Summary of Contents for BROKIS MONA SMALL
- Page 1 CM12229...
- Page 2 INSTALLATION MONA SMALL MANUAL Table light Download COMPONENTS INCLUDED WARNING: WITH UNIT: 1x assembled light The manufacturer assumes no liability for 1x hex key size damage resulting from incorrect assembly. 1x cotton gloves When unpacking the light, do so with regard 1x installation manual for its material composition –...
-
Page 3: Cleaning The Glass
Cleaning information CLEANING THE GLASS BROKIS applies the highest possible quality standards in manufacturing its lights. Prior to shipping, each light undergoes several quality controls and stages of cleaning. Lights may require additional cleaning as a result of transportation, storage, and the amount of time that passes between packing in our plant and subsequent unpacking by the client. -
Page 4: Switching On The Light
SWITCHING ON THE LIGHT Plug the power cable into an electrical outlet and ensure the light works properly. PAGE 4... - Page 5 DISASSEMBLING THE SHADE / LIGHT SOURCE Use the hex key to loosen the set screw in the metal fixture and remove the shade with light source. PAGE 5...
- Page 6 REMOVING THE OUTER CAP Use the hex key to loosen the set screw in the outer cap of the light source and remove the cap. PAGE 6...
- Page 7 REMOVING THE OUTER CAP Use the hex key to loosen the set screw in the other outer cap of the light source and remove the cap. PAGE 7...
- Page 8 REMOVING THE LIGHT SOURCE LOCKING CYLINDER Use the hex key to loosen the set screw in the inner cap of the light source. Next, remove the locking cylinder by pulling it out of the shade while holding the light source in place. PAGE 8...
- Page 9 REMOVING THE LIGHT SOURCE Remove the light source from the glass shade. PAGE 9...
- Page 10 INSTALLING THE LIGHT SOURCE Position the light source in the glass shade so that it fits neatly in the holes. If the light source is loose in the holes, add another seal, position it in the holes again, and check for a snug fit. PAGE 10...
- Page 11 INSTALLING THE LOCKING CYLINDER Insert the aluminium locking cylinder through the hole in the glass and into the light source until the dimple in the cylinder is aligned with the set screw in the inner cap. PAGE 11...
- Page 12 INSTALLING THE OUTER CAPS Press the outer caps over the locking cylinders until flush against the glass. The rounded cap goes on the end of the light source without the connector. The open cap goes on the end with the connector. Tighten the set screws while gently pressing the caps against the glass.
- Page 13 INSTALLING THE SHADE Position the shade with light source on the metal fixture and secure in place with the set screw. PAGE 13...
