Owner's Manual
Lirico Toilet
Features:
-Porcelain elongated one-piece toilet
-Floor-standing installation
-Includes mounting hardware
-Siphonic single flush system (1.28 gpf)
-Soft-closing seat cover and tank are included
-Meets and exceeds the following standards/codes:
-ASME A112.19.2-2013/CSA B45.1-13/ASME A112.19.14-2013
-EPA's WaterSense Specification for Tank-Type Toilets
Table of Contents/Contenido:
Page 2: Product Specifications/Especificaciones de Producto
Page 3: Parts Breakdown/Desglosamiento de Partes
Page 4, 5, 6: Installation Instructions/Instrucciones de Instalación
Page 7 : Cleaning & Care/Cuidado y Limpieza
Advertisement
Table of Contents
Summary of Contents for Rejuvenation Lirico
- Page 1 Owner’s Manual Lirico Toilet Features: -Porcelain elongated one-piece toilet -Floor-standing installation -Includes mounting hardware -Siphonic single flush system (1.28 gpf) -Soft-closing seat cover and tank are included -Meets and exceeds the following standards/codes: -ASME A112.19.2-2013/CSA B45.1-13/ASME A112.19.14-2013 -EPA’s WaterSense Specification for Tank-Type Toilets...
- Page 2 Product Specifications/Especificaciones de Producto 15” 7” 28 5/8” 17 3/4” 3/4” 13 7/8” 31” INLET 16 1/2” M 7/8” 6” Outlet diam. OD: 3” ID: 2” Note: Drawings provided herein are meant to give the user an idea of the product and are not made to scale. The sizes in inches are rounded up to the nearest 1/16.
- Page 3 Parts Breakdown/Desglosamiento de Partes Hose Floater Fill Valve Flush Valve Lever kit...
- Page 4 Installation Instructions/Instrucciones de Instalación Toilet Installation 1. Install the water supply and drainage outlet as marked. 4. Holding the toilet up (2 people are recommended), align the toilet over Tile and seal the floor to prevent chemical reaction and damage the flange, slide the T# screws to align with the installation holes in the to the porcelain of the toilet.
- Page 5 Installation Instructions/Instrucciones de Instalación Flush System Installation/Adjustment 7. Open the tank cover and make sure the hose is inserted into the 8. Apply a bid of silicone around the toilet base, then overflow pipe. NOTE: The flushing water will be inadequate if the hose proceed to installing the toilet seat with cover.
- Page 6 Installation Instructions/Instrucciones de Instalación Seat Installation/Adjustment Assemble the hinges as shown and thread up Put the clear plastic washers on the underside of Tighten the screws until the hinges are nearly the nuts to the bottom of expandable plastic preassembled seat hinges - make sure they align fixed, then adjust them to align with the shafts anchors to prevent them from falling off, then properly and prongs are inserted into the holes.
- Page 7 Cleaning and Care For best results, please care for this product in accordance with the following instructions: - Only use warm water and a mild detergent (i.e. dishwashing soap) for cleaning. - If another cleaner is used, check the label to make sure that it is safe for use on the material being cleaned and always test in an inconspicuous area first.
