Summary of Contents for Nexen WEB CONTROL EN40
- Page 1 WEB CONTROL PRODUCTS User Manual Electro-Pneumatic Transducer EN40 FORM NO. L-20097-F-0605 FORM NO. L-20097-F-0605...
- Page 2 In accordance with Nexen’s established policy of constant product improvement, the specifications contained in this manual are subject to change without notice. Technical data listed in this manual are based on the latest information available at the time of printing and are also subject to change without notice.
-
Page 3: Table Of Contents
ABLE OF ONTENTS Introduction ----------------------------------------------------------------------------------------------------------- 4 Installation ------------------------------------------------------------------------------------------------------------ 4 Electrical Connections --------------------------------------------------------------------------------------------- 5 Air Line Connections ----------------------------------------------------------------------------------------------- 6 Adjustment ----------------------------------------------------------------------------------------------------------- 7 Maintenance --------------------------------------------------------------------------------------------------------- 8 Troubleshooting ----------------------------------------------------------------------------------------------------- 8 Parts List -------------------------------------------------------------------------------------------------------------- 8 Product Numbers --------------------------------------------------------------------------------------------------- 9 Warranty -------------------------------------------------------------------------------------------------------------10 FORM NO. L-20097-F-0605... -
Page 4: Introduction
Nexen’s EN40 Electro-Pneumatic Convertor converts current input signals into corresponding pneumatic signals. Normally the “EN40” is used as part of a Nexen Tension Control System, or as an independent Electro-Pneumatic Convertor, controlled by an external signal from a Process Controller. -
Page 5: Electrical Connections
BASE MOUNTING [4] Brackets & 1. Remove “EN40” Wall Mounting Bracket. [4] 5mm Screws 1.319 Provided (or use [33.5] [4] #10 Screws) 2.638 2. Secure “EN40” to base using Brackets and M5 [67] Cap Screws provided in parts bag (See Figure 3.) 0.48 [12.2] 4.645... -
Page 6: Air Line Connections
FIGURE 8 AIR LINE CONNECTIONS Nexen’s EN40 requires clean, pressure regulated air for maximum performance and long life. Nexen offers a filter that is ideally suited for the needs of the EN40 (See PRODUCT NUMBERS section). A pre-filter, rated at 5.0 micron or less is used to remove large particles from the air supply. The coalescing filter, rated at .1 micron or less, is then used to final filter the air before it enters the EN40 (See Figure 9). -
Page 7: Adjustment
ADJUSTMENT Nexen’s EN40 has been factory adjusted and should TABLE 1 not require further adjustment with appropriate supply Model EN40-1B EN40-2B EN40-1A EN40-1D pressure (See Table 1). Imin (mADC) NOTE: If less than rated pressure is available for “Psup,” the output of the EN40 will be proportionately Imax lower. -
Page 8: Maintenance
MAINTENANCE There is no scheduled maintenance required for Nexen’s EN40 Electro-Pneumatic Convertor. TROUBLESHOOTING OPERATIONAL CHECK 3. Vary electrical signal to “EN40” within the range of 4-20mA, DC. 1. Remove Gauge Port Plug, and install a suitable a) If pressure does not vary directly with signal, air pressure gauge. -
Page 9: Product Numbers
PRODUCT NUMBERS EN40 Model Product Numbers Output Pressure Input Signal EN40-1D 912001 10–100 kPa [1.5–15 psi] 4–20 mA EN40-2B 912004 10–586 kPa [1.5–85 psi] 10–50 mA EN40-1B 912028 10–586 kPa [1.5–85 psi] 4–20 mA EN40-1A 912035 10–393 kPa [1.5–57 psi] 4–20 mA FILTER Description... -
Page 10: Warranty
WARRANTY WARRANTIES Nexen warrants that the Products will be free from any defects in material or workmanship for a period of 12 months from the date of shipment. NEXEN MAKES NO OTHER WARRANTY, EXPRESS OR IMPLIED, AND ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED.
