Summary of Contents for Xenon FEVER DEFENCE
- Page 1 ASSEMBLY INSTRUCTIONS...
- Page 2 PARTS LIST - Centre Column - Base Unit - Display/Camera Unit - Power Lead Unscrew 3 bolts on bottom Remove 4 screws from top side of centre column of centre column cap...
- Page 3 Insert cables of base unit through side Insert centre column into opening on base aperture of centre column plate being careful not to pinch cables Insert 3 fixing bolts through baseplate to Remove lockring from display mounting attach centre column bracket...
- Page 4 Insert display bracket into top of centre Insert cables as follows: A- Power input column cap and fix securly with lockring from base (2 leads) to LED strip and Display. B- Network Cable from Base to Display. C- 2 x Centre Column USB ports to display USB Ports.
- Page 5 Insert 12v power lead to baseplate to power on...
