- Page 1 STREET KART user manual printed_racers...
- Page 2 What you need: Street kart assembly Filament PLA / PC CF Hardware M1.6x3mm link M1.6x4mm link M1.6x5mm link M1.6x6mm link parts off from KST X06 servo M1.6x8mm link horn. M2.0x14mm link M2.0 nuts link Bearings 2x5x2,5mm link 0.9mm hex screwdriver link 1.5mm hex screwdriver link...
- Page 3 Street kart assembly Street kart assembly Secure upper plate and servo with Secure servo and seat with M1.6x8mm M1.6x5mm screw. screw. Secure steering links and servo horn Secure printed or brass 9mm standoffs with M1.6x4mm screws. Two arms of with M1.6x6mm screws.
- Page 4 Street kart assembly Street kart assembly Secure upper plate, servo and seat Secure spindles from below with to lower plate with M1.6x3mm, M1.6x4mm screws. Connect spindles M1.6x4mm M1.6x6mm screws. and steering links with M1.6x4mm screws. Spindles has to move freely but without any wobble. Use grease for more smooth movement.
- Page 5 Street kart assembly Street kart assembly Solder all wires on your ESC. Wires Secure motor mount with plastic should be longer than necessary for parts on both sides with better future cable management M1.6x6mm screws. and manipulation. Secure ESC with M1.6x4mm screws to the lower plate.
- Page 6 Street kart assembly Street kart assembly Solder wires from ESC to the N20 Secure rear axle bearings mounts motor. Install motor gear to the with plastic parts on both sides motor shaft. Fitment should be with M1.6x5mm screws. without any tolerance. Install rear axle bearings mounts Secure RX in cooler with M1.6x5mm...
- Page 7 Street kart assembly Street kart assembly Secure cooler and cooler mount Secure steering wheel base with M1.6x4mm screws. with self adhesive tape to the servo. Secure cooler to the left Glue two parts of steering rear axle bearing mount wheels with CA glue. with M1.6x6mm screws.
- Page 8 Street kart assembly Street kart assembly Secure exhaust with Secure battery holder standoffs and M1.6x4mm screw. battery pad to the lower plate with Exhaust needs to M1.6x6mm screws. be printed separately in vase mode. Secure battery holder to Place front bodywork to its place. the printed or brass standoffs with M1.6x6mm...
- Page 9 Street kart assembly Street kart assembly Secure front bodywork with Insert M2.0x14mm screws as front M1.6x3mm M1.6x6mm axles. Use small piece of screws. tape or thread to achieve perfect fit of screws in bearings without wobble. Insert two 2x5x2,5mm bearings Cut 2mm brass rod to in each spindle.
- Page 10 Street kart assembly Street kart assembly Prepare all tires. Secure rear rims with M1.6x6mm screws. Insert rims to the tires. Install front wheels on M2.0x14mm Fitment should be screws and secure them with M2.0 without any tolerance. nuts. Wheels should spins freely but without wobble.
- Page 11 Street kart assembly Street kart assembly Secure rear wheels with Install battery. M1.6x3mm screws. The screw tip should touch the notch on the axle to fix it on place. Use rubber orings to achieve Done! Enjoy your new street kart, great athesion and silent riding because it will never be as clean as at experience.
