Hytek FC05 Quick Setup Manual

1 - MAIN MENU
When the black manager's Datatag is inserted into
the Datatag slot the display screen will show the
screen below. Removing the Datatag at any time
will exit the configuration and the Terminal will
return to standby mode. To access the required
menu press the corresponding key on the keypad.
FT1000 MAIN MENU
1 = DISPLAY VEHICLE TOTALS
2 = SYSTEM SETUP
3 = TAG SETUP
4 = EXPORT OPTIONS
5 = STOCK LEVELS
<<PLEASE MAKE YOUR SELECTION>>
<<PLEASE MAKE YOUR SELECTION>>
3 - SYSTEM SETUP SCREEN
When "2" is selected on the Main Menu screen the
screen below is shown. NOTE: Options 5, 6 are
only present when the GREY ENGINEERS TAG is
inserted into the FC5. To access one of the six
options shown press the corresponding number on
the keypad. The time and date, when set, will be
displayed at the top of the main display screen in
standby mode. When a tank's low level is reached
a warning will be shown on the main display screen
in standby mode alongside the relevant tank
details. Press "0" on the keypad to return to the
Main Menu screen.
VEHICLE TOTALS FROM 00:00 00/00/2000
1 = SET TIME
2 = SET DATE
3 = SET TANK 1 LOW LEVEL > 1500L
4 = SET TANK 2 LOW LEVEL > 1200L
5 = PUMP SETUP
6 = TANK SETUP
<<PLEASE MAKE YOUR SELECTION>>
<<PLEASE MAKE YOU SELECTION>>
HYTEK FC05
FUEL CONTROL TERMINAL
QUICK SETUP GUIDE
0=BACK
2 - VEHICLE TOTALS SCREEN
When "1" is selected on the Main Menu screen the
screen below is shown. The total amount of fuel
drawn for each vehicle on the system is shown
along with its status (whether it has been locked
out of not). Pressing the CLR button on the
keypad will reset the totals. Press "0" on the
keypad to return to the Main Menu screen.
VEHICLE TOTALS FROM 00:00 00/00/2000
TAG
TAG REG
0 OVERRIDE
1 GU02YED
2 EX04YED
3 EX02XHO
4 GH09YAY
5 FD58DSX
6 DH47HJL
7 FH03GDF
2 = PAGE UP
<<PLEASE MAKE YOU SELECTION>>
4 – PUMP SETUP SCREEN
The PUMP SETUP screen is shown below. To
access this screen, press "5" from the SYSTEM
SETUP menu:
IMPORTANT: Please note that the "0 = BACK"
function is not available on this particular screen as
the "0" button changes the "MAG FACTOR" for
pump 2. You must remove the engineers tag to
save all inputted parameters.
SYSTEM No. 10000
PUMP 1
TANK NO. 1 > 1
START TIME 3 > 030
END TIME 5 > 030
7 > 010
PULSE RATIO
MAG FACTOR 9 > 01
ALT PUMP NO. C > 1
TANK CONFIGURATION
TANK 1
PRODUCT DIESEL
AMOUNT STATUS
305.00L
201.22L
189.33L LOCKED OUT
988.31L
416.28L
744.91L LOCKED OUT
345.21L
129.89L
8 = PAGE DOWN
CLR = RESET TOTALS
0=BACK
PUMP 2
2 > 2
4 > 040
6 > 040
8 > 010
0 > 01
E > 2
TANK2
GAS OIL
S534/2
