Overland Storage Snap Server 4400 Assembly

®
Snap Server
You can set up your system to send an e-mail alert in the event of a hardware
Note
failure. For details, see the section on e-mail notification in your Administrator
Guide.
These instructions explain how to replace the fan assembly on the Snap Server 4400.

Shutting Down the Server

Shut down the server before you make any repairs. Improper shutdown may
Caution
lead to loss of data or physical harm.
To start the shutdown process, press the power button on the front of the server.
1
The green power LED remains lit until the shutdown process is complete. Do not
disconnect the AC power cord while the LED remains lit.
After the power LED is off, disconnect the AC power
2
cord from the back of the server.
If you need to remove the server from a rack to access
3
to the back panel, disconnect the Ethernet cable(s).

Removing the Top Cover

Press both top cover release latches toward the center.
1
Still pressing the latches, slide the front edge of the cover back about 1 inch.
2
Lift off the cover and set it aside.
3
Field Service Documentation
Copyright © 2009, Overland Storage, Inc. All rights reserved. Information in this document is subject to change without notice and does
not represent a commitment on the part of Overland Storage or any of its subsidiaries.
4400 Fan Assembly
Snap Server 4400
Power button
1
