Summary of Contents for Coaster 500500
- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 500500 SOFA BED RACK REVISION 0 : 09/06/2021 REVISION 1 : 10/04/2021 PAGE 1 OF 6 COASTERFURNITURE.COM...
-
Page 2: Parts Identification
500500 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. -
Page 3: Hardware Identification
500500 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS PARTS IDENTIFICATION LONG RACK SUPPORT 2PCS RACK ARM 4PCS HARDWARE IDENTIFICATION LEG PAD SHORT HEX BOLT 4PCS 8PCS (3/8" x 32mm) (3/8" x 45mm BLK) LONG HEX BOLT SMALL CAP 8PCS 12PCS (3/8" x 65mm BLK) - Page 4 500500 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS STEP 1 Do not tighten until each step is completed or instructed. STEP 2 PAGE 3 OF 7 PAGE 4 OF 6 COASTERFURNITURE.COM COASTERFURNITURE.COM...
- Page 5 500500 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 PAGE 3 OF 7 PAGE 5 OF 6 COASTERFURNITURE.COM COASTERFURNITURE.COM...
- Page 6 500500 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Product Size : 1086 X 1073 X 2426 H (MM) Product Size : 42.75" X 42.25" X 95.5" 945 mm 37.25" 2426 mm 2320 mm 95.5" 91.25" 1003 mm 39.5" 1073 mm 1086 mm 42.25"...
