Drymatic Boost Bar Setup

DRYMATIC BOOST BAR - 90DEG ADAPTOR SETUP
The intended purpose of the Drymatic Boost Bar is to heat the airflow generated by a Centrifugal or Radial Air-Mover.
The system adds Heat Energy to the airflow, resulting in greater evaporation potential.
• Read the Owner's Manual fully before setting up and operating the Drymatic Boost Bar
• This presentation material offers set-up and use guidelines but DOES NOT substitute for fully reading the Owner's
Manual.
• The Owner's Manual and additional product information can be found on
Operating as a Target Drying System:
The Drymatic Boost Bar can be used to raise the ambient temperature within tented chambers, voids, subfloor spaces,
and cavities. Increasing the temperature of the affected materials will result in an increase in evaporation potential.
This guide will walk you through the use of the Boost Bar with the
Step 1: The Drymatic Boost Bar should be placed in front of a centrifugal or radial airmover (not axial) – it is
recommended that the airmover have a similar outlet size to that of the Boost Bar. A
should be used to maximise airflow between the two units. The Boost to Fan connector is fixed using the
on either side of the connector, this allows for various outlet sizes.
Website: www.drymatic.com
https://facebook.com/DBKDrymatic
www.drymatic.com
90deg Adaptor.
Fan to Boost Bar Connector
Fan to Boost Bar Connectors
The Fan to Boost Bar Connectors
guide all of the airflow into the Boost Bar, increas-
ing pressure and air velocity out of the
Adaptor, but they also tether the Airmover and
Drymatic Boost Bar together.
This reduces the risk of the policyholder seperat-
ing the two items on a claim and minimises the
chances of disruption to your drying regime.
Phone: +441443 237927
Email@ sales@drymatic.com
Velcro strap
not only help
90deg
