- Page 1 Installation Guide PMWT-560/580 Projector Wall Mount for SMART Board interactive whiteboards...
- Page 2 Trademark Notice SMART Board and the SMART logo are trademarks of SMART Technologies Inc. TORX is a trademark of Textron Inc. NEC is a registered trademark of NEC Corporation. All other third-party product and company names are mentioned for identification purposes only and may be trademarks of their respective owners.
-
Page 3: Installation Overview
For operating safety and to avoid damage, read this guide carefully before setting up and using the projector mount. Observe the following precautions: • Adding more weight or applying an unexpected force to the projector support may cause it to break and possibly cause injury. PMWT-560/580 Installation Guide... -
Page 4: Accessory Kit Contents
Do not hang anything from the support or hit or jostle it in any way. • If you require replacement parts, the service technician must use replacement parts that are specified by SMART Technologies Inc. or SMART-approved parts with the same characteristics as the original. Accessory Kit Contents... - Page 5 This guarantees that there is enough clearance between the projector mount and the ceiling. Make sure the highest anchor holes are at least: • 4" (10.2 cm) from the ceiling, if you’re installing a 560 PMWT-560/580 Installation Guide...
- Page 6 NOTE: If you would like to install the interactive whiteboard at the recommended installation height, make sure the lowest anchor holes are at least: • 74 1/2" (189.2 cm) from the floor, if you’re installing a 560 • 77" (195.6 cm) from the floor, if you’re installing a 580 PMWT-560/580 Installation Guide...
- Page 7 Assembling and Mounting the Projector Support Follow these instructions to assemble the projector mount and mount it on the wall. Upper Support Projector Brackets Lower Support NOTE: This illustration shows the projector wall mount for the 580. Wall Mount Bracket PMWT-560/580 Installation Guide...
- Page 8 1" Screw Projector Bracket Attachment for a 560 Projector 1/2" Screw Brackets Protruding Threaded Inserts 1" Screw Projector Bracket Attachment for a 580 2. Lay the wall mount bracket on the floor or any large, flat surface. PMWT-560/580 Installation Guide...
- Page 9 4. Attach the lower support to the wall mount bracket by inserting two No. 8-32 x 1/2" security hex screws in the third hole from the bottom, as shown in the diagram below. Leave the screws loose enough to allow for movement of the lower support. Upper Support Lower Support Wall Mount Bracket PMWT-560/580 Installation Guide...
- Page 10 Attaching the Upper and Lower Support for a 560 Vacant Screw Hole Upper Support Lower Support Attaching the Upper and Lower Support for a 580 6. Tighten all the screws that attach the upper and lower supports to the wall mount bracket. PMWT-560/580 Installation Guide...
- Page 11 Tighten the screw until it is snug, and then do another half-turn. Attaching the Projector Plate to the Projector 1. Close and lock the projector’s mirror cover. 2. Turn the projector over. 3. Remove the projector’s feet. PMWT-560/580 Installation Guide...
- Page 12 They make the projector less susceptible to theft and provide a backup support in case the feet attachments fail. It’s normal for the screws to protrude a significant distance even when you’ve tightened them. PMWT-560/580 Installation Guide...
- Page 13 Don’t tighten the screw completely. Insert it only until the screw becomes visible on the inside of the projector bracket. Slot in Projector Plate PMWT-560/580 Installation Guide...
- Page 14 Interactive Whiteboard Wall Mount Bracket 3. Horizontally center the interactive whiteboard below the projector mount, if necessary. 4. Connect the interactive whiteboard to your computer. Consult the installation guide that came with your interactive whiteboard for details. PMWT-560/580 Installation Guide...
- Page 15 Use the projector’s feet to make adjustments as well. To lower one side of the projector, loosen the feet on that side of the projector slightly. To lower the front or back of the projector, loosen the front or back feet slightly. PMWT-560/580 Installation Guide...
- Page 16 Although you can make additional adjustments digitally, digital adjustment can degrade the projected image’s quality. NOTE: After you’ve adjusted the image position, there may be a border of 1/4"–1/2" (0.6 cm–1.3 cm) between the projected image and the edges of the interactive whiteboard. This is normal. PMWT-560/580 Installation Guide...
-
Page 17: Customer Support
Calgary, AB CANADA T3C 0M5 Returning Defective Merchandise All projector wall mounts for SMART Board interactive whiteboards (PMWT-560/580) are covered by a two-year limited equipment warranty. To return defective merchandise, call SMART Technical Support. You will receive the appropriate Return of Merchandise authorization and instructions for transporting your projector wall mount to an authorized service center. - Page 18 300, 1207 – 11th Avenue SW Calgary, AB CANADA T3C 0M5 Main Switchboard: 1.888.42.SMART (Canada/U.S.) or +1.403.245.0333 (all other countries) Support Tel: 1.866.518.6791 (Canada/U.S.) or +1.403.228.5940 (all other countries) Support Fax: +1.403.806.1256 support@smarttech.com www.smarttech.com 99-00545-00 REV D0...
