Yatai PKC1 Series Operating Instruction

PKC1 系列（
智能型数位式功率调整器
Intelligent Digital Power Regulator
使用说明书
Operating Instruction
上海亚泰仪表有限公司
Shanghai Yatai Instrumentation CO., Ltd
）
Series
非常感谢您采用亚泰 PKC1 系列智能型数位式功率调整器， 使用前务必详读本使用说明书以防止操作错误！
Thank you very much for choosing Yatai PKC1 series intelligent digital power regulator， Please read this operating
instruction carefully before using it to avoid malfunction！
操作注意事项/Caution When Operating
● 断电后方可清洗控制器/Before cleaning the controller, please ensure that the power is switch off
● 清除显示器上污渍请用软布或棉纸/Please remove stains on the display panel by using a soft cloth only
● 显示器易被划伤，禁止用硬物擦拭或触及/No scrubbing or touching the display panel with any hard object,
the display panel can be easily scratched
● 禁止用螺丝刀或书写笔等硬物体操作面板按键，否则会损坏或划伤按键/Do not press any button on the
display panel using pointy objects such as ballpoint pen or screw driver, it can easily scratch the panel or
damage buttons on the panel
一、产品确认/Product validation
PKC1 智能型数位式功率调整器是用先进的单片机技术设计而成的，是新一代的用可控硅控制正弦波波
形导通大小/多少从而达到控制交流电压输出大小的控制器，并具有以下特点/PKC1 Intelligent Digital
Power Regulator is using advanced single-chip design, it is the new generation regulator providing control solution
for power-conversion application by using SCR to control the sine wave：
■ 产品信息
● 采用高级数字化单片机作为控制核心，有丰富的参数设定、检测和完善的保护功能
Microcontroller is used as the key with parameter set-up、test and protect functions
● LED 数码管显示、键盘参数设置、操作方便
LED display and key configuration are easy to operate
● 10 位精度的 AD 转换、分辨率高、线性度好
10 bits AD conversion，high resolution with high linearity
● 12 位精度的 DA 输出、最小模拟量输出值可设定
12 bits DA output accuracy、the minimum value of the analog output can be set
● 输入、输出接口均采用隔离技术、安全及抗干扰能力强
Input and output port are both using secure、jam-proofing isolation technology
● 采用宽触发脉冲提高触发控制信号的可靠性
Wide trigger pulse to improve reliability of control signal
● 集成开环、恒压、限压、恒流、限流等可选择功能，控温精度高、效果好
Integration of open-loop、 constant pressure、 limited pressure、 constant current、 limited current which can
be selected, high precision of temperature control
● RS485 通讯接口、采用标准的 MODBUS 协议的 RTU 模式
RS485 communication port、support standard MODBUS protocol RTU mode
■ 功能信息/Functions
● 电源频率 50/60 Hz 自动侦测 Power frequency 50/60 Hz auto-detect
● 可选择过零或相位控制方式 Zero cross control or phase angle control selectable
● 可选择自动或手动输出 Auto output or manual output selectable
● 可选择多种输入方式 Multi-input type optional
● 可设定相位控制时起始输出电压 Configurable starting output voltage of phase control
Configurable maximum and minimum output limit
● 可设定最小或最大输出量限制
Configurable soft start or kick start time
● 可设定缓冲启动或脉冲启动时间
Voltage/Current feedback detection function
● 电压/电流反馈检测功能
● 部分功能可通过外部开关操作 Some functions can operate through external switch
● 多种自动诊断警报功能 Multi automatic diagnostic alarm function
