Renata
Fitting Instructions
Steel Flat Tube Towel Rail
Please read these instructions and terms and conditions carefully prior
to installation. Failure to do so may invalidate the warranty.
Drawings
fig. 1
Pipe Centres
Pipe centres left to right
Pipe centres from wall
Depth from wall
1. Unpack & Inspect
This product should have reached you in perfect condition.
Please carefully unpack and inspect this radiator and
all fittings. Your point of purchase must be notified of
any shortages or damage within 28 days of delivery.
For further information please see terms and conditions
at the bottom of the next page.
www.radiatorsdirect.co.uk
=
width less 30mm
=
58mm - 68mm
=
73mm - 83mm
fig. 2
2. Contents
You should have:
• 1 Radiator
• 4 Wall Bracket
• 1 Manual Airvent
A
B
C
D
E
The fixing kits (screws and dowels) are suitable for compact walls or
hollow bricks. Please ensure suitable fixings are used for the correct
wall type.
01342 305555
You will need:
•
Electric drill & bits
•
Tape measure
•
Screwdriver
•
Spanner
•
Hex Keys
•
Spirit Level
•
PTFE Tape
•
Valves
