our Technology
Edge Solution
Complete intelligent solution
Local processing
Quick outputs
Machine Access
Targeted Advertising
Non-Intrusive Spoof
Authorised Vehicle Use
Know Your Customer
Multi-layered spoof
detection
No customer interaction
required

Advertisement

Table of Contents
loading

Summary of Contents for Innovative Technology ICU Series

  • Page 1 Leading Biometric Solutions ICU Intelligent Identification offers age verification and several facial recognition-based functions Age Restricted Sales Access Control Machine Access Authorised Vehicle Use Photo ID Verification Face Covering Detection Targeted Advertising Know Your Customer (KYC) Applications ICU can benefit a vast number of industries. Customise facial recognition, age verification and gender identification functions to fit your application Age Restricted Sales Access Control...
  • Page 2 Leading Biometric Solutions ICU Intelligent Identification offers age verification and several facial recognition-based functions Our Products ICU Pro Perform age verification & facial recognition-based functions on a machine or control entry points (e.g. Electronic Gates, Barriers, Restricted Premises) • No PC required •...
  • Page 3 Development Kit What’s included: • ICU Lite • USB Camera • Quick start guide • Documentation (stored on ICU Lite) • 3 months free IMS Cloud account (access to database & ICU Online calls) www.intelligent-identification.com...
  • Page 4 USER MANUAL Copyright © Innovative Technology Ltd 2021 ICU Range Manual Version: [1.0]...
  • Page 5: Table Of Contents

    ..................28 ESTING THE EVICE ONFIGURATION ICU M ..........................29 ANAGEMENT UITE 4.8.1 Login to the IMS ..........................29 4.8.2 Members ............................30 Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 1 of 68...
  • Page 6 Operation ............................57 7.3.2 Storage ............................57 ICU P ........................58 OWER EQUIREMENTS 7.4.1 Supply Voltages ..........................58 7.4.2 Supply Currents ..........................58 Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 2 of 68...
  • Page 7 Obama Fake ..........................64 9.1.3 Einstein Real ..........................65 9.1.4 Einstein Fake ..........................66 9.1.5 Underage ............................67 ......................68 XAMPLE IRCUITS OLENOID RIVER Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 3 of 68...
  • Page 8: Document Introduction

    Phone: +44 161 626 9999 (Main) Email: support@innovative-technology.com Phone: +44 161 507 1818 (Technical Support) Further Innovative Technology Ltd. representatives can be found on our website. www.innovative-technology.com 1.2 Related Documents This document should be read together with the following documents: ICU Image API –...
  • Page 9: Manual Amendments

    User Manual ICU Range << Back to Contents 1.3 Manual Amendments Rev. Date Amendment Details Issued by 09.07.2021 - First Issue Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 5 of 68...
  • Page 10: Copyright

    Authorized Reseller, and extending for the length of time stipulated by Innovative Technology Ltd. A list of Innovative Technology Ltd offices can be found on the website. If the product proves defective within the applicable warranty period, Innovative Technology Ltd will repair or replace the product. Innovative Technology Ltd shall have the sole discretion whether to repair or replace, and any replacement product supplied may be new or reconditioned.
  • Page 11: Product Safety Information

    1.7 Disclaimer Innovative Technology Ltd is not responsible for any loss, harm, or damage caused by the installation and use of this product. This does not affect your local statutory rights.
  • Page 12 • Následující krytí konečného produktu jsou požadované: Mechanické, Protipožární Caution! Accessibility to children not evaluated. To be evaluated in end product application. Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 8 of 68...
  • Page 13: Product Introduction

    • Age Restricted Sales • Access Control • Photo ID Verification • Face Covering Detection • Know Your Customer (KYC) 2.1.4 Component Overview Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 9 of 68...
  • Page 14: Icu Lite

    • Machinery Access • Authorised Vehicle Use • Photo ID Verification • Targeted Advertising • Know Your Customer (KYC) 2.2.4 Component Overview Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 10 of 68...
  • Page 15: Mechanical Installation

    USB- A connector Caution! The ICU Lite may interfere with wireless USB dongles if connected too close to each other Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 11 of 68...
  • Page 16: Software Installation And Configuration

    2. Remove USB drive once a pulsing blue light appears on the ICU Pro. This will take approx. 2 minutes Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 12 of 68...
  • Page 17: Accessing The Icu Pro & Icu Lite Via Usb (Rndis)

    2. Connect the ICU Lite to a USB port of a computer using the USB-A connector Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 13 of 68...
  • Page 18 9. Go to the “Sharing” tab, tick box as indicated and select to share with the Remote NDIS network (Ethernet 8). Click OK to confirm the settings Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 14 of 68...
  • Page 19: Link An Icu Device To An Account

    ITL 2. Once the account credentials had been verified correctly you will be prompted to the ICU home screen automatically Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 15 of 68...
  • Page 20 “Update Device Name” to save the changes. This name will refer to this device throughout your account Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 16 of 68...
  • Page 21: Camera Configurations

    For best results, use a USB camera with • Resolution 1280 X 720 (720p) • Auto focus and auto exposure Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 17 of 68...
  • Page 22: Camera Setup

    If there is a second camera connected to the ICU Pro please repeat and then click “Save changes” Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 18 of 68...
  • Page 23: Face Size And Pose Angle

    To reset the red bar, click “Reset min face size”. This will return the settings to zero and update as the session continues Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 19 of 68...
  • Page 24 Click “Save changes” to set the parameters on the ICU device Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 20 of 68...
  • Page 25: Zoom Mode

    1280 x 720 pixel Click “Save changes” to set the parameters on the ICU device Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 21 of 68...
  • Page 26: Modes Of Operation

    Consistency spoof detection Click on white button to disable Consistency spoof detection Click “Save changes” to set the parameters on the ICU device Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 22 of 68...
  • Page 27: Screen Spoof Detection

    2D spoof detection Click on white button to disable 2D spoof detection Click “Save changes” to set the parameters on the ICU device Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 23 of 68...
  • Page 28: View Mode

    FOV or a new face appears. Select a kiosk mode from the drop down menu Click “Save changes” to set the parameters on the ICU device Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 24 of 68...
  • Page 29: Api Mode

    API documentation. Click “API” tab or button on home screen Tick “API Enable function”. This will open the adjustable parameters Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 25 of 68...
  • Page 30 Function”. Click “Save” to apply the settings to the ICU device The ICU device will reset and reboot with API mode disabled Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 26 of 68...
  • Page 31: Video Stream Setup

    “Stream Enable”. Click “Save” to apply the settings to the ICU device The ICU device will reset and reboot with video stream disabled Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 27 of 68...
  • Page 32: Live View - Testing The Icu Device Configuration

    This will open a wide screen of the live video stream When a transaction has ended the results will be displayed in the box as shown Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 28 of 68...
  • Page 33: Icu Management Suite

    Sign in to your account with the login credentials provided by ITL The ICU dashboard will open once signed-in to an account Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 29 of 68...
  • Page 34: Members

    Enter First name, Surname and Additional (can be edited anytime) and click “Submit” to enroll the new members Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 30 of 68...
  • Page 35 For best results it is recommended to enroll images in a format how the person is likely to be presented to a camera in the application Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 31 of 68...
  • Page 36: Creating A Group

    Type in any group name and click “Create” All groups created will appear in the list and can be edited or deleted Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 32 of 68...
  • Page 37: Adding Members To Groups

    Select a member and click “Edit” Select a Group from the dropdown menu and click “Save” The selected group for a member is displayed as shown Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 33 of 68...
  • Page 38: Adding An Age Group

    Specify an age and a comparison i.e., if age < 25 and click “Create” The new age-related Action will now appear in the list Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 34 of 68...
  • Page 39: Outputs

    4.8.3.2 Example 1: Configure an Output on Control Out One Click on the Control Out One Output on the device image. This will open the adjustable parameters for this Output Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 35 of 68...
  • Page 40: Example 2: Create A Led Colour Change

    This will open the adjustable parameters for this Output Enter a name for this Output, select an LED colour and click “Save” Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 36 of 68...
  • Page 41: Example 3: Post-Url Via Ethernet

    (Basic in this example), enter username and password and click “Save”. This new Output will now appear in the list of created Outputs Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 37 of 68...
  • Page 42: Actions

    This will open all available Outputs to assign to the specific Action. To assign an Output click the checkbox next to it. Click “Save” Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 38 of 68...
  • Page 43: Applying Actions For Member Groups To Specific Icu Devices

    “Test action” Scroll down to the bottom of your browser and click “Save Changes” to apply the settings to the ICU device Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 39 of 68...
  • Page 44: Applying Actions For Age Groups To Specific Icu Devices

    “Test action” Scroll down to the bottom of your browser and click “Save Changes” to apply the settings to the ICU device Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 40 of 68...
  • Page 45: Applying Actions For Gender Detection To Specific Icu Devices

    “Test action” Scroll down to the bottom of your browser and click “Save Changes” to apply the settings to the ICU device Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 41 of 68...
  • Page 46: Applying Actions For Mask Detection To Specific Icu Devices

    “Test action” Scroll down to the bottom of your browser and click “Save Changes” to apply the settings to the ICU device Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 42 of 68...
  • Page 47: Applying Actions For Spoof Detection To Specific Icu Devices

    “Test action” Scroll down to the bottom of your browser and click “Save Changes” to apply the settings to the ICU device Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 43 of 68...
  • Page 48: Protocols And Interfaces

    ® Secure Protocol (eSSP) are field proven secure interfaces initially designed by Innovative Technology Ltd. to address the problems by cash handling systems in gaming machines. The SSP protocol specification has been updated to allow the user to poll ICU devices for faces presented to a connected camera and to retrieve the results of face detections.
  • Page 49: Interface Options Icu Pro

    16-way Serial Header provides access to 2x UART ports, 2x Logical Inputs & 2x Logical Outputs. Power (V ) can be supplied using this header as an alternative to the Latching Main Power connector. Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 45 of 68...
  • Page 50: Control Out

    (if the load is inductive) that an external re-circulating diode or other system is used to reduce the back EMF. Not required if using the voltage output pin from the ICU. Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0...
  • Page 51: Pin Assignments Icu Pro

    0V / GND Output Driver 2 for inductive loads Output Driver 2 Output Driver 1 for inductive loads Output Driver 1 0V / GND Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 47 of 68...
  • Page 52: Power

    User Manual ICU Range << Back to Contents 5.4.6.3 Power Pin Description 0V / GND 9 - 24VDC 0V / GND 9-24VDC Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 48 of 68...
  • Page 53: Setup Examples Icu Pro

    5.4.7 Setup Examples ICU Pro 5.4.7.1 Example 1: Age Verification with LED indications 5.4.7.2 Example 2: Door Access with Buzzer and LED indications Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 49 of 68...
  • Page 54: Interface Options Icu Lite

    High-Speed USB 2.0 Host port capable of data rates up to 480Mbps. Intended for connection to a USB compatible webcam. 5.5.3 Setup ICU Lite Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 50 of 68...
  • Page 55: Overview Of Basic Icu Network Infrastructure

    User interacts with user application User Interface User portal to interact with user application. All tasks are initiated from the User Interface Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 51 of 68...
  • Page 56: Example 2: Icu Devices Connected Via Ethernet To Wifi Client

    User User interacts with application User Interface User portal to interact with user application. All tasks are initiated from the User Interface Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 52 of 68...
  • Page 57: Example 3: Icu Devices Connected Via Wifi Network

    User User interacts with application User Interface User portal to interact with user application. All tasks are initiated from the User Interface Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 53 of 68...
  • Page 58: First Level Support

    Device is not registered to Green Quick flash any account Loading Neural Networks Purple Quick flash Populating Device DB Blue Slow flash Device waiting for Face Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 54 of 68...
  • Page 59: Technical Data

    User Manual ICU Range << Back to Contents 7 TECHNICAL DATA 7.1 Dimensions 7.1.1 ICU Pro Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 55 of 68...
  • Page 60: Icu Lite

    User Manual ICU Range << Back to Contents 7.1.2 ICU Lite 7.2 Weight ICU Pro: ICU Lite: Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 56 of 68...
  • Page 61: Environmental Requirements

    ICU Lite ICU Pro ICU Lite Temperature Humidity 7.3.2 Storage Environment Minimum Maximum ICU Pro ICU Lite ICU Pro ICU Lite Temperature Humidity Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 57 of 68...
  • Page 62: Power Requirements Icu Pro

    1.5A continuous. Solenoid outputs have a HW safety feature which limits the output drive to 10 seconds. Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 58 of 68...
  • Page 63: Power Requirements Icu Lite

    User Manual ICU Range << Back to Contents 7.5 Power Requirements ICU Lite 7.5.1 Supply Voltages 7.5.2 Supply Currents Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 59 of 68...
  • Page 64: Interface Logic Levels Icu Pro

    . The Input low voltage threshold is 1V, the input high voltage threshold is 3.1V. The outputs are driven using a push-pull 5V logic output. The source impedance is 470R. Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0...
  • Page 65: Compliances And Approvals

    The CB Scheme covers the below National Differences: • Europe EN 62368-1:2020+A11:2020 • Canada CSA 62368-1: 2019 • UL 62368-1: 2019 • Japan J62368-1 (H30) Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 61 of 68...
  • Page 66: Appendix

    The following faces can be used to test the ICU Device. Test Members are also added by default. Member Group Obama Real Premium Obama Fake Excluded Einstein Real Premium Einstein Fake Excluded Underage Under 25 Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 62 of 68...
  • Page 67: Obama Real

    User Manual ICU Range << Back to Contents 9.1.1 Obama Real Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 63 of 68...
  • Page 68: Obama Fake

    User Manual ICU Range << Back to Contents 9.1.2 Obama Fake Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 64 of 68...
  • Page 69: Einstein Real

    User Manual ICU Range << Back to Contents 9.1.3 Einstein Real Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 65 of 68...
  • Page 70: Einstein Fake

    User Manual ICU Range << Back to Contents 9.1.4 Einstein Fake Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 66 of 68...
  • Page 71: Underage

    User Manual ICU Range << Back to Contents 9.1.5 Underage Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 67 of 68...
  • Page 72: Example Circuits Solenoid Driver

    User Manual ICU Range << Back to Contents 9.2 Example Circuits Solenoid Driver Copyright © Innovative Technology Ltd 2021 Doc: GA00… User Manual ICU Range Version: 1.0 Page 68 of 68...
