LaunchPad Interface User Guide
T-UG019 (v1.0) July 17, 2018
Abstract
This document provides information about interface board that allows user to connect Texas
Instruments LaunchPad board to Typhoon HIL emulator.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LaunchPad Interface and is the answer not in the manual?

Questions and answers

Summary of Contents for TYPHOON LaunchPad Interface

  • Page 1 LaunchPad Interface User Guide T-UG019 (v1.0) July 17, 2018 Abstract This document provides information about interface board that allows user to connect Texas Instruments LaunchPad board to Typhoon HIL emulator.
  • Page 2: Table Of Contents

    Typhoon HIL LaunchPad Interface User Guide Table of Contents Overview ......................2 Features ......................2 Detailed description ....................3 Analog signal connector .................. 4 Digital signal connector ................... 5 LaunchPad headers ..................6 Power supply ....................7 Product Images ....................8 Revision history ....................
  • Page 3: Overview

    LaunchPad Interface User Guide 1 Overview LaunchPad Interface is the way to go for those who want to accelerate the development of Power Electronics applications for Texas Instrument family of DSPs. Typhoon HIL emulates power stage of a PE device that includes power converters, electrical machinery, filters, electrical grid, PV cells, passive elements, etc.
  • Page 4: Detailed Description

    Typhoon HIL LaunchPad Interface User Guide 3 Detailed description LaunchPad Interface is shown in Figure 3.1. Numbers in white circles represents the sections of chapter 3 that describe the marked components of the board. Figure 3.1 – LaunchPad Interface layout...
  • Page 5: Analog Signal Connector

    This is a 96 pin DIN 41612/IEC receptacle connector that is directly pluggable into analog connector of the Typhoon HIL emulators, followed by three rows of measurement terminals. Table 1 shows how 20 analog signals (16 analog outputs and 4 analog inputs) from Typhoon HIL emulator are connected to LaunchPad headers (LAUNCHXL-F28379D analog stage).
  • Page 6: Digital Signal Connector

    This is a 96 pin DIN 41612/IEC receptacle connector that is directly pluggable into digital connector of the Typhoon HIL emulators, followed by three rows of measurement terminals. Table 2 shows how 32 digital signals (16 outputs and 16 inputs) from Typhoon HIL emulator are routed to the LaunchPad headers (LAUNCHXL-F28379D digital stage).
  • Page 7: Launchpad Headers

     LAUNCHXL2-RM46 LaunchPad Interface board is primarily designed for LAUNCHXL-F28379D while other LaunchPad boards are supported as well, but it is advised to check the pinout first because not all pins are available on all boards or they have different capabilities. Texas Instruments LAUNCHXL-F28379D is shown in Figure 3.4.
  • Page 8: Power Supply

    Typhoon HIL LaunchPad Interface User Guide 3.4 Power supply LaunchPad boards are powered from USB by default. With the LaunchPad Interface they can be powered from HIL instead. Proceed with caution. Study the schematic of the used LaunchPad board carefully before making any changes.
  • Page 9: Product Images

    Typhoon HIL LaunchPad Interface User Guide 4 Product Images Picture of LaunchPad Interface board, without the LaunchPad, is shown in Figure 4.1. Figure 4.1 -LaunchPad Interface www.typhoon-hil.com...
  • Page 10: Revision History

    Typhoon HIL LaunchPad Interface User Guide 5 Revision history Date Version Revision 17-07-2018 Initial release. Authorized Distributor : QUARBZ Info Systems , INDIA www.quarbz.com, e-mail: hil.info@quarbz.com Contact no.:91 9838071684, 91 9 8380 7 1 6 85 www.typhoon-hil.com...
