Model Number:

Manual

Revision:

SXE16V1

Document Catalog Number:

Setcan Corp.

Authorship:

Stressvest

F o r c e o n F o r c e R e i n v e n t e d

1080 Kingsbury Avenue

Winnipeg, Manitoba

Canada

R2P 1W5

1-(866)-353-5055

Effective Date:

2018/OCT/02

1.2

16-0001.XX

User Guide

Visit our Website at www.stressvest.com

Table of Contents

Need help?

Do you have a question about the StressVest StressX Elite and is the answer not in the manual?

Questions and answers

Summary of Contents for Setcan StressVest StressX Elite

Page 1 Effective Date: Revision: SXE16V1 2018/OCT/02 16-0001.XX Document Catalog Number: Setcan Corp. Authorship: User Guide Stressvest F o r c e o n F o r c e R e i n v e n t e d 1080 Kingsbury Avenue Visit our Website at www.stressvest.com...
Page 2 Setcan Corp. The information furnished herein is believed to be accurate and reliable. However, no responsibility is assumed by Setcan Corp for its use, or for any infringements of patents or other rights of third parties resulting from its use.
Page 3 Original Purchaser and the product that you purchased is not covered by this warranty. What is covered: This Product includes a Stressvest StressX Elite Controller, an Arm Shocker, a Belt • Shocker, fabric mounting case and Accessory Items. Accessory Items include but are not limited the carrying case if purchased.
Page 4 Setcan Corporation Mail the defective StressVest® including Stressvest StressX Elite Controller, an Arm Shocker, a Belt Shocker, fabric mounting case and Accessory Items with postage prepaid together with a photocopy of your bill of sale and written description of the defect to: Setcan Corporation, 1080 Kingsbury Avenue, Winnipeg, Manitoba, Canada, R2P 1W5, Attn: Warranty Department.
Page 5 NOTWITHSTANDING ANY FAILURE OF ESSENTIAL PURPOSE OF ANY EXCLUSIVE REMEDY PROVIDED HEREIN. SOME STATES DO NOT ALLOW FOR THE LIMITATION OR EXCLUSION OF LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL StressVest® is a Registered trademark of Setcan Corporation. Patents: U.S. Patent, Patents Pending and International Patents Pending Document: User Guide StressX Elite rev_1.2 (10-02-2018).doc...
Page 6 User Guide StressX Elite rev_1.2 (10-02-2018).doc WARNINGS, RISKS AND LIABILITIES IMPORTANT STRESSVEST® PRODUCT SAFETY AND HEALTH INFORMATION   Read and understand the following before handling or using the StressX Elite and related products. Prior to utilizing the StressX Elite system, all individuals participating in StressX Elite training or exposure, should receive proper training in it’s safe use by a certified StressX Elite instructor or master instructor.
Page 7 User Guide StressX Elite rev_1.2 (10-02-2018).doc physiologic and metabolic effects. In human studies of electrical discharge from a single Electrical Discharge of up to 15 seconds, the effects on acidosis, CK, electrolytes, stress hormones, and vital signs have been comparable to or less than changes expected from physical exertion similar to struggling, resistance, fighting, fleeing, or from the application of some other force tools or techniques.
Page 8 User Guide StressX Elite rev_1.2 (10-02-2018).doc Reasonable efforts should be made to minimize the number of Electrical Discharge exposures. StressX Elite instructors should use the lowest number of Electric Discharge exposures that are objectively reasonable to accomplish the training objective. Incapacitation, Falling, and Startle Hazard.
Page 9 StressX Elite manufacturer, the StressX Elite distributor, Setcan Corporation and all of its agents, directors and employees for any damages, costs, loss or injury arising out of any and all activities during the StressX Elite Electric Discharge Exposure. ...
Page 10 User Guide StressX Elite rev_1.2 (10-02-2018).doc inherent in this agreement. StressX® Elite is owned and operated by Setcan Corporation 1080 Kingsbury Avenue, Winnipeg, MB, Canada R2P 1W5 Fax: (204)-586-2049 Phone: 1-(204)- 336-0011. PROHIBITED FROM PARTICIPATING IN STRESSX ELITE TRAINING The following individuals are prohibited from participating in training using the StressX Elite system: Any person whom is not a legal adult or does not have the mental capacity to understand •...
Page 11 User Guide StressX Elite rev_1.2 (10-02-2018).doc Page Intentionally Left Blank Document: User Guide StressX Elite rev_1.2 (10-02-2018).doc 10/2/2018 Page 11 of 38...
Page 12: Table Of Contents
User Guide StressX Elite rev_1.2 (10-02-2018).doc Table of Contents 1. Introduction to Guide ....................14 1.1. Important ............................14 1.2. Scope ............................14 1.3. Product ............................14 1.4. StressX Elite Safety ........................15 2. Overview of StressX Elite Package ................. 17 2.1.
Page 13 User Guide StressX Elite rev_1.2 (10-02-2018).doc 7. Cleaning and Maintenance ..................34 7.1. Cleaning the StressX Elite ......................34 7.2. Storing the StressX Elite ....................... 34 7.3. Maintenance (Software updates) ....................35 8. Saab® Integration Device (Optional) ............... 36 8.1. Nomanclature of the Saab®...
Page 14: Introduction To Guide
User Guide StressX Elite rev_1.2 (10-02-2018).doc 1. Introduction to Guide 1.1. Important All purchasers and/or users of the StressX Elite must first read and understand the Warnings, Risks and Liabilities associate with the StressX Elite prior to using the product. The Warnings, Risks and Liabilities can be found on Page 6, 7, 8, 9 &...
Page 15: Stressx Elite Safety
User Guide StressX Elite rev_1.2 (10-02-2018).doc 1.4. StressX Elite Safety NEVER place the shocker on any other location on the body other than the abdomen and upper, outer arm. PLACE SHOCKERS ONLY IN SAFE AREA SPECIFIED ABOVE. Document: User Guide StressX Elite rev_1.2 (10-02-2018).doc 10/2/2018 Page 15 of 38...
Page 16 User Guide StressX Elite rev_1.2 (10-02-2018).doc NEVER touch the electrodes on any of the shocking devices with the hands or fingers. DANGER! DO NOT TOUCH ELECTRODES WITH HANDS OR FINGERS NEVER place the one shocker on one arm and the other shocker on the other arm. Document: User Guide StressX Elite rev_1.2 (10-02-2018).doc 10/2/2018...
Page 17: Overview Of Stressx Elite Package
User Guide StressX Elite rev_1.2 (10-02-2018).doc 2. Overview of StressX Elite Package Each package includes the following: Quantity Item Legend StressX Elite Molle Mount Carrier StressX Elite Controller StressX Elite Arm Shocker StressX Elite Stomach Shocker StressX Elite Controller Output Plug Caps StressX Elite Controller Input Plug Cap AA Batteries Document:...
Page 18: Electronics Specifications
User Guide StressX Elite rev_1.2 (10-02-2018).doc 2.1. Electronics Specifications The StressX Elite Controller is RoHS compliant and meets or exceeds United States military requirements for all internal and external components. 2.2. Environmental The StessX Elite is dust proof and capable of being submerged in 1 meter of static water for up to 30 minutes.
Page 19: Stressx Elite Nomanclature
User Guide StressX Elite rev_1.2 (10-02-2018).doc 3. StressX Elite Nomanclature 3.1. StressX Elite Nomanclature Legend Symbol Description Battery Compartment #1. Battery Compartment #2. Mini USB Access Port. Output Receptacle #1. Input Receptacle. Output Receptacle #2. Document: User Guide StressX Elite rev_1.2 (10-02-2018).doc 10/2/2018 Page 19 of 38...
Page 20: Function Buttons
User Guide StressX Elite rev_1.2 (10-02-2018).doc 3.2. Function Buttons Legend Symbol Description Function Power On/Off The Power button is used to power the StressX Elite Controller on and off. Navigate Up The Navigate Up button is used to increase the mode number or shock level.
Page 21: Assembly
User Guide StressX Elite rev_1.2 (10-02-2018).doc Shock Level The Shock Level button places the StressX Elite Selection Controller in the Shock Level adjustment state. Mode Selection The Mode button places the StressX Elite Controller in the mode navigation state. Battery Life The Battery Life indicator identifies when the Indicator batteries should be changed.
Page 22 User Guide StressX Elite rev_1.2 (10-02-2018).doc 2. Attach the Belt Shocker to output 1, the Arm Shocker to Output 2, and the sensor system to the input. (MILES integration device used for illustration purposes.) Belt Shocker M.I.L.E.S. Arm Shocker Integration Device Document: User Guide StressX Elite rev_1.2 (10-02-2018).doc 10/2/2018...
Page 23: Battery Installation
User Guide StressX Elite rev_1.2 (10-02-2018).doc 4. Battery Installation 4.1. Overview of Battery Installation The StressX Elite Controller is powered by four (4) AA batteries. The StressX Elite Belt and Arm Shockers do not require batteries as they are powered from the StressX Elite Controller. The StressX Elite Controller has two battery compartments that hold two (2) of the four (4) required batteries.
Page 24: Uninstalling Batteries From The Stressx Elite
User Guide StressX Elite rev_1.2 (10-02-2018).doc 4.3. Uninstalling Batteries from the StressX Elite 1. Unscrew the cap to battery compartment one (B1). 2. Insert two AA batteries with the positive (+) post in first. 3. Screw the cap to battery compartment one (B1) back on and hand tighten. 4.
Page 25: Operating The Stressx Elite
User Guide StressX Elite rev_1.2 (10-02-2018).doc 5. Operating the StressX Elite This section explains how to perform the following: Powering on the StressX Elite • Powering off the StressX Elite • Selecting a training mode • Selecting a shock level •...
Page 26: Powering Off The Stressx Elite
User Guide StressX Elite rev_1.2 (10-02-2018).doc NOTE: During start-up a self test is run by the StressX Elite Controller. If any concern is identified and error code will be displayed in digital display. 5.2. Powering off the StressX Elite Press and hold the Power On/Off button for three (3) seconds until OFF appears.
Page 27: Selecting A Training Mode
User Guide StressX Elite rev_1.2 (10-02-2018).doc NOTE: When shock level five (5) and six (6) is selected for Injured Soldier mode, only the first shock will occur at the selected level, then the remaining shocks for the 30 second duration will drop to a level four (4).
Page 28 User Guide StressX Elite rev_1.2 (10-02-2018).doc Press the up or down arrow until desired mode number is displayed in the Mode Selection Window (Digital display directly above the Mode Selection button). Press the Enter button when the desired mode is displayed. The mode is now uploaded and ready for use.
Page 29: Understanding Shock Levels
User Guide StressX Elite rev_1.2 (10-02-2018).doc 5.5. Understanding Shock Levels The shock level can be adjusted manually by utilizing the shock level selection button. Each shock level increases the amount of time the shock is delivered. This allows for more pulses to be delivered as the interval increases.
Page 30 User Guide StressX Elite rev_1.2 (10-02-2018).doc Press the up or down arrow until desired shock level is displayed in the Shock Selection Window (Digital display directly above the Shock Level Selection button). Press the Enter button when the desired shock level is displayed. Document: User Guide StressX Elite rev_1.2 (10-02-2018).doc 10/2/2018...
Page 31: Understanding The Hit Counter
User Guide StressX Elite rev_1.2 (10-02-2018).doc The shock level is now uploaded and ready for use. Note: When Mode 2 (Move to Cover Mode) is selected, the shock level will default to level one (1). This means the first activation will occur at a level one (1). Each subsequent activation will occur at a shock level one higher than the previous activation.
Page 32 User Guide StressX Elite rev_1.2 (10-02-2018).doc Press and hold the Hit Counter button for three (3) seconds and the Hit Counter Display will reset to zero (0). Document: User Guide StressX Elite rev_1.2 (10-02-2018).doc 10/2/2018 Page 32 of 38...
Page 33: Trouble Shooting
User Guide StressX Elite rev_1.2 (10-02-2018).doc 6. Trouble Shooting 6.1. StressX Elite won’t power on. Possible Problem Corrective Action 1. No Batteries in StressX Elite. Place new batteries into StressX Elite. 2. Batteries are dead or are too low. Place new batteries into StressX Elite. 6.2.
Page 34: Cleaning And Maintenance
User Guide StressX Elite rev_1.2 (10-02-2018).doc 7. Cleaning and Maintenance 7.1. Cleaning the StressX Elite StressX Elite Controller The StressX Elite can be cleaned with a cloth that is damp with clean, warm water. Prior to cleaning, always: 1. Ensure battery caps are on securely. 2.
Page 35: Maintenance (Software Updates)
User Guide StressX Elite rev_1.2 (10-02-2018).doc 7.3. Maintenance (Software updates) Periodically, the StressX Elite Controller will require a software update. An email will be sent to the email address provided when the StressX Elite is registered. Instructions will be provided on the link provided on how to conduct the software update.
Page 36: Saab® Integration Device (Optional)
User Guide StressX Elite rev_1.2 (10-02-2018).doc 8. Saab® Integration Device (Optional) The Saab® Integration Device (SID) allows the StressX Elite to be integrated with the Saab® Personnel Detection Device (PDD). It will allow the StressX Elite to be triggered when the PDD is activated during training.
Page 37: Connecting The Saab® Integration Device To The Stressx Elite
User Guide StressX Elite rev_1.2 (10-02-2018).doc 8.2. Connecting the Saab® Integration Device to the StressX Elite Attach the Saab® Integration Device connector to the StressX Elite’s Input Receptacle. Saab® Integration Device 8.3. Syncing the Saab® Integration Device to the Saab® Personnel Detection Device (PDD) Before the StressX Elite can be used with the Saab®...
Page 38: Mounting Saab® Integration Device
User Guide StressX Elite rev_1.2 (10-02-2018).doc 4. Hold the Saab Integration Device against the Saab® PDDs IR-port until the vest indicates syncing is complete. 5. The ‘Hits’ display on the StressX Elite will change to ‘0’ to indicate that the syncing is complete and the StressX Elite is now ready to be used with the Saab PDD.
