3nStar PTE0912 User Manual

Point of sale system i5 12th generation
Hide thumbs

Advertisement

Quick Links

Download this manual
USER MANUAL
PTE0912
Point of Sale System i5 12
Generation
th

Advertisement

loading
Need help?

Need help?

Do you have a question about the PTE0912 and is the answer not in the manual?

Questions and answers

Summary of Contents for 3nStar PTE0912

  • Page 1 USER MANUAL PTE0912 Point of Sale System i5 12 Generation...
  • Page 2 3nStar Inc. Information provided in this manual is intended to be accurate and reliable. However, 3nStar Inc. assumes no responsibility for its use, nor for any infringements upon the rights of third parties, which may result from its use.
  • Page 3 Table of Contents 1. Introduction Quick Start Guide 004 - 004 Introduction 005 - 006 Terminology & Tools 006 - 008 Dimensions 008 - 009 Specification 009 - 010 2. Assembly Single Hinge Stand 011 - 013 Add-on Devices 014 - 015 3.
  • Page 4 Quick Start Guide...
  • Page 5 Introduction PTE0912 is a 15inch panel pc based on Intel’s 12 generation Alder Lake CPU.
  • Page 6 Terminology and Tools Smart DD: This is a proprietary port that can support two Smart DD monitors daisy chaining. This port utilizes a USB-C connector but it is NOT compatible with previous generation USB-C (USB DP) ports. Contact your sales represenative for additional information.
  • Page 7 Some of these tools may be used for the assembly.
  • Page 8 Dimensions...

  • Page 9: Specification

    Specification Note: This model does not support VPro or iAMT. Contact your 3nStar sales representative for other qualifying products.
  • Page 11 Assembly Single Hinge Stand Note: This is a general reference assembly guide, the actual display back cover may not match your product. It will not matter to the assembly. Tools Needed: You will need to prepare a screwdriver in order to assemble the stand. Items Included: Panel PC with Part A of the stand attached.
  • Page 12 STEP 2: Remove the stand cable cover by sliding it down (left image) then lift it away (right image). STEP 3: Lift up the angle of Part A of the stand. STEP 4: Align Part B of the base with Part A of the base as shown. While holding the base together with one hand. Use your hand to slightly fasten the screws .
  • Page 13 STEP 5: Place the stand in the upright position (left image) then use the screwdriver to fasten the two screws (right image). STEP 6: Place the stand cable cover back on the stand. Then assembly is complete.
  • Page 14 Add-on Device Note: This is a general reference assembly guide, the actual display back cover may not match your product. It will not matter to the assembly. Tools Needed: You will need to prepare a screwdriver in order to assemble the add-on device. Items Included: Panel PC with Part A of the stand attached.

  • Page 15: Software Installation And Setup

    STEP 3: Fasten the two screws. Complete. Software Installation and Setup For the most up to date drivers, go to https://www.3nStar.com Follow the below order if installation for the Motherboard: ①Chipset ②Audio ③Graphics ④Intel® ME ⑤Setup Serial IO ⑥LAN ⑦Sensor 1.
  • Page 16 • Click [ Install ] • Click [ Yes ] • Click [ Restart Now ]...
  • Page 17 2. Audio • Double click [ Setup ] • Click [ Yes ] • Click [ Yes, I want to restart my computer • Click [ Next ] now ], [ Finish ]...
  • Page 18 3. Graphics • Double Click [ Installer.exe ] • Click [ Yes ] • Click [ Next ] • Click [ Next ] • Click [ Finish ]...
  • Page 19 4. Intel® ME • Double Click [ DPInst64.exe] • Click [ Next ] • Accept Terms then click [ Next ] • Click [ Next ] • Click [ Yes ] • Click [ Finish ]...
  • Page 20 5. Serial IO • Double Click [ SetupSerialIO.exe ] • Click [ Next ] • Accept terms then click [ Next ] • Click [ Next ] • Click [ Next ] • Select Yes, I want to restart this computer now the click [ Finish ]...
  • Page 21 6. LAN • Double Click [ Setup] • Click [ Yes ] 7. Sensor • Double Click [ install ] • Click [ Yes ]...
  • Page 22 Press any key to continue … Cash Drawer Command...

  • Page 23: Bios Introduction

    BIOS Introduction Enter the BIOS by pressing delete during system boot.

  • Page 24: Accessing The Memory

    Enable and Disable Ambient Light and Proximity Sensor in BIOS Step 1: Start up the system Step 2: Press [ Delete ] during startup to enter BIOS Step 3: Under Advanced > Sensor Device Configuration click Disabled to turn off, Sensor 1 to turn on proximity and ambient light sensor.
  • Page 25 STEP 2: Remove the bottom cover. STEP 3: Lift up the panel module which will automatically release the sensor FFC cable.
  • Page 26 M.2 Tray with Screw x 1 M.2 (PCIe Gen III) x 1 (This can be purchased from 3NSTAR or otherwise) STEP 1: Get thermal pad from the accessory box. Remove the plastic and place the thermal pad on to the...
  • Page 27 STEP 2: Slide the M.2 into the tray. STEP 3: Fasten the screw. Complete. Note: Make sure the system is off when inserting the M.2 tray into the socket.
