ONLINE RT1 LITHIUM
User Manual
LiFePO4 1.5K/2K/3K Online UPS
Uninterruptible Power Supply System
Version: 1.0
www.orionpowersystems.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONLINE RT1 LITHIUM and is the answer not in the manual?

Questions and answers

Summary of Contents for Orion Power Systems ONLINE RT1 LITHIUM

  • Page 1 ONLINE RT1 LITHIUM User Manual LiFePO4 1.5K/2K/3K Online UPS Uninterruptible Power Supply System Version: 1.0 www.orionpowersystems.com...
  • Page 2: Table Of Contents

    Table of Contents 1. Important Safety Warning ................... 1 1-1. Transportation ........................... 1 1-2. Preparation ..........................1 1-3. Installation ..........................1 1-4. Operation ..........................2 1-5. Maintenance, service and faults ....................2 2. Installation and setup ..................4 2-1. Rear panel view ........................4 2-2.
  • Page 3: Important Safety Warning

    1. Important Safety Warning Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully.
  • Page 4: Operation

    1-4. Operation Do not disconnect the mains cable on the UPS system or the building wiring outlet  (shockproof socket outlet) during operations since this would cancel the protective earthing of the UPS system and of all connected loads. The UPS system features its own, internal current source (batteries). The UPS output ...
  • Page 5 When changing batteries, install the same number and same type of batteries or  battery packs. Manufacturer Type Rated 25.6 V dc, 7.5 Ah LIFE-247500 Voltronic Power LIFE-485000 48 V dc, 5.0 Ah 76.8 V dc, 2.5 Ah LIFE-722500 Please replace the fuse only with the same type and amperage in order to avoid fire ...
  • Page 6: Installation And Setup

    2. Installation and setup NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. 2-1. Rear panel view 1K/1.5K 1. Programmable outlets: connect to non-critical loads 2.
  • Page 7: Install The Ups (Only For Rt1 Models)

    2-3. Install the UPS (Only for RT Models) For safety consideration, the UPS is shipped out from factory without connecting battery wires. Before install the UPS, please follow below steps to re-connect battery wires first. Step 1 Step 2 Step 3 Remove front panel.
  • Page 8 2. It’s required to maintain maximum altitude of 3000m to keep UPS normal operation at full load UPS. 3. Place UPS: It’s equipped with fan for cooling. Therefore, place the UPS in a well-ventilated area. It’s required to maintain minimum clearance of 100mm in the front of the UPS and 300mm in the back and two sides of the UPS for heat dissipation and easy-maintenance.
  • Page 9: Battery Replacement

    the UPS unit. Connect from “OUT” outlet to the equipment with another modem/fax/phone line cable. Step 5: Disable and enable EPO function This UPS is equipped with EPO function. By default, the UPS is delivered from factory with Pin 1 and pin 2 closed (a metal plate is connected to Pin 1 and Pin2) for UPS normal operation. To activate EPO function, remove two screws on EPO port and metal plate will be removed.
  • Page 10 NOTE 4 : Upon battery disconnection, equipment is not protected from power outages. CAUTION!! Consider all warnings, cautions, and notes before replacing batteries. Step 1 Step 2 Step 3 Remove front panel. Disconnect battery wires. Pull out the battery box by removing two screws on the front panel.
  • Page 11: Operations

    3. Operations 3-1. Button operation Button Function  Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to turn on the UPS.  Mute the alarm: After the UPS is turned on in battery mode, press and hold this button for at least 3 seconds to disable or enable the alarm ON/Mute system.
  • Page 12 Function Display Backup time information Indicates the estimated backup time. H: hours, M: minute, S: second. Configuration and fault information Indicates the configuration items, and the configuration items are listed in details in section 3-5. Indicates the warning and fault codes, and the codes are listed in details in section 3-7 and 3-8.
  • Page 13: Audible Alarm

    3-3. Audible Alarm Battery Mode Sounding every 5 seconds Low Battery Sounding every 2 seconds Overload Sounding every second Fault Continuously sounding Bypass Mode Sounding every 10 seconds 3-4. LCD display wordings index Abbreviation Display content Meaning Enable Disable Escape High loss Low loss Active open...
  • Page 14 01: Output voltage setting  Interface Setting Parameter 3: Output voltage For 230 Models, You may choose the following output voltage: 200: presents output voltage is 200Vac 208: presents output voltage is 208Vac 220: presents output voltage is 220Vac 230: presents output voltage is 230Vac (Default) 240: presents output voltage is 240Vac For 120 Models, You may choose the following output voltage:...
  • Page 15 05: ECO voltage range setting  Interface Setting Parameter 3: Set the acceptable high voltage point and low voltage point for ECO mode by pressing Down key or Up key. HLS: High loss voltage in ECO mode in parameter 2. For 230 Models, the setting range in parameter 3 is from +7V to +24V of the nominal voltage.
  • Page 16 08: Bypass frequency range setting  Interface Setting Parameter 3: Set the acceptable high frequency point and acceptable low frequency point for Bypass mode by pressing the Down key or Up key. HLS: Bypass high frequency point For 50Hz output frequency models: 51-55Hz: setting the frequency high loss point from 51Hz to 55HZ(Default: 53.0Hz) For 60Hz output frequency models:...
  • Page 17 13: Maximum charger current setting  Interface Setting Parameter 3: Set up the charger maximum current. 1/2/4/6/8: setting the charger maximum current 1/2/4/6/8 in Ampere. (Default: 4A) Recharge time VS charging current is as below table. Unit: hours Model DC1500RT1L DC2000RT1L DC3000RT1L 11.4 16: EPO logic setting ...
  • Page 18: Operating Mode Description

    00: Exit setting  Interface Setting Exit the setting mode. 3-6. Operating Mode Description Operating mode Description LCD display Online mode When the input voltage is within acceptable range, UPS will provide pure and stable AC power to output. The UPS will also charge the battery at online mode.
  • Page 19: Faults Reference Code

    3-7. Faults Reference Code Fault event Fault code Icon Fault event Fault code Icon Bus start fail Battery voltage too high Bus over Battery voltage too low Bus under Charger output short Inverter soft start fail Over temperature Inverter voltage high Overload Inverter voltage Low Charger failure...
  • Page 20: Troubleshooting

    4. Troubleshooting If the UPS system does not operate correctly, please solve the problem by using the table below. Symptom Possible cause Remedy No indication and alarm even The AC input power is not Check if input power cord though the mains is normal. connected well.
  • Page 21: Storage And Maintenance

    Symptom Possible cause Remedy Fault code is shown as 14 and the The UPS shut down Check output wiring and if icon is lighting on LCD automatically because connected devices are in display. Alarm is continuously short circuit occurs on the short circuit status.
  • Page 22: Specifications

    6. Specifications DC1500RT1L DC2000RT1L DC3000RT1L MODEL (RT UL model) CAPACITY* 1500VA/1350W 2000VA/1800W 3000VA / 2700W INPUT 160VAC/140VAC/120VAC/110VAC ± 5 % or 80VAC/70VAC/60VAC/55VAC ± 5 % Low Line Transfer ( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0) Low Line Voltage 175VAC/155VAC/135VAC/125VAC ±...
  • Page 23 Output Power Rating Table Model name Input rating Output rating DC1500RT1L 100-125Vac, 50/60Hz, 100/110/115/120/125Vac, 50/60Hz, 1Ø 12A, 1Ø 1500VA/1350W,12A (@125Vac input) ; 1500VA/1300W,12.5A (@120Vac input) ; 1500VA/1270W,13A (@115Vac input) ; 1500VA/1200W,13.6A (@110Vac input) ; 1350VA/1040W,13.5A (@100Vac input) DC2000RT1L 100-125Vac, 50/60Hz, 100/110/115/120/125Vac, 50/60Hz, 1Ø...
  • Page 24 Orion Power Systems Service and Technical Support If you have any problems or questions with the UPS, call your local distributor or Orion Power Systems technical support at the following telephone number: In the United States: 1-877-385-1654 Please have the following information ready when you call:...
