EOB WS360 Manual

Wireless transmitter

Hide thumbs

Table of Contents

Quick Links

Download this manual

WIRELESS

TRANSMITTER

CR2032

UNIVERSAL TRANSMITTER UNDER THE

EU DECLARATION OF CONFORMITY

Here is ELEKTROBOCK CZ s.r.o. declares that the WS360

radio equipment complies with Directive 2014/53 / EU. The

full text of the EU Declaration of Conformity is available at

the following Internet address: www.elbock.cz

Designed and manufactured in CZ.

WS360

150m

433.92 MHZ

SWITCH

IP20

Table of Contents

Need help?

Do you have a question about the WS360 and is the answer not in the manual?

Questions and answers

Summary of Contents for EOB WS360

Page 1 UNIVERSAL TRANSMITTER UNDER THE SWITCH EU DECLARATION OF CONFORMITY Here is ELEKTROBOCK CZ s.r.o. declares that the WS360 radio equipment complies with Directive 2014/53 / EU. The full text of the EU Declaration of Conformity is available at the following Internet address: www.elbock.cz...
Page 2 Description WS360 serves as a transmitter for wireless bells of the BZ90x series as well as for remote control of WS3xx receivers, which can switch various el. appliances (lighting, blinds, electric locks, direct heaters, etc.). The transmitter contains 4 inputs (K1 to K4). When any channel is pressed, a coded signal is sent to the learned receiver that performs the function.
Page 3 RF signal throughput The range between wireless devices is greatly affected by the distance between the transmitter, receiver, and obstacles on a straight line between them. The material from which the walls are made also decides. The reach is least affected by the weak wall of plasterboard or brick.
Page 4 1) Put the receiver in learning mode according to the instructions of the respective receiver. 2) Press the button on the transmitter (WS360) with which you want to control the receiver. 3) In case of successful pairing, the indicator LED on the receiver flashes.
Page 5 Controlled elements The following elements can be controlled using the WS360 transmitter: WS301 Receiver under the switch Order No.: 3301 WS302 Wall receiver Order No.: 3302 WS303 Receiver into the socket Order No.: 3303 WS304-10 DIN rail receiver Order No.: 3304...
Page 6 WS360 WS360 Wireless transmitter The universal transmitter under the WS360 switch can be used as a spare button for BZ9xx wireless doorbells, but also for controlling other wireless products with self- learning code (WS3xx series) from ELEKTROBOCK CZ. Advantages: - installation under the switch...
