Change for life

User's Manual

Operation Instructions

Dehumidifier

Models: GGL25AW

Thank you for choosing our product.

Please read this User's Manual carefully before operation and

retain it for reference.

If you lost the User's Manual, please contact the Tool Box or visit

www.gilman-group.com or send an email to Tool Box for the

electronic version.

Table of Contents

Need help?

Do you have a question about the GREE GGL25AW and is the answer not in the manual?

Questions and answers

Summary of Contents for GILMAN GREE GGL25AW

Page 1 Thank you for choosing our product. Please read this User's Manual carefully before operation and retain it for reference. If you lost the User's Manual, please contact the Tool Box or visit www.gilman-group.com or send an email to Tool Box for the electronic version.
Page 3: Table Of Contents
Contents Operation Notes Safety Precautions................1 Parts' Name..................2 Confirm the Following before Start Operation........3 Display of Air Cleanness..............4 Operation Instructions Introduction of Button Function............5 Treatment when Water Bucket is Full..........9 Continuous Drainage...............10 Maintenance Maintenance and Care..............11 Malfunction Check Items before Maintenance............15 Electric schematic diagram Electric schematic diagram..............17 NOTE:...
Page 5 Explanation of Symbols Indicates a hazardous situation that, if not avoided, DANGER will result in death or serious injury. Indicates a hazardous situation that, if not avoided, WARNING could result in death or serious injury. Indicates a hazardous situation that, if not avoided, CAUTION may result in minor or moderate injury.
Page 6: Safety Precautions
Safety Precautions This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruc- tion concerning use of the appliance in a safe way and understand the hazards involved.
Page 7: Parts' Name
Parts' Name Front Display, touch panel U-shaped light ring Air outlet Panel PM2.5 detection Temperature and Water bucket humidity detection Continuous drain cover Back Handle Activated carbon filter (inside) HEPA dust collection filter (middle) Air inlet Air filter (outside) Castor Power cord...
Page 8: Confirm The Following Before Start Operation
Confirm the Following before Start Operation The dehumidifier cannot cool and speed, and the protection device in will generate heat during operation, the unit may act to make the unit run which will cause the indoor tempera- intermittently. ture to rise slightly. When the room temperature and hu- midity become low, the dehumidifi- Please make sure that the water...
Page 9: Display Of Air Cleanness
Confirm the Following before Start Operation accuracy of different humidity detec- Humidity perception tion devices also have deviation. After moving, select the high fan mode to run for several minutes to quickly humidity humidity sense the environmental humidity. Display humidity is different from other hygrometers In different locations of the same room, the temperature and humidity may...
Page 10: Operation Instructions
Operation Instructions Introduction of Button Function Standby button After pressing the standby button , the dehumidifier starts or stops running. (When the operation stops or the power plug is plugged in again, press the standby button again immediately, and it will take about 3 minutes to start dehumidification) Humidity display After the unit starts running, it will automatically detect the indoor humidity, and...
Page 11 Operation Instructions Dry mode: When the icon " " is on, it means the unit enters the Dry mode. When the clothes drying is completed, the humidity in the room will be main- tained within a certain range to prevent the clothes from becoming moldy. NOTE Fan speed and humidity cannot be adjusted in Dry mode.
Page 12 Operation Instructions Fan speed button Press the fan speed button to adjust the fan speed of the unit. (Setting method: When the unit enters the drying function, the fan speed will be forced NOTE to be high and cannot be adjusted. When auto fan speed has been set, the unit will automatically adjust the fan speed according to the detected humidity under the dehu- midification mode.
Page 13 Operation Instructions Standby operation Under the standby status, touch the operation area (except the standby button) to wake up the WiFi button and the timer button , and then turn on or turn off the WiFi function and set the timer on function. Detection reminder The unit is equipped with the PM2.5 sensor.
Page 14: Treatment When Water Bucket Is Full
Operation Instructions Treatment when Water Bucket (2) Please wash it with cool or warm is Full water. Do not clean it with deter- gent, the chemically-treated cloth, Drainage gasoline, benzene, thinner or other solvents to avoid scratches or da- (1) Grasp the clasps at both sides of mage to the water bucket, which may the water bucket to pull out the water cause water leakage.
Page 15: Continuous Drainage
Operation Instructions uous drainage hole. Do not remove the float (magnet) assemb- ly in the water bucket, because the float (magnet) assembly is used to monitor whether the water level is full. Damage Be sure to plug it in to to it may cause the water in the tank to avoid water leakage.
Page 16: Maintenance And Care
Maintenance and Care To ensure the service life of the dehumidifier, please check and maintain it re- gularly. Turn off the dehumidifier and disconnect the power before cleaning the de- humidifier to avoid electric shock. Do not wash the dehumidifier with water to avoid electric shock. WARNING Do not use volatile liquid (such as thinner or gasoline) to clean the dehumidifi- er, otherwise it will damage the appearance of the dehumidifier.
Page 17 Maintenance and Care Cleaning of humidity sensor If the sensor is dusty, it may not work normally. It is recommended to maintain the humidity sensor once every month and clean it with the brush of vacuum cleaner. Be sure to operate the unit when the NOTE power plug is disconnected.
Page 18 Maintenance and Care NOTE Do not clean the air filter with water above 40°C, and do not ex- pose it to sunlight to avoid shrinkage and deformation of the filter, which will affect the use. The active carbon filter does not require special cleaning and main- tenance.
Page 19 Maintenance and Care When not in use for a long time When the unit won’t be used for a long time, please follow the methods below in order to ensure the service life of the dehumidifier. Pull out the power Pour out the remain- Clean the air filter.
Page 20: Check Items Before Maintenance
Check Items before Maintenance Troubleshooting Please check the following items in the table before contacting for mainte- nance. If the problem still cannot be solved, please contact the dealer or the professional in time. Status Please check Solution Is the power cord loose? Insert the power cord in the socket.
Page 21 Check Items before Maintenance Is the filter installed correct- Please operate according to the in- ly? Is the packaging film re- structions in the user’s manual. Poor removal moved? effect of dirty air If the problem is still not solved after Is the HEPA dust filter dirty? maintenance, please replace with a new filter.
Page 22: Electric Schematic Diagram
Electric schematic diagram The electric schematic diagram are subject to change without notice. Please refer to which one on the unit. SWING MOTOR DC-MOTOR PROXIMITY TUBE SWITCH TEMP.SENSOR DC-MOTOR FLOW BN(BK) TUBE SWING MAIN BOARD BU(WH) YEGN(GN) DISPLAY BOARD DISP DISP AC-L POWER...
Page 24 Warranty Registration 於網上登記新產品保養 Register your product online www.dchtoolbox.com 66129938269 客戶服務中心 DCH ToolBox Customer Service Centre 香港九龍灣啟祥道20號大昌行集團大廈4樓 4/F, DCH Building, 20 Kai Cheung Road, Kowloon Bay, Hong Kong 客戶服務熱線 Customer Service Hotline: (852) 8210 8210 電郵地址 E-mail: 8210service@gilman-group.com 網址 Website: www.gilman-group.com...
