INSTALLATION INSTRUCTIONS FOR
Before installing this product pay special attention to these instructions. It is recommended that this
product is installed by a qualified electrician to IEE wiring regulations (BS 7671) and current building
regulations. These products can safely be fitted into Zone 2. See lighting regulations diagram
Installation Steps
1. P
rior to commencing work isolate the power supply cable at the main fuse box.
2.
Check that there are no other concealed cables or pipe work in the intended installation area
(check the entire area).
3.
The mirror is mounted on the wall by means of two fixing screws.
4.
Make sure that it is at the correct height and level. Using a suitable marker through the fixing
holes mark the position of the holes on the wall.
5.
Using the correct size drill bit for the wall fixing drill holes in the marked locations. (Please note
that for certain wall types i.e. plasterboard walls, the wall fixings supplied are not
recommended)
6.
Place the rawl plugs into the holes. Feed the supply through the central rubber grommet,
position the back plate and secure using the correct fixings (the rubber washers provided must
be used to ensure no water can penetrate into the fitting).
7.
Connect the supply cable to the connector block as shown in the wiring diagram. Ensure the
conductors are fully inserted into the terminals and no loose wire strands are protruding. Fully
tighten the screws on the terminals making sure that the screw clamps onto the conductor and
not the insulation.
8.
Fix the mirror to the wall.
9.
Ensure that the correct type and wattage bulb are always used. (see Luminaire for details).
10.
Finally switch on the power, and then touch the switch sign with a finger on the sensor or wave
hands below sensor to test the product.
Shelf fixing (selected models only).
To fix glass shelf to mirror attach the metal support arms to the bottom of the mirror frame using
the screws provided. The rubber washer supplied must be used to ensure that IP44 is maintained.
Place the glass shelf and secure with the screws located underneath the metal support arm. Care
must be taken not to over tighten.

Cleaning Instructions

In order to maintain the quality finish of this product please do not use any abrasives or solvents
when cleaning this product. Use only a damp cloth for cleaning this product. Do not allow water to
stand on any part of the mirror.
Please clean any spillage that may affect the quality of the finish as described above.

Special care

Care Should be exercised when cleaning this product. Although its finish is extremely durable, it can
be damaged by harsh abrasives and cleaning pads. To clean, use a light, non-abrasive cleaning
solution or cleaning polish.
V1.10.2022
IP44 ILLUMINATED MIRRORS
.
