Summary of Contents for AIRKNIGHT AK1000

  • Page 1 Quick Start Guide www.airknight.io...
  • Page 2 PROTECT YOUR AIR The AirKnight AK1000 is an advanced, multifunctional air quality monitor that combines numerous different types of high-quality air sensors with a built-in fan to allow real-time monitoring of carbon dioxide (CO2), formaldehyde (HCHO), total volatile organic compounds (TVOC), PM2.5/10, air quality...
  • Page 3 Set the time (see step-by-step directions on the next page). STEP 3: The AK1000 will automatically turn off after 11 hours in order to recalibrate the sensors and prolong STEP 4: the product life (including battery life). Turn it back on when you want to use it again.
  • Page 4 TIME / TEMPERATURE ADJUSTMENT & CHARGING Time Adjustment: Press the power button (quickly) 3 times to enter time setting mode. Press the left or right buttons to adjust the hours. Then press the power button to switch to minutes. Press the left or right buttons to adjust the minutes. Once done adjusting, press the power button to confirm and complete the time setting.
  • Page 5 CO2 levels (i.e. by opening a window / door or stopping the activity causing the high reading). Note 1: The default setting for the CO2 alarm is OFF. The AK1000 CO2 alarm can be turned on by simply pressing the LEFT button on the top of the monitor twice. Exposure to less than optimal CO2 levels for an extended period of time may not be healthy and it is therefore recommended to turn this CO2 alarm function ON.
  • Page 6 / fumes, the device may need to be reset. Open a window or bring the AK1000 outdoors to allow the sensors to exhaust any possible accumulated fumes and to allow the readings to adjust back down to more normal levels.
  • Page 7 HOW TO INTERPRET READINGS Good Acceptable Unhealthy Very Unhealthy 0-1000 1000-2000 2000-3000 3000+ HCHO 0.0 - 0.1 0.1 - 0.123 0.123 - 0.5 0.5+ TVOC 0-0.5 0.5-1.0 1.0-3.0 3.0+ PM 2.5 0-35 35-55 55-75 PM 10 0-60 60-80 80-100 100+ Temperature 65°F-79°F <65°F or >79°F...
  • Page 8 PARAMETERS PARAMETERS Measurement Measurement Measurement Resolution Range Method Accuracy 400-5000 PPM Infrared (NDIR) 1 PPM 50ppm±5% ±10 g/m (0~100 g/m ), PM 2.5, PM 10 0-999 g/m Laser Scattering 1 g/m ±10%(≥100 g/m ) HCHO 0.000-1.999 mg/m Semiconductor 0.001 mg/m ±15% TVOC 0.000-9.999 mg/m...

  • Page 9: Carbon Dioxide (Co2)

    UNDERSTANDING THE AIR QUALITY METRICS 1. CARBON DIOXIDE (CO2) Carbon Dioxide is a gas which is colorless, tasteless, and important for plant photosynthesis. Too much CO2 may cause drowsiness, reduce cognitive function, and poor decision making. CO2 is generally allowable up to 1,000ppm. With readings above 2,000, it can cause dizziness, tinnitus, or even suffocation.
  • Page 10 2. TOTAL VOLATILE ORGANIC COMPOUNDS (TVOC) TVOC stands for “Total Volatile Organic Compounds” and is comprised of organic compounds / substances that have a high vapor pressure. Irritation to nose, throat, eyes and affects on breathing which could produce symptoms such as fatigue, nausea, skin problems and more. High levels could affect organs and damage the lungs, liver, kidney or the nervous system.
  • Page 11 3. FORMALDEHYDE (HCHO) Formaldehyde is a gas that is pungent and colorless. It is typically released from burning products such as kerosene, gas, wood, or tobacco. Impact on Health: High levels of HCHO can cause eyes, nose, and throat to have a burning sensation. It will affect breathing significantly.
  • Page 12 PARTICULATE MATTER PM 2.5 Fine particulate matter that is 2.5 microns or less in diameter. shortness of breath, fatigue, coughing, chest discomfort possibly leading to heart attacks, strokes, asthma, and bronchitis, premature death from heart ailments, lung disease and cancer. PM2.5 is worse than PM10 because its size is smaller, allowing it to penetrate deeper into the lungs.
  • Page 13 PARTICULATE MATTER PM 10 Fine particulate matter that is 10.5 microns or less in diameter Nasal and upper respiratory tract health problems causing long-term effects that differ depending on the source Cooking (especially using the stovetop) High emissions of gas, oil, diesel fuel and burning wood Pollutants that come from power plants, automobiles, and indus trial buildings Older appliances that burn (stove) will produce higher levels of PM Tips to Improve: Remain indoors when external levels are high.
  • Page 14 6. AIR QUALITY INDEX (AQI) An indication of overall air quality including the top four major pollutants: ground level ozone, carbon monoxide, sulfur dioxide, and airborne particles (aerosols) / particulate matter. Respiratory and circulatory systems issues which vary depending on the source Cold winter air Cooking Pollution from traffic...
  • Page 15 8. HUMIDITY Humidity is the level of water vapor in the atmosphere. With an increase of humidity by 35% or more, formaldehyde emissions will increase and remain suspended in the air. Humid outdoor weather Activities which release steam / moisture into the air such as drying laundry, taking a hot bath or shower, or boiling water/liquid Tips to Improve: Utilize dehumidifiers to control levels of humidity.
  • Page 16 This air quality monitor is meant to be used indoors and kept dry at all times. It is strongly recommended to store in a cool, dry place. Sampling Frequency: The sampling frequency of the AK1000 is 1.5 seconds. This means that your AirKnight is providing you with updated readings every 1-2 seconds. Please note that, in order to provide constantly-updated, real-time readings, the AK1000 contains a continuously running mini fan which gives off a very slight buzzing sound.

  • Page 17: Product Specifications

    PRODUCT SPECIFICATIONS Model AK1000 Power Source Rechargeable Lithium-Ion Battery Battery Capacity 3000 mAh Charging Input AC 100-240V, 5V Micro USB Connection Product Size 7.48 x 3.15 x 2.05 Inches Display Method LCD VA Screen Atmospheric Pressure 12.47 PSI - 15.37 PSI Sampling Frequency 1.5 Seconds...
  • Page 18 For more info on air quality, go to www.AirKnight.io. LEGAL DISCLAIMER The use or misuse of this air quality monitor is conditioned upon the user’s agreement that in no...
  • Page 19 Copyright © 2022 Chicago Superior Products, LLC All rights reserved. No portion of this book may be copied or reproduced in any way without prior written consent from the author.
