stealth.com TT-RXWMV000-S Assembly Instructions

TT-RXWMV000-S
RX Universal Wall Mount – Silver
IMPORTANT WARNINGS: Read the entire instruction sheet before
you begin installation or assembly. Installer must verify that the entire
wall will safely support the combined weight of all attached
equipment and hardware. Improper installation of this product can
cause extensive property damage or serious personal injury, either
during or after the installation.
It is the responsibility of the installer to ensure that all applications
including wood, concrete, block, brick, steel, etc. are secured properly
to code. California installations could require specific anchorage, and
additional mounting screws. Check with local authorities for codes in
your area. Other seismic states have similar regulations.

DISCLAIMER

This product is subject to a LIMITED WARRANTY. See other
materials included when the product was purchased. THE
MANUFACTURER AND/OR THE DISTRIBUTOR WILL BEAR NO
RESPONSIBILITY FOR ANY DAMAGES OF ANY KIND ARISING
FROM ANY IMPROPER INSTALLATION OF THIS PRODUCT.
1/8"
5/32"
7/32"
4x
2x
#14 x 2-1/2 M4 x 12 mm
3x
#14 x 2-1/2
Assembly Instructions
Locate the wall stud and
mark the top hole. Drill a
pilot 11/64 hole and insert
screw part way. Place a
level on the side of mount
and mark other holes
then drill pilot holes.
Tighten all screws to the
wall.
Note: If you have metal
studs, you will require an
appropriate anchor from
your hardware supplier.
Using the 4 screws provided and a
Philips head screwdriver attach the
LCD to the mounting plate.
4x
M4 x 12 mm
