Summary of Contents for U-FLY W606-3
- Page 3 Blade Replace method Blade A Matters: Blade B 1.Take out to replace the tail blade, according to the figure change corresponding to the tail blade. If change error, will not be able to control. 2.Tail blade A turn counterclockwise direction,Tail blade B turn clockwise direction.
- Page 5 BATTERY CHARGING USING INSTRUCTIONS 1. When playing the drone,please connect the drone’s power with two wires( positive and negative pole ) to the battery with two wires(positive and negative pole). (figure 1). 2. When charging,please unplug the two wires (positive and negative pole) plug at first,then connect the drone’s three wires plug to the charger.
-
Page 6: Operating Method
2.4G FREQUENCY FOR INSTRUCTIONS 1.Put the power into the drone slot,open the drone power switch and placed on level ground smoothly,and then open the remote controller switch.The remote controller indicator light will flash frequency for the state.After the frequency of state succeed,the controller's indicator light will be bright.The drone head lights will be bright after flashing 2-3 times and the back lights will flash all the time.At this time,you can control the drone fly. -
Page 7: One Key Return
TRIMMER ADJUST THE DESCRIPTION How Does Headless Mode Work: The functioning of headless mode is pretty simple. The only pre-requisite is that before taking off, you’re required to position the drone in such a way that its front is your front. Since yaw (the left stick) anyway doesn’t have anything to do with orientation (left is left and right is right all the time, regardless of where your drone is pointing at), it is how the drone... -
Page 8: Calibration Method
CALIBRATION METHOD 1.When the hexacopter appear rotation flying and blades can not normal rotate.Put the hexacopter in the horizontal place,calibrate the transmitter,move both joysticks simultaneously down and to the right to their maximum positions. At this time, hexacopter light flashing, let go of the joysticks. It means calibration successful. 2.when the hexacopter has been in a direction rotation or move,controller trim is also can not be transferred to the midpoint. - Page 9 一、CAMERA INSTALLATION INSTRUCTION: (Built- in Camera ) TF Card Slot Camera Camera Socket 8.TF Card Reader Slot Screen 2.TF Card Slot 1.Video/Photo 5.Slow Backward / Down 2.TF Card Slot 6.OK 3.ON /OFF 7.Menu 4.Fast Forward / Up 8.TF Card Reader Slot...
