ROMANOFF Yasui RBF 32/21 Product Manual

Rotating burnout furnace
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT MANUAL
SINCE 1949
RBF 32/21
ROTATING BURNOUT FURNACE
OPERATIONS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Yasui RBF 32/21 and is the answer not in the manual?

Questions and answers

Related Manuals for ROMANOFF Yasui RBF 32/21

Summary of Contents for ROMANOFF Yasui RBF 32/21

  • Page 1 PRODUCT MANUAL SINCE 1949 RBF 32/21 ROTATING BURNOUT FURNACE OPERATIONS MANUAL...

  • Page 2: Table Of Contents

    RBF 32/21 Instruction Manual SKU: 77-021 CONTENTS 1. INTRODUCTION ........................5 1-1. SAFETY PRECAUTIONS ....................5 1-2. SAFETY INFORMATION ....................5 1-3. PASSWORD ........................7 1-3-1. KIND OF PASSWORD ....................7 1-3-2. ISSUE OF PASSWORD .................... 8 1-4. SPECIFICATION LABEL ....................9 1-5.
  • Page 3 RBF 32/21 Instruction Manual SKU: 77-021 4-1-1. Tap FLASK INFO tab ....................23 4-1-2. Details ........................23 4-1-3. MANUAL / AUTOMATIC ..................24 4-1-4. Change memory number ..................24 4-1-5. SET POSITION ......................24 4-1-6. MANUAL ROTATION ....................25 4-1-7. PRESENT POSITION ....................25 4-1-8.
  • Page 4 RBF 32/21 Instruction Manual SKU: 77-021 5-8. LOG & HISTORY ......................41 6. WHEN IRREGULARITY HAPPENED ................. 42 6-1. ERROR MESSAGES ......................42 6-2. ERROR CODE LIST .......................43 6-3. BLACKOUT ........................45 6-4. OVERHEAT PROTECTION FUNCTION .................48 6-4-1. CHOICE OF SETTING ..................... 48 6-4-2.

  • Page 5: Introduction

    RBF 32/21 Instruction Manual SKU: 77-021 1. INTRODUCTION 1-1. SAFETY PRECAUTIONS Three safety precautions are described in this instruction manual to avoid risks on human body during operation. Be sure to read these precautions before using our products. Each meaning as follows; DANGER: Indicates a high-risk hazard.
  • Page 6 RBF 32/21 Instruction Manual SKU: 77-021 DANGER 1. Since this product generates very high temperature (more than 900 degrees Celsius), always pay attention not to suffer burns. Do not allow unskilled or untrained person to operate this product. Person who does not pay attention is highly possible to suffer serious burns. 2.

  • Page 7: Password

    RBF 32/21 Instruction Manual SKU: 77-021 CAUTION 1. Periodically, check and clean the rotation driving parts. Remove wax on the bearing system. Rotation can be suspended by wax and rust sticking which lead over load at each driving part. 2. Do not try to cool inside of the furnace forcibly and very rapidly using a fan. Particularly, if forced at high temperature, the door frame material may be cracked or deformed.

  • Page 8: Issue Of Password

    RBF 32/21 Instruction Manual SKU: 77-021 2) Monthly update password In case this product is used by monthly use conditions, this password is necessary on or after the first day of the month to which the next monthly calculation starting time belongs. Monthly calculation starting time is 0:00 a.m.

  • Page 9: Specification Label

    RBF 32/21 Instruction Manual SKU: 77-021 1-4. SPECIFICATION LABEL 1) The principal specifications label of this product is affixed on the right side of RBF32/21. Apply power specified voltage printed on the label. Should any voltage exceed beyond the specified voltage, the manufacturer is not responsible to guarantee performance of RBF32/21. 2) When ordering spare parts, specify the production serial number that is printed on that label.
  • Page 10 RBF 32/21 Instruction Manual SKU: 77-021 IMPORTANT - The manufacturer shall in no event be liable for any damage resulting from improper use, negligence to follow the warnings and cautions in the instructions manual or the labels on this product, unskillfulness, use of non-original optional / consumable accessories / spare parts, non-authorized modification.

  • Page 11: Nomenclature

    RBF 32/21 Instruction Manual SKU: 77-021 2. NOMENCLATURE 2-1. FRONT VIEW Afterburner Dew protection Eave Electric component Cover LCD Control panel ALL STOP button Power lamp Breaker switch Door handle Door Level adjuster...

  • Page 12: Operation Panel

    RBF 32/21 Instruction Manual SKU: 77-021 2-2. OPERATION PANEL MAIN DISPLAY START BUTTON STOP START STOP BUTTON USB SLOT ALL STOP TURN TABLE BUTTON ROTATION button STOP STOP POWER ALL STOP POWER LAMP BREAKER SWITCH...

  • Page 13: Operation

    RBF 32/21 Instruction Manual SKU: 77-021 3. OPERATION 3-1. AUTOMATIC OPERATION AUTOMATIC OPERATION can be processed as follows; Turn breaker ON → Choose MEMORY No. → Put flasks into furnace → Check TOTAL TIME to decide time to start → Push start button IMPORTANT DO NOT TURN BREAKER SWITCH ON UNLESS YOU REMOVE PACKING MATERIALS FOR TRANSPORTATION INSIDE OF FURNACE BODY.

  • Page 14: Choose Recipe

    RBF 32/21 Instruction Manual SKU: 77-021 3-1-2. CHOOSE RECIPE Tap MEMORY button to open SERCH window to choose recipe. Tap one of recipes at this window and tap OK button. 3-1-3. PUT FLASKS INSIDE You can call any position youprefer automatically for each flask.

  • Page 15: Burn Out

    RBF 32/21 Instruction Manual SKU: 77-021 Confirm burnout cycle is what you expect and push start switch. The present back ground color will turn pink. 3-1-5. BURN OUT Wait for burnout cycle finishes. You can check how much time passed from temperature reach down to casting point here at this window.

  • Page 16: Stop Operation

    RBF 32/21 Instruction Manual SKU: 77-021 2) Rotation will stop at the point you’ve entered. The present back ground color will turn green. This is to prevent leaving rotation suspended. Do not forget to push rotation button for 2 seconds after taking flask out of furnace to continue. The back ground color will turn pink.

  • Page 17: How To Program Recipe Memories

    RBF 32/21 Instruction Manual SKU: 77-021 2) Tap OK button 3) Turn breaker switch OFF when you see the pop up window. 3-2. HOW TO PROGRAM RECIPE MEMORIES 3-2-1. EDIT TEMPARATURE 1) Tap MEMORY No. button. 2) Tap MEMORY No.01 for instance. 3) Tap OK button after that.
  • Page 18 RBF 32/21 Instruction Manual SKU: 77-021 Au_and_Ag 14:30 2:00 0:30 2:00 0:30 2:00 0:30 1:00 1:00 2:30 0:30 2:00 Final 5) If you want to change Temperature at STEP1, 230c to 250c, Tap the CELL marked as above. 6) You will see a keyboard activated. 14:30 Au_and_Ag 2:00...

  • Page 19: Edit Other Factors

    RBF 32/21 Instruction Manual SKU: 77-021 3-2-2. EDIT OTHER FACTORS You can edit other factors like ELV TIME, KEEP TIME by the same manner as described already. (See page 29 for detail) 3-2-3. ADD and DELETE STEP(s) 1) When you want to add one additional line (step). Tap blank cell next to Final cell marked as below. 14:30 Au_and_Ag 2:00...

  • Page 20: Manual Operation

    RBF 32/21 Instruction Manual SKU: 77-021 3-3. MANUAL OPERATION 3-3-1. POWER ON AT BREAKER SWITCH Turn breaker switch ON. Wait for the GRAPH / LIST display shown. 3-3-2. SWITCH MODE Tap FLASK INFO button Tap MANUAL button PRESENTTEMP button to edit. 3-3-3.

  • Page 21: Take Flask Out For Casting

    RBF 32/21 Instruction Manual SKU: 77-021 3-3-4. TAKE FLASK OUT FOR CASTING 1) Tap SET POSITION button to edit the value. 2) Rotation will stop at the point you’ve entered. The present back ground color will turn green. This is to prevent leaving rotation suspended. Do not forget to push rotation button for 2 seconds after taking flask out of furnace.

  • Page 22: Power Off

    RBF 32/21 Instruction Manual SKU: 77-021 3-3-6. POWER OFF 1) Tap LOG OFF tab 2) Tap OK button 3) Turn breaker switch OFF when you see the pop up window 3-4. ALL STOP BUTTON Push ALL STOP button in front of control box, when you want to suspend all of the function. Nothing can be operated on this condition.

  • Page 23: Description Of Each Window

    RBF 32/21 Instruction Manual SKU: 77-021 4. DESCRIPTION of EACH WINDOW 4-1. FLASK INFO window 4-1-1. Tap FLASK INFO tab to open. 4-1-2. Details Memory No. edit button Button for setting position of turn table Choice of MODE Shows positioon Presentvalue showing TIME AFTER TARGET...

  • Page 24: Manual / Automatic

    RBF 32/21 Instruction Manual SKU: 77-021 4-1-3. MANUAL / AUTOMATIC 1) You can choose mode AUTOMATIC or MANUAL by tapping buttons directly. 2) MEMORY No. will not be indicated when MANUAL mode is chosen. 4-1-4. Change memory number 1) Tap memory No. button. 2) choose memory from the list.

  • Page 25: Manual Rotation

    RBF 32/21 Instruction Manual SKU: 77-021 4-1-6. MANUAL ROTATION You can also rotate and stop turn table by manual. Push one of two buttons on control panel down for more than 2 seconds for continuous rotation. Rotation starts and continues after finger released until you push one of two buttons again. TURN TABLE ROTATION button While pushing one of two buttons a short time for...

  • Page 26: Time After Target

    RBF 32/21 Instruction Manual SKU: 77-021 4-1-9. TIME AFTER TARGET This informs you how long it passed from the point when temperature reaches final level. The display shows set temperature curve in red, while actual curve is shown in yellow. You will know ideal time for final casting level by this.

  • Page 27: Details

    RBF 32/21 Instruction Manual SKU: 77-021 4-2-2. Details Present position of turn Heating pilot table lamp MEMORY No.display and edit Present Positioning button Tap this button to edit. temperature Tap this to activate keyboard. Result will be displayed here. 00:00 12:30 00:00 LIST button...

  • Page 28: Memory No

    RBF 32/21 Instruction Manual SKU: 77-021 00:00 12:30 00:00 MEMORY > LIST 4-2-7. MEMORY No. MEMORY Number is displayed here and can be edited. 4-2-8. TIME AFTER TARGET 00:00 Already described in previous page. 12:30 4-2-9. TOTAL TIME TOTAL TIME of each parameter of MEMORY, ELV TIME + KEEP TIME, to calculate time of starting 12:30 4-2-10.

  • Page 29: List Window (Tap List Button To Jump →)

    RBF 32/21 Instruction Manual SKU: 77-021 4-3. LIST window (tap LIST button to jump →) Memory No. edit button COMMENT edit button Valid only at AUTO mode. Selected COMMENT is indicated here. The window will turn Memory search Can be edited with keyboard by window when this button is tapped.

  • Page 30: Memory Number Edit Button

    RBF 32/21 Instruction Manual SKU: 77-021 4-3-1. MEMORY Number edit button The window will turn Memory search window when this button is tapped (Only at AUTO mode) 4-3-2. COMMENT button Selected COMMENT is indicated here. You can register and edit comment here with keyboard by tapping this button. 4-3-3.

  • Page 31: Config

    RBF 32/21 Instruction Manual SKU: 77-021 4-4. CONFIG Will be described later. 4-5. LOG OFF 1) Tap LOG OFF tab before turning breaker OFF. 2) Tap OK button 3) Turn breaker switch OFF when you see this pop up window...

  • Page 32: Config Menu

    RBF 32/21 Instruction Manual SKU: 77-021 5. CONFIG MENU You have several configuration menus in this page. ＜How to open CONFIG menu window＞ 1) Tap CONFIG tab to open the window. CONFIG window ＜About each icon＞ MACHINE You can check machine information like its serial number and several program versions. COPY/CLEAR You can copy chosen recipe to minimize time for programming.
  • Page 33 RBF 32/21 Instruction Manual SKU: 77-021 SECURITY You can protect existing recipe details so that nobody can edit. You can also change password for protection here. DATE & TIME You can set calendar and clock at your region. DISPLAY You can control display setting here. PAYMENT PASSWORD You can enter Passwords for Monthly payment here.

  • Page 34: Machine

    RBF 32/21 Instruction Manual SKU: 77-021 5-1. MACHINE You can check machine information like its serial number and several program versions. ＜How to open “MACHINE” window＞ 1) Tap CONFIG tab to open CONFIG menu. 2 ) Tap MACHINE icon to open. [ VERSION ] You can check program version information here.
  • Page 35 RBF 32/21 Instruction Manual SKU: 77-021 2) Tap COPY icon to open. [ COPY ] 1) Multiple copy - When you want to create many copies of one specific recipe. (below) 2) Single copy - When you want to create just one copy. button - You can copy all of memories in the system to USB flash drive.

  • Page 36: Security

    RBF 32/21 Instruction Manual SKU: 77-021 5-3. SECURITY You can protect recipe data and edit password for recipe protection. ＜How to open “SECURITY” window＞ 1) Tap CONFIG tab to open CONFIG menu. 2) Tap SECURITY icon to open. [ LOCK ] - You can lock the recipes you choose.

  • Page 37: Display

    RBF 32/21 Instruction Manual SKU: 77-021 2) Tap DATE & TIME icon to open. - Tap blank to open keyboard to enter date and time. - Tap SET button to finish. 5-5. DISPLAY You can switch suspension power ON or OFF; adjust brightness. ＜How to open ”DISPLAY”...

  • Page 38: Payment Password

    RBF 32/21 Instruction Manual SKU: 77-021 4) BRIGHTNESS You can adjust the brightness of display. button to decrease, tap button to increase. You can also long tap for continuous adjusting. Direct entering value by keyboard can be also done. The range is 0 -100% 5) MEASUREMENT SYSTEM You can change temperature measurement system here.

  • Page 39: Maintenance

    RBF 32/21 Instruction Manual SKU: 77-021 ＊ WHAT IS MONTHLY PAYMENT? Monthly payment system is a method to have you pay just like credit every month to distributor. You need to pay credit every month to get password as RBF 32/ 21 will be locked by system after payment deadline.
  • Page 40 RBF 32/21 Instruction Manual SKU: 77-021 Descriptions on MAINTENANCE window Category1 Category2 Description SWITCH START START switch ON/OFF monitor STOP STOP switch ON/OFF monitor ← Rotation switch ON/OFF monitor → Rotation switch ON/OFF monitor DOOR DOOR switch ON/OFF monitor PHOTO Original position of PHOTO SENSOR for rotation ON/OFF monitor SENSOR Present position sensor ON/OFF monitor...

  • Page 41: Log & History

    RBF 32/21 Instruction Manual SKU: 77-021 5-8. LOG & HISTORY ＜How to open ” LOG & HISTORY ” window＞ 1) Tap CONFIG tab to open CONFIG menu. 2) Tap LOG & HISTORY button to open. You can check machine log when problem happened. It is very difficult to communicate about problems on this product.

  • Page 42: When Irregularity Happened

    RBF 32/21 Instruction Manual SKU: 77-021 6. WHEN IRREGULARITY HAPPENED 6-1. ERROR MESSAGES RBF shows messages when something irregularity happens. You cannot operate RBF while Error message is displayed. Example of error message 1) Error code 3) Error detail 2) Error icon 4) Remedy 5) OK button 1) Error code...

  • Page 43: Error Code List

    RBF 32/21 Instruction Manual SKU: 77-021 6-2. ERROR CODE LIST Error Description How to recover Level code Cause Remarks E0100 Error Thermocouple of main heater defective. Replace thermocouple. E0101 Error Main heater defective. Replace heater coil. Thermocouple of main heater incorrect E0102 Warning Replace heater coil.
  • Page 44 RBF 32/21 Instruction Manual SKU: 77-021 E9037 Error I/O initialize error. Reboot system or replace PCB. E9055 SYSTEM USB flash drive 1 broken. Replace System USB1. Warning E9056 SYSTEM USB flash drive 2 broken. Replace System USB2. Data copy to replaced new drive will begin. Wait for copy finishing and normal reboot (takes E9057 long time) and replace broken drive after that.

  • Page 45: Blackout

    RBF 32/21 Instruction Manual SKU: 77-021 6-3. BLACKOUT If electric power supply failed, control system reacts as follows; 1) MANUAL BURNOUT MODE When electric power supply is restored, this product does not resume heating automatically. Check setting value of temperature. Press START key, so that this product will resume its running. 2) AUTOMATIC BURNOUT MODE (blackout and recovery before the set time of Step 1) In case blackout happened during standing by and restored before start time of Step 1, this product resumes its running when power supply is restored.
  • Page 46 RBF 32/21 Instruction Manual SKU: 77-021 4) AUTOMATIC BURNOUT MODE (during burnout cycle time within 5 minutes) When electric power supply is restored, this product automatically resumes its running from the point where blackout occurred. Blackout within 5 minutes Time standing by STEP 2 STEP 1 STEP 3...
  • Page 47 RBF 32/21 Instruction Manual SKU: 77-021 5) AUTOMATIC BURNOUT MODE (during burnout cycle time for over 5 minutes) When electric power supply is restored, this product automatically resumes its running from the point where blackout occurred. The time lost will be resumed and burnout cycle will be delayed for the time equal to blackout time period.

  • Page 48: Overheat Protection Function

    RBF 32/21 Instruction Manual SKU: 77-021 6-4. OVERHEAT PROTECTION FUNCTION CAUTION Overheating can break molds, stones in molds and even this product. Try to set temperature with utmost attention. 1. Be sure to check setting temperature of this function before startup. Change it if necessary. 2.

  • Page 49: Edit Of Setting Temp

    RBF 32/21 Instruction Manual SKU: 77-021 * The default setting is LIMIT C. You can change if necessary * You will see an error message when startup if temperature is set in recipe higher than the LIMIT chosen. Change MEMORY, LIMIT, or Edit recipe to re-start. 6-4-2.
  • Page 50 RBF 32/21 Instruction Manual SKU: 77-021 Tap one of LIMIT to callten keys and edit. Tap OK button to enter. We strongly recommend you to maintain default value for MARGIN. IMPORTANT The manufacturer shall in no event be liable for any consequential or indirect damages including, but not limited to, loss of production or loss of profit (including burnout for normal precious metal casting, for stone-in-wax casting and etc.) or damages due to machine downtime.

  • Page 51: Installation

    RBF 32/21 Instruction Manual SKU: 77-021 7. INSTALLATION 7-1. UNPACKING Open the door, and remove cushioning material between turntable and heater panel. (Do not give unnecessary strong force at this part, otherwise heater surface may be damaged.) 7-2. MAIN UNIT CAUTION 1.

  • Page 52: Afterburner

    RBF 32/21 Instruction Manual SKU: 77-021 7-3. AFTERBURNER WARNING 1. Be sure to turn power off before installation. There might be an electric shock by high-voltage current. 2. Wiring should be made by a qualified technician under correct method. There might be electric contacts molten down or a fire caused by it.
  • Page 53 RBF 32/21 Instruction Manual SKU: 77-021 3) Place honeycomb cover in position passing cables through its holes as below figures.
  • Page 54 RBF 32/21 Instruction Manual SKU: 77-021 4) Connect the cable for sheath heating element to terminal block for afterburner. 5) Repeat the above 1) to 4) for other two afterburner sheath heating elements. 6) Insert the tip of thermocouple tube into the hole for thermocouple as below figures. 7) Fix 2 parts with included saddles like this.
  • Page 55 RBF 32/21 Instruction Manual SKU: 77-021 IMPORTANT The position of thermocouple is important to avoid short life of thermocouple and heater or poor effect of burning smoke. Protruding length should be adjusted to approx. 10mm. 8) Place afterburner onto the top of RBF32/21 main body. Connect cables for afterburner from built-in power control box of RBF32/21 main body as the figures below and in the next page.
  • Page 56 RBF 32/21 Instruction Manual SKU: 77-021 9) Fix afterburner body with fixation plates and bolts. 10) Attach terminal block cover of afterburner body. 11) Place dew protection pan, so that weep hole should be positioned at the front left. Let each gap fit on eye bolts. Attach hose onto weep hole (hose is not included). Drain eye bolt 12) Be sure to assemble adiabatic and dew protection board for afterburner as the figure.

  • Page 57: Connecting Power Supply

    RBF 32/21 Instruction Manual SKU: 77-021 7-4. CONNECTING POWER SUPPLY Connect this product to power source AC 220V, three phase. WARNING 1. Connect to specified power supply only. 2. Be sure to connect ground wire to avoid electrical shock hazards. 3.

  • Page 58: Exhaust System

    RBF 32/21 Instruction Manual SKU: 77-021 7-6. EXHAUST SYSTEM Install equipment for exhaustion such as exhaust duct (not provided from manufacturer). CAUTION 1. Building of exhaust system should be done by a qualified technician. 2. Use noncombustible material. 3. Install high power fan suitable for exhaust of fumes. 4.
  • Page 59 RBF 32/21 Instruction Manual SKU: 77-021 Fan of proper capacity Use noncombustible material for ceiling Hood should cover whole machine whole machine...

  • Page 60: Drain Orifice

    RBF 32/21 Instruction Manual SKU: 77-021 7-7. DRAIN ORIFICE The drain orifice is used for limiting the amount of air which flows inside the furnace. Remove and clean the drain orifice every day. Rear Turntable Drain orifice Wax receiver Front Drain orifice Front Rear...

  • Page 61: Maintenance

    RBF 32/21 Instruction Manual SKU: 77-021 8. MAINTENANCE Check operating conditions periodically, so that this product can always be used in good condition. Especially, perform the following maintenance work periodically. 8-1. CLEANING FILTER FOR COOLING FAN CAUTION It is recommended to clean filter every work day, although cleaning cycle depends on frequency of use and work environment.

  • Page 62: Checking Crack Of Adiabatic Material

    RBF 32/21 Instruction Manual SKU: 77-021 CAUTION If wax is not drained smoothly (a large amount of wax remains inside the furnace) because of clogging etc., a large amount of gas over combustion capability of afterburner may be generated, and incomplete combustion gas (black gas) may blow out from exit of afterburner.

  • Page 63: Spare Parts List

    RBF 32/21 Instruction Manual SKU: 77-021 9. SPARE PARTS LIST Name of part Item number Heater panel, rear 13310207 Heater panel, left and right 13310210 Upper heat insulator board on bottom, rear 13310208 Upper heat insulator board on bottom, left and 13310211 right Door blanket upper...

  • Page 64: Specifications

    RBF 32/21 Instruction Manual SKU: 77-021 ADHESIVE (1) Inorganic adhesive 150g ARONCERAMIC 13073600 for repairing crack f. frame/slab. ADHESIVE (2) 13074100 Coating cement QF-180 500ml for blanket. 10. SPECIFICATIONS Power source AC 220 V 10%, 50/60 Hz, three phase ± Power consumption 16.2 kVA (including afterburner) Setting range of temperature...
  • Page 65 RBF 32/21 Instruction Manual SKU: 77-021...
  • Page 66 RBF 32/21 Instruction Manual SKU: 77-021 Date Name Edition Description 2021/7/7 Shindo M00-00E edition. 内 容 詳 細 Page 表 紙 画 像 差 替 え 画 像 差 替 え 2 - 1 . 画 像 差 P5, 6,11,12 替...
