Summary of Contents for Sereonic WH-100
- Page 1 WIRELESS TV HEADPHONES USER MANUAL MODEL: WH-100...
-
Page 2: Package Contents
PACKAGE CONTENTS Transmitter x1 Headphones x1 Micro USB 3.5mm Audio 5V Adapter x1 Charging Cable x1 Cable x1 Digital Optical RCA Converter Cable x1 (optional) Cable x1... - Page 3 HEADPHONE AND TRANSMITTER DETAILS Charging Port (for base) ON/ OFF/ TUNE Charging Port Volume +/- Key for USB cable) Headphones Jack Coaxial Input Optical Input Port Channel Power Switch Port...
-
Page 4: Power The Transmitter
SETTING UP THE TRANSMITTER STEP 1: POWER THE TRANSMITTER Plug the power supply cable into the Dock/Transmitter Plug the adaptor into the wall socket or power strip. STEP 2: TEST HEADPHONES AND TRANSMITTER WITH YOUR PHONE Connect the Dock/Transmitter to your cellphone with the 3.5mm audio cable. Play the music on your cellphone. - Page 5 SETTING UP THE TRANSMITTER STEP 3: CONNECT TO YOUR TV’S AUDIO PORT OR CABLE BOX 4 options to connect with your TV or Cable box CONNECT OPTION 1: The Preferred Method: Optical Optical Port This method allows sound to be heard through the headphones and the TV. If you need sound to come only through the headphones, mute the TV.
- Page 6 SETTING UP THE TRANSMITTER CONNECT OPTION 2: RCA Audio Out Audio Out These are circular red and white Audio Out jacks, also called RCA jacks. Connect the included RCA adapter cable to the Audio Out or Output jacks on your TV. Then, connect the included AUX cable to the adapter and plug the other end of the AUX cable into the Audio In jack on the back of the transmitter.
- Page 7 SETTING UP THE TRANSMITTER CONNECT OPTION 3: Headphone Jack AUX PORT (HEADPHONE) Plug one end of the AUX cable into the TV’s AUX Port. Plug the other end into the AUX Port on the back of the transmitter. No sound will come through the TV if using AUX.
- Page 8 TV or cable box with the transmitter. STEP 4: USING THE SEREONIC HEADPHONES Make sure that the transmitter has been set up and is powered ON. Press the power button for 3 seconds to turn on the headphones.
- Page 9 CHARGING YOUR WIRELESS HEADPHONES OPTION 1: Docking Charging The dock/transmitter LED light will be flashing BLUE while the headphones are being charged. LED light will be steady BLUE when the headphones are fully charged. Please see tips as below: Before placing the headphones on the transmitter, make sure that the charging port of the headphone (left side) is the same direction as the charging pin of the transmitter!!! OPTION 2:...
-
Page 10: Troubleshooting
TROUBLESHOOTING A. I can’t hear any audio from my headphones. Check that the transmitter and your headphones are both turned ON. Check that all cables from the TV to the transmitter are connected properly. Check that the transmitter is plugged in to the AC outlet. Check that your headphones are fully charged Check that the headphones are within 100 feet of the transmitter. - Page 11 TROUBLESHOOTING C. I followed these steps, but I still don’t hear anything from my headphones. If you have a second TV at home, set up the Wireless Headphones on that TV and see if the audio works. If it works on the second TV, you may need to adjust the settings on the first TV.
-
Page 12: Warranty
Serene Group, Inc. warrant WH-100 to be free from defects in materials and workmanship under intended home use. If WH-100 fails to function properly due to defects in materials or workmanship, within one year of original purchase, return the unit (freight prepaid) with proof of purchase (sales receipt or packing slip, no exceptions) to Serene Group, Inc.
