INVOLAR

Micro-Inverters

eGate

INVOLAR Grid-Connected Photovoltaic

Power Interface

Model Number PIU4KA-230-UK

User Operating Manual

(Version_eGate(UK)G83_PIU4KA_1.5)

This manual is an integral part of the unit. Please read the instruction

manual carefully before installation, operation or maintenance. Keep this

instruction manual for future reference.

INVOLAR Corporation Ltd.

E-mail:

info@involar.com

Web:

www.involar.com

Tel: +86(0)2150272208

Fax: +86(0)2150277705

Table of Contents

Need help?

Do you have a question about the eGate PIU4KA-230-UK and is the answer not in the manual?

Questions and answers

Summary of Contents for Involar eGate PIU4KA-230-UK

Page 1 INVOLAR Micro-Inverters eGate INVOLAR Grid-Connected Photovoltaic Power Interface Model Number PIU4KA-230-UK User Operating Manual (Version_eGate(UK)G83_PIU4KA_1.5) This manual is an integral part of the unit. Please read the instruction manual carefully before installation, operation or maintenance. Keep this instruction manual for future reference.
Page 2 Contact Information Involar Corporation Ltd 887 Zuchongzhi Road, #84-407, Shanghai, 201203, China Tel：86-21-50272208 Fax：86-21-50277705 Web：www.involar.com E-mail：info@involar.com...
Page 3: Table Of Contents
TABLE OF CONTENTS READ THIS FIRST ........................ 4 SAFETY SYMBOLS ........................ 5 ........6 YMBOLS REPLACE WORDS ON THE EQUIPMENT ON A DISPLAY OR IN MANUALS ......................8 ECHNICAL OMPETENCE EC D ..................8 AFETY NSTRUCTIONS AND IRECTIVES FEATURES ..........................10 .........................
Page 4: Read This First
1 Read This First Involar‟s new product “eGate” acts as the power interface (PI) to the utility grid. It is a separate device installed at the coupling point to the utility grid to provide the safety functions such as over/under voltage, over/under frequency, active anti-islanding as well as lightning protection.
Page 5: Safety Symbols
2 Safety Symbols Warnings and cautions indicate possible dangerous conditions that can occur if instructions are not carefully read and followed. Please read the following safety symbols and important safety instructions. DANGER The DANGER symbols in this manual and on the eGate ndicates a hazard with a high level of risk which if not avoided, will result in death or serious injury.
Page 6: Symbols Replace Words On The Equipment, On A Display Or In Manuals
Symbols replace words on the equipment, on a display or in manuals. Trademark No access for unauthorized personnel Caution- risk of danger Symbol for the marking of electrical and electronics devices according to Directive 2002/96/EC. Indicates that the device, accessories and the packaging must not be disposed as unsorted municipal waste and must be collected separately at the end of the usage Please follow Local Ordinances or Regulations for disposal or contact...
Page 7 DC terminal, indicating the polarity of the connections, negative, all negative connections with black insulated wires Power conversion equipment, refers to our DC/AC inverter Service Personnel A person having appropriate technical training and experience necessary to be aware of hazards to which that person may be exposed in performing a task and of measures to minimize the risks to that person or other persons...
Page 8: Technical Competence
Involar require using only genuine replacement parts, manufactured or sold by Involar for all repairs or replacements. Read carefully through each step in every procedure before commencing installation; any exceptions may result in a failure to properly and safely complete the installation.
Page 9 The installation should only commence if there is a written permission to install the designated components. WARNING: IMPORTANT: the input AC voltage of the INVOLAR eGate shall not exceed the rated voltage; higher voltage may cause permanent damage to the device. It contains no user serviceable and INVOLAR-eGate Warranty parts.
Page 10: Features
3 Features Structure of eGate Figure 3.1.1 Structure of eGate ○ Cover Fixing Screws ○ PV Power Plant Input Cable ○ Grid Output Cable ○ Ethernet Cable (Optional) ○ Can bus Cable (Optional) ○ Communication module (Optional) ○ ○ ETU module...
Page 11: Safety Power Limiting Fold-Back Technology
Safety Power Limiting Fold-back Technology To provide a safe and flexible system design the eGate has an Intelligent „Fold-Back‟ Technology, which when required will communicate with one or more of the inverters within a branch circuit to reduce its power output. There are two areas where the technology is applied; Fold-back at eGate level: the current shall NOT exceed 16A under whatever circumstances;...
Page 12: Technical Parameters
Technical Parameters Model PIU4KA-230-UK Input Data (AC) Rated input power 3.68KW Rated input voltage 230V Rated input current Rated input frequency 50Hz Output Data (AC) Rated output power 3.68KW Rated output voltage 230V Rated output current 207V～264V Output voltage range Output frequency range 47Hz~50.5Hz Total current harmonic distortion...
Page 13: Installation
4 Installation Operating Condition Operating Temperature Ambient temperature: -20℃～﹢45℃。 Operating Humidity Air Relative Humidity <=90% Rated Input AC230V/50Hz...
Page 14: System Diagram
System diagram Figure 4.2.1 System diagram...
Page 15: Circuit Diagram
Circuit Diagram Figure 4.3.1 Circuit diagram of micro inverter installation.
Page 16: Installation Procedure
Installation Procedure Optional Ports Figure 4.4.1 Dimension of eGate Warning  eGate MUST connect to earth effectively.  Please ensure proper use of tools and correct personal protective equipment (PPE) are worn when carrying out installation. Caution Installation of power supply cable and CAN Bus/ Ethernet cables must be separate from each other.
Page 17 Installation Diagram See below Figure 4.4.2. Figure 4.4.2 Installation Diagram Mounting brackets. (2 top & 2 bottom) CAN Bus cable entry. (Optional) Ethernet cable entry. (Optional) AC cable to PV array. AC cable to grid. Table 4.4.3 AC Input Terminal Green/Yellow - PE Pin1-Green/Yellow Blue - N...
Page 18 Diagram 4.4.4 AC Connections Step1: Mount eGate cabinet to the wall or a fixed structure. Step 2: Connect the extension cable from the micro inverters to the input socket of the eGate marked „PV ARRAY‟. Step 3: Connect the extension cable with one bare end for grid point connection to the output socket marked „GRID‟.
Page 19: Operating Status
5 Operating Status INVOLAR‟s new product “eGate” acts as the power interface (PI) to the utility grid. It is a separate device installed at the coupling point to the utility grid to provide the safety functions such as over/under voltage, over/under frequency, and especially active anti-islanding protection as well as lightning protection and line impedance stabilizing network (LISN), modular design.
Page 20: Grid-Connection
PV module through each micro-inverter. When the output energy reaches the power generation conditions, the eGate system begin connect grid and generate electricity. Grid Disconnect If the state grid cannot match the following situations (table 5.1.1) the INVOLAR Micro-Inter will enter disabled mode. Type...
